CDM-700 High Speed Satellite Modem
Front Panel Operation

6.3.6 (SELECT:) Util

UTIL: RT-Clk

Display Firmware
Select RT-Clk, Ref, ID, Display, Firmware, or FAST using the ◄ ► arrow keys. Press
.
ENTER
UTIL: Rt-Clk
Edit Real-Time Clock:
10:23:51 23/05/06 (
Edit the time and date settings of the real-time clock by selecting the digit to be changed, using
the ◄ ► arrow keys. The value of the digit is then changed using the
.
ENTER
Note: In accordance with international convention, the date is shown in DAY/MONTH/YEAR
format.
UTIL: Ref
Internal 10 MHz Ref Freq
Fine Adjust:+1911
This menu provides a fine adjustment for the internal 10 MHz reference. The range is +2000
counts to -2000 counts.
UTIL: ID
Edit Circuit ID:
------------------------
Edit the Circuit ID string, using the ◄ ►
characters) is available. Select the cursor position on the bottom line using the ◄ ► arrow keys,
then edit the selected character using the
Once the string has been composed, press
Ref ID
FAST
(
arrow keys. Only the bottom line (0 to 24
arrow keys. The following characters are available:
<Space> ( ) * + - , . / 0-9 and A-Z
ENTER
6–66
E)
E)
.
Revision 5
MN/CDM700.IOM
arrow keys. Press
