CDM-700 High Speed Satellite Modem
Front Panel Operation
6.3.1.5

(CONFIG:) Intfc1 (CDI-50 OC-3 Interface)

The menus depicted in this section pertain to the CDI-50 OC-3 Optical and STM-1 Copper Interface.
Intfc1 OC-3:
Tx
Select Tx, Rx or Mode using the
Intfc1 OC-3:
Intfc1 OC-3 Tx:
Data
Select Data or Ena/Dis using the
If Intfc1 OC-3 Tx:
Intfc1 Tx Data Rate:
155.520000 Mbps
Intfc1 Tx Data Rate:
Disabled
This is a 'read only' status window to display the data rate of the interface. When the Tx side of
this interface is enabled or disabled via Intfc1 OC-3 Tx:
status is reflected in this display:
•
When Tx is enabled, the data rate of the interface is displayed, as shown in the top
example.
•
When Tx is disabled, that status is reflected in this display, as shown in the bottom
example.
Press or
ENTER
If Intfc1 OC-3 Tx:
Intfc1 Tx Status:
Enable Disable
This selection activates or deactivates the transmit (Tx) side of this interface. Disabling the Tx
side deactivates it and changes the data rate to 0.
Select Enable or Disable using the
Note: Disabling the Tx side will also turn off the output power.
Rx Mode (
◄ ►
Tx
Ena/Dis
◄ ►
Data is selected:
to return to the previous menu.
CLEAR
Ena/Dis is selected:
◄ ►
E)
arrow keys. Press
ENTER
( E)
arrow keys. Press
ENTER
(E)
(E)
Ena/Dis (see next section), that
( E)
arrow keys. Press
ENTER
6–31
Revision 5
MN/CDM700.IOM
.
.
.
