Delete VLAN? No
0003
If No is selected, the VLAN will not be deleted. If Yes is selected, the VLAN will be deleted and
the VLAN table updated.
Select No or Yes using the ◄ ► arrow keys. Press
Intfc1 Gigabit Ethernet:
Intfc1 GBEI Negotiation
View (
The unit supports Auto or Manual negotiation options. Auto is the recommended setting.
Manual options include:
•
100 Mbps Half Duplex
•
100 Mbps Full Duplex
•
1000 Mbps Full Duplex Slave (Not Recommended For Normal Usage)
•
1000 Mbps Full Duplex Master (Not Recommended For Normal Usage)
Manual Negotiation
The unit supports three Manual Negotiation selections, Master/Slave, Speed and Duplex:
Mst/Slv, Speed and Dplx.
Intfc1 GBEI Negotiation
Mst/Slv
Select Mst/Slv, Speed or Dplx using the ◄ ► arrow keys. Press
Master/Slave Options
IMPORTANT
If Mst/Slv is selected, select Slave or Master using the ◄ ► arrow keys. Press
Yes
TAGGED
Negotiation
E)
Speed
Dplx
Master/Slave applies to 1000 Mbps setting only. The Master and Slave
settings are a link debug feature only and are not intended for normal use.
ENTER.
Manual
Auto
(
E)
6–49
MN/CDM700.IOM
ENTER.
ENTER.
Revision 5
