CDM-700 High Speed Satellite Modem
HSSI Interface (CDI-60)
D.2
Physical Description
The HSSI data interface is implemented on a 3.95 x 7.022 inch (10.03 x 17.83 cm) PCB.
Connection to the modem is provided when the 96-pin DIN connector is engaged into the modem
slot. The HSSI interface consists of a 50-pin SCSI connector and an activity Light-Emitting
Diode (LED) that is lit when the interface is enabled.
D–3
Revision 5
MN/CDM700.IOM
