CDM-700 High Speed Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Tx Clock TCI= 2 bytes
Invert
Tx Line Code TLC= 3 bytes
Tx Carrier TXO= 1 byte
State
Description of Arguments
to Query
Command or Query.
Invert Transmit Clock, where:
s=Defines which interface slot ( 1 or 2 )
x=Invert Transmit Clock, where:
0=Normal
1=Inverted
(Note: Command valid Only with CDI-60 HSSI interface)
Example: TCI = 11 (selects Inverted TX Clock, Slot 1)
Command or Query. (G.703 Parameters)
Tx Line Code, where:
s=Defines which interface slot ( 1 or 2 )
c=Defines which channel ( 1 to 2 )
x=Defines Tx Line Code, where:
0=None ( Valid for E3, T3, and STS-1 )
1=HDB3 (Valid for E3 )
2=B3ZS ( Valid for T3 and STS-1)
(Note: Command valid Only with CDI-10 Dual G.703 interface)
Example: TLC=111 (sets Line Code to HDB3 for interface 1
channel 1)
Command or Query.
Tx Carrier State, where:
0=OFF due to front panel or remote control command
1=ON
2=RTI (receive/transmit inhibit)
3=OFF due to ext H/W Tx Carrier Off command (not a valid
argument when used as a command)
Example: TXO=1 (Tx Carrier ON)
Response to
Command
TCI =
TCI?
TCI *
TCI #
TLC=
TLC?
TLC*
TLC#
TXO=
TXO?
TXO*
TXO#
11–11
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
TCI?s TCI =sx
(see description of
arguments)
TLC?sc TLC=scx
(see description of
arguments)
TXO? TXO=x
(see description of
arguments)
