Magellan
9500/9500Ω
9504/9504Ω
®
with SmartSentry
Product Reference Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Magellan 9500 and is the answer not in the manual?

Questions and answers

Related Manuals for Datalogic Magellan 9500

Summary of Contents for Datalogic Magellan 9500

  • Page 1 ® Magellan 9500/9500Ω 9504/9504Ω ® with SmartSentry Product Reference Guide...
  • Page 2 Datalogic reserves the right to change any specification at any time without prior notice. Datalogic is a registered trademark of Datalogic S.p.A. in many countries and the Datalogic logo is a trademark of Datalogic S.p.A. All other brand and product names referred to herein may be trademarks of their respective own- ers.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1. Introduction ..................1-1 Manual Overview ......................1-1 How to Use This Manual ..................1-2 Scanner and Scanner/Scale Nomenclature ..............1-4 Connectors ......................1-5 Physical Parameters ....................1-6 Scanning ......................1-6 Deactivating EAS Tags ...................1-6 Weighing ......................1-7 Warm-Up Time .....................1-8 Electrical Specifications ....................1-10 Power Supply .....................
  • Page 4 Viewing Angle ..................... 2-28 Placing and Installing the Remote Scale Display ............2-29 Changing Weighing Modes ..................2-32 Set-Up & Installation ....................2-33 EAS Considerations ..................... 2-33 Set-up ....................... 2-36 Installation ......................2-38 System Power-Up Recap .................... 2-41 Chapter 3. Operation and Maintenance ............3-1 Scanning Items ....................3-1 Deactivating Security Labels ...................3-3 Proper Weighing Technique ..................3-5...
  • Page 5 Shift Test (Metric) ....................5-12 Increasing- Load Test (Phase 2) ................5-13 Blanking Test ..................... 5-14 Decreasing-Load Test ..................5-15 Return to Zero Test ..................... 5-15 Chapter 6. Programming................... 6-1 Introduction to Label Programming ................6-1 Understanding the Basics .....................6-1 Integrating the Scanner With Your Host System ..............6-2 Customizing Your Scanner’s Operation ..............6-2 Programming Overview ....................6-4 Programming via Handheld Device ................6-4...
  • Page 6 EAS Deactivation Duration — Retry ............... 6-57 EAS Deactivation Duration — Manual ..............6-58 Interface Related Features ..................6-59 Interface Type ....................6-59 Maximum Host-Transmitted Message Length ............6-66 Number of Host Transmission Buffers ..............6-67 Global Prefix ....................... 6-68 Global Suffix .......................
  • Page 7 UPC-A Enable ......................6-121 UPC-A Number System Character Transmission ............ 6-122 UPC-A Check Character Transmission ..............6-123 Expand UPC-A to EAN-13 ................... 6-124 UPC/EAN AIM ID ....................6-125 UPC-A Label ID ....................6-126 UPC-A 2-Digit Supplemental Label ID ..............6-127 UPC-A 5-Digit Supplemental Label ID ..............
  • Page 8 RSS-14 Check Character Transmission ..............6-176 RSS-14/EAN-128 Emulation ................6-177 RSS-14 2D Component Enable ................6-178 RSS-14 AIM ID ....................6-179 RSS-14 Label ID ....................6-180 RSS Expanded Enable ....................6-181 RSS Expanded EAN-128 Emulation ..............6-182 RSS Expanded 2D Component Enable ..............6-183 RSS Expanded AIM ID ..................
  • Page 9 I 2 of 5 Check Character Transmission ..............6-224 I 2 of 5 AIM ID ....................6-225 I 2 of 5 Label ID ....................6-226 I 2 of 5 Length Control ..................6-227 I 2 of 5 Maximum Label Length ................6-228 I 2 of 5 Minimum Label Length ................
  • Page 10 Accepting Commands from an RS-232 Scanner Host ............D-1 Appendix E. Factory Defaults............... E-1 Appendix F. Handheld Data Format Requirements....... F-1 Handheld Data Format Requirements General ............F-1 Datalogic Handheld Data Format Requirements ............F-2 AIM Formats ...................... F-10 ® Magellan 9500...
  • Page 11 Agreement. If you do not intend to be bound to the terms of this Agreement, Data- logic is not willing to license the Software to you, you may not use the Datalogic Product or the Software, and you must contact the party from whom you acquired the Datalogic Product for instructions.
  • Page 12 Software clause at DFARS 252.227-7013(c)(1)(ii), whichever is applicable. If End User is using the Datalogic Product outside of the United States, End User must comply with the applicable local laws of the country in which the Datalogic Product is used, with U.S. export control laws, and with the English language version of this Agreement. The provisions of the "United Nations Convention on International Sale of Goods"...

  • Page 13: Chapter 1. Introduction

    Chapter 1 Introduction This Product Reference Guide contains comprehensive instructions on how to install the scanner or scanner/scale (either model may be termed “scanner” for the purpose of simplicity in this manual), how to program it using special programming feature bar code labels, and advanced user information as described in the following overview.

  • Page 14: How To Use This Manual

    , details procedures and provides custom bar- Chapter 6 Programming codes for setting programmable scanner and scanner/scale features. This chapter is organized by the categories: General Features, Interface Related Features and Symbology Related Features. , lists the various functions Appendix A LED/Beeper Indications &...

  • Page 15: Manual Conventions

    Manual Overview Manual Conventions ‘NOTE’ blocks contain information that is helpful and rec- ommended. They provide information that is critical to operations and/or procedures described in this manual. ‘LEGAL NOTE’ blocks indicate procedures or activities LEGAL NOTE which may be regulated under law by governmental agencies.

  • Page 16: Scanner And Scanner/Scale Nomenclature

    Scanner and Scanner/Scale Nomenclature Controls, indicators and other nomenclature are shown in Figure 1-1 Figure 1-1. Scanner/Scale Nomenclature Scanner LED (Green) Volume/Tone Push Button Weighing Surface — Lean Oversize Produce Here Scale LED (Yellow) EAS LED (Tri-Color) Bonnet Vertical Window Horizontal Window Scale Zero Push Button...

  • Page 17: Connectors

    Scanner and Scanner/Scale Nomenclature Connectors The appearance of the connector panel will vary depending upon the fac- tory options purchased with your model. Reference Figure 1-2 Figure 1-2. Connector Panel 0.00 POS Terminal Remote Display Aux. Port Scale Host Power EAS Port POS TERMINAL REMOTE DISPLAY AUXILLIARY PORT...

  • Page 18: Physical Parameters

    Physical Parameters This chapter provides specifications for performance, environmental and electrical parameters. Reference the second chapter of this manual, Site , for physical measurements of all models and Preparation and Installation some accessories. Scanning The scanner has a scan zone between the two windows where the scanner projects laser light in order to scan items.

  • Page 19: Weighing

    Physical Parameters Weighing Specifications for scale capacity, settling time, minimum and maximum static weight, zeroing, and warm-up time are given below. For more infor- mation regarding the topic: , refer to the Proper Weighing Technique Opera- chapter of this manual. tion and Maintenance Rated Weight Capacity The scale’s operational weight capacity is:...

  • Page 20: Warm-Up Time

    Warm-Up Time There are two pertinent warm-up times that apply to the scanner or scan- ner/scale: The two warm-up periods can be performed concurrently, thereby reducing the total required warm-up time to 60 minutes. NOTE Thermal Equilibrium When the unit is moved from a cooler temperature (such as a storage area) to a warmer environment (such as a checkstand location), 60 minutes must be allowed to acclimate the unit to ambient conditions prior to cali- bration or operation.
  • Page 21 (4,842 LUX) (86,080 LUX) Humidity Spill Proof Hot / Wet 40°C / 95% RH (Datalogic MS-0006-13-0004) Hot / Dry 40°C / 5% RH Cold / Dry 10°C / 5% RH Warm / Wet 25%C / 50% RH Storage +70 C...

  • Page 22: Electrical Specifications

    Electrical Specifications Before installation, always verify that the site’s electrical service meets the scanner/scale’s requirements. The scanner has been engineered for com- patibility with most international electrical systems operating in ranges from 100 to 240VAC at 50-60 Hz. Verify that the power source will sup- ply “clean”...

  • Page 23: Laser And Product Safety

    Laser and Product Safety Laser and Product Safety Laser safety requirements are based on IEC Standard Publication 60825-1 (2001) and CDRH 21CFR, Chapter 1, Subchapter J and (CDRH) Laser Product Performance Standard, User information [1040.10(h)1]: • User Maintenance. No user maintenance of the system other than cleaning of the scan windows is required.
  • Page 24 Safety precautions to be taken: No adjustments or alteration of the scanner or scanner/scale housing are to be attempted by the user. The failure of the facet wheel motor while the unit is continuing to emit a laser beam causes the emission levels to exceed those for inherently safe CAUTION operation.

  • Page 25: Labeling

    Labeling Labeling Regulatory, reference and safety labeling is shown in Figure 1-4 Figure 1-4. Labeling Or... Located on EAS Single-Antenna models = 3000 n = 3000 Max 15 kg e = .01 lb Min 0.1 kg e = 0.005 kg Max 30 lbs IEC CLASS 1 LASER PRODUCT NTEP: 02 - 043...

  • Page 26: Agency Compliances

    Canada Measures Canada New York New York Certificate 90/384/EEC Directive NWML OImL R76-1 and R76-2 ® Contact Datalogic Product Marketing at (541) 683-5700, or your Datalogic representative for a complete listing of approvals for other countries. 1-14 ® Magellan 9500...

  • Page 27: Bar Codes Supported

    Bar Codes Supported Bar Codes Supported The scanner can read/decode the following bar code types (symbologies): • UPC Versions A & E • UPC Supplementals and Add-ons (2 & 5 digit supplimentals, Cou- pon code and Code 128) • Plural Stage Dual UPC Bar Codes for Japan ( 2 label read) •...
  • Page 28 NOTES 1-16 ® Magellan 9500...

  • Page 29: Chapter 2. Site Preparation And Installation

    Chapter 2 Site Preparation and Installation This chapter provides a reference for preparing most checkstands to receive the scanner or scanner/scale. Included are physical parameters and instructions for checkstand preparation, power and ventilation consider- ations, cable routing information and unit installation. Site Preparation lists all procedures necessary to prepare the checkstand.

  • Page 30: Pre-Installation Considerations

    Figure 2-1. 9500 Models Model 9501 Model 9502 Pre-Installation Considerations It should be noted that the scope of this manual does not encompass all factors related to worker safety and checkstand design. It does, however, offer a list of considerations that may be helpful in ensuring greater safety and productivity.

  • Page 31: Checkstand Design

    Checkstand Design Checkstand Design 1. Select a design which allows load-sharing by several muscle groups (for example designs which allow the cashier to use both hands for scanning and bagging). 2. Select checkstands which deliver products to the cashier on an input belt and do not require the unloading of items from a cart.

  • Page 32: Scanner Installation

    Scanner Installation 1. Mount the horizontal surface of the scanner flush with the counter- top to encourage slide scanning rather than lifting. 2. Position the centerline of the scanner read area 8 - 10 inches (20.3 - 25.4 cm) from the edge of the checkstand (cashier side). Scanner Maintenance 1.

  • Page 33: Site Preparation Overview

    Site Preparation Overview Develop a smooth fluid motion during scanning, sharing work equally between hands. Use the entire hand for grasping and lifting items. Since the scanner reads labels on all four sides plus the top and bottom, there is no need to turn a bar code toward either of the scanner windows.
  • Page 34 Recommended Power Installation: Since the typical grocery envi- ronment includes conveyor belts and electric motors, care should be taken to ensure that the scanner has a supply of “clean” power (power without excessive electrical noise). A wiring diagram shows the recommended wir- ing that will provide the scanner with a “clean”...

  • Page 35: Ventilation And Spacing

    Ventilation and Spacing Vertical Clearance: Provision must be made to allow adequate space above the scanner bonnet for removal and replacement of the All Weighs™ Platter (the L-shaped platter). Optimal clearance permits the platter to be grasped at its top vertical edge and lifted for removal without obstruction (such as a fixed keyboard mount or any type of enclosure).
  • Page 36 • A source of air that provides adequate cooling by convective air flow. DO NOT place the scanner in a close-fitting, fully enclosed checkstand. Pro- vide a MINIMUM of 16 square inches (103.2 square centimeters) of air intake from below the installation for sufficient convective cooling. NOTE If motors, conveyor belts, or other heat producing equipment are located near the scanner, forced air ventilation may be required.

  • Page 37: Service Access

    Service Access Service Access The scanner and scanner/scale have been engineered to allow performance of all routine service and maintenance (such as “zeroing” and calibration) without removing the scanner from the checkstand. Additionally all cable connections made at the scanner can be connected and removed while the unit is sitting on the countertop.

  • Page 38: Power Installation

    Power Installation Reference the wiring diagram in for the recommended fusing Figure 2-4 arrangement. Grounding The AC/DC Power Supply should have an AC outlet with a clean earth ground. If you are not sure how to verify the amount of electrical noise (interference) on the power line, ask a qualified electrician to measure the input line voltage.

  • Page 39: Checkstand Preparation

    Checkstand Preparation Checkstand Preparation Reference . When performing a first time installation into a Figure 2-5 new checkstand, verify before cutting that room will be allowed for ® cabling, the AC/DC Power Supply, and the Sensormatic Controller Box. When making the opening, take extra care to accurately cut to the correct dimensions.

  • Page 40: Liquid Spills And Moisture

    Liquid Spills and Moisture Select a checkstand design which allows fluids to flow through, and directs liquids away from any electronic equipment or storage areas. Counter Cutout The most important consideration when planning the counter opening for the scanner is the operator’s comfortable reaching distance. The ideal, ergonomically sound installation allows items to be directed within easy reach, and a scanning area requiring no lifting or special orientation of items.
  • Page 41 Counter Cutout 3. Install the AC/DC Power Supply, the Remote Scale Display cable and the interface cable(s) observing the following: Interface cables (and display cable, if applicable) should be routed away from all highly inductive electrical devices, like motors and conveyor belts, and even away from the unit’s power cable if possible.
  • Page 42 Figure 2-6. Typical Checkstand Design & Cutout Location Remote Display Conveyor POS Terminal & Printer Optional Item Diverter Deadplate 6.3" (16.0cm) Scanner Keyboard Cash Drawer (Below Scanner) Scan & Bag Well (Optional) Check Writing Flush — Correct Stand Take-Away (Optional) Belt Bagging Above Flush —...
  • Page 43 Counter Cutout Refer to for dimensional information. Figure 2-7 Figure 2-8 provide counter cutout details for model 850x/950x inter- Figure 2-9 changeability and minimum required counter cutout (for new 950x instal- lations) respectively. Figure 2-7. Dimensions 8.0" Window (20.32cm) 8.6" (21.84cm) 7.0"...
  • Page 44 Figure 2-8. Cutout Dimensions: Recommended for 8500/9500 Interchangeability 20.125" (51.12cm) 18.625" (47.30cm) Max. Radius = 0.25" (0.64cm) 4x Rail 3.0" ± .03" (7.62 ± .76mm) 0.75" 11.625" (1.9cm) (29.53cm) (Center Line) Rail 0.75" If leveling feet are needed, (1.9cm) 3.0" ± .03" use the placement shown here, (7.62 ±...
  • Page 45 Counter Cutout Figure 2-9. Cutout Dimensions: Minimum Required Counter Cutout 20.09 ± 0.06" (51.03 ± 0.15cm) 17.88 ± 0.06" (45.26 ± 0.015cm) Max. Radius = 0.25" (0.64cm) 4x Rail 3.0" ± .03" (7.62 ± .76mm) 1.22" 11.562" (3.1cm) (29.367cm) (Center Line) Rail 1.0"...

  • Page 46: Checkstand Mounting

    Checkstand Mounting There are a number of things to take into account when installing the unit into a checkstand. Key factors are ergonomic/worker safety, loading capac- ity and stability. Consider the scanner or scanner/scale’s weight when cal- culating the robustness of construction needed to support it as well as maximum capacity of weighed and scanned items.

  • Page 47: Unpacking

    Installation Overview The following text describes each of these steps. Unpacking To unpack the unit: • Inspect the package for signs of damage that may have occurred dur- ing shipping. If damage is found, report it to your carrier immedi- ately.

  • Page 48: Operational Verification

    Figure 2-10. Remove Protective Vinyl Protective vinyl MUST be removed from the platter before use. • Proceed to the instructions below. Operational Verification Operational Verification Follow these steps to ensure that your unit has arrived undamaged and is fully functional before installing it in the counter and connecting it to your POS system.
  • Page 49 Installation Overview When power is applied to the unit, the normal indicator sequence is: • The scanner indicator (top-most, green LED) will be lit (dim) steadily. • The EAS indicator (bottom-most, tri-color LED) will flash ON/ OFF during power-up. Additionally, the 7-segment display will flash the number ‘9’.
  • Page 50 Scanner: Pass UPC/EAN bar code labels in front of the scanner’s win- dows. Since the interface cable is not yet connected to the POS ter- minal, the scanner may be limited to reading only one or two labels (see the note that follows). The scanner indicates when each label has been successfully read by flashing the green scanner light and emitting a good read tone (beep).
  • Page 51 Installation Overview Scale: If the Yellow (middle, scale) LED is not lit, press the Scale Zero Push Button momentarily. If the scale is operating correctly, the yel- low LED will illuminate and remain on steady, and the display will show a reading of 0.00 lb (0.000 kg for metric). If the display is blank or a is displayed, it may be necessary to calibrate - 0 -...

  • Page 52: Diagnostic Modes

    Diagnostic Modes Two diagnostic modes are available which allow you to initiate scanner or scale diagnostic tests, as well as verify the scanner’s ability to read bar codes. Scanner Diagnostic Mode While in Scanner Diagnostic Mode, continuous scanning of labels is allowed, permitting the user to scan an unlimited number of bar codes while troubleshooting problems.

  • Page 53: Cables & Connections

    Installation Overview Scale Diagnostic Mode To enter Scale Diagnostic Mode, press the Scale Zero Push Button for approximately four seconds. Six rapid tones will be sounded, indicating the unit is leaving normal operation and entering Scale Diagnostic Mode. The Remote Display will flash a ‘1’ across the display while the dignostic routine is being run.
  • Page 54 Figure 2-11. Cable Routing POS Terminal, Printer & Remote Cash Drawer Keyboard Display Alternate Cable Routing Scanner AC Power Switch Remote Scale (recommended) Display Cable Scanner (optional Interface AC/DC Scanner/Scale) Cable Power Supply Scale Interface Cable EAS Antenna Cable (Scanner/Scale) AC Power EAS Controller Box Optional...

  • Page 55: Remote Scale Display Placement/Installation

    Remote Scale Display Placement/Installation provides physical dimensions for the AC/DC Adapter (part Figure 2-12 number 8-0582). Figure 2-12. Physical Measurements: AC/DC Adapter 2.3" (5.8 cm) Remote Scale Display Placement/Installation When installing the optional Remote Scale Display, consider both the cus- tomer’s viewing angle and the amount of daily ambient light conditions anticipated at this installation site.

  • Page 56: Viewing Angle

    Viewing Angle The optimum viewing angle is directly facing the customer. To ensure that the display is easily readable for the majority of your customers, the dis- play should be approximately 48 to 60” (122 to 152 cm) from the floor. Check with local Weights and Measures authorities regarding proper posi- tioning of scale displays used in retail trade.

  • Page 57: Placing And Installing The Remote Scale Display

    Remote Scale Display Placement/Installation The connector at the Remote Scale Display end is secured with a rubber band during shipping to prevent damage to the “locking tabs” (see Figure 2-15). After routing the cable, remove this rubber band before the cable end con- necting to the Remote Scale Display head.
  • Page 58 Figure 2-14. Physical Measurements: Remote Display (Short Base) 5.8" 14.7 cm 0.00 3.0" 7.6 cm Minimum 5.5" (14.0 cm) Maximum 11.75" (29.8 cm) 3.375" 0.953 cm 4.5" 31.6 cm 6. Cut the stalk to fit your installation (if required). 7. Route the cable through the base/stalk so that you can plug the con- nector into the display head.
  • Page 59 Remote Scale Display Placement/Installation 11. Install mounting screws or bolts to complete the installation of the Remote Scale Display. Take care not to pinch or pierce the interface cable while securing the Remote Scale Display to the checkstand. Figure 2-15. Remote Scale Display Components Mounting Display Head Example...

  • Page 60: Changing Weighing Modes

    Figure 2-16. Remote Scale Short Base Display Mounting Template 4 1/2" (11.4 cm) 3 3/8" (8.57 cm) 3/4" (1.9 cm) RONT Changing Weighing Modes Your scanner/scale has been programmed for weighing in either pounds or kilograms depending upon the initial operating environment that was specified when you ordered your scanner/scale.

  • Page 61: Set-Up & Installation

    Set-Up & Installation Set-Up & Installation These setup and installation procedures assume that you have already pre- pared your checkstand to receive the scanner or scanner/scale. If you have not already made the counter cutout and routed power and interface cables, do so now as described in the previous instructions.
  • Page 62 Swapping Position: EAS Single-Antenna ONLY The EAS Antenna must be located in the position needed for your instal- and. Locate it as described below: lation. Reference Figure 2-18 1. Remove the platter (see Figure 2-22 2. If the unit is a model containing a scale, and the scale assembly is determined to be in the position the EAS Single-Antenna should be with regard to product flow, proceed to the next step.
  • Page 63 Set-Up & Installation 4. Disconnect the Load Cell harness. 5. Move the Load Cell/Spider Assembly into position on the opposite side of the scanner cavity and re-install the original screws. Torque the screws evenly to 50 in-lb. Figure 2-19. Locating the EAS Single-Antenna (Left-to-Right) Product Flow Product Flow EAS Antenna...

  • Page 64: Set-Up

    Set-up 1. Place the scanner on the checkstand next to the counter cutout. 2. Make all connections to peripheral devices, such as the Remote Scale Display (see ) and EAS Controller Box (see Figure 2-15 ). Power on the EAS Controller Box. Figure 2-20 Figure 2-20.
  • Page 65 Set-Up & Installation Figure 2-21. Connecting Cables to the Scanner/Scale 0.00 POS Terminal Remote Display Aux. Port Scale Host Power EAS Port POS TERMINAL REMOTE DISPLAY AUXILLIARY PORT SCALE HOST POWER EAS PORT · Test Port · Label Data Drives Remote Display Scale Data (dual AC Brick Input Connection to...

  • Page 66: Installation

    Installation 1. Make sure that all cables are firmly attached (except that the AC/ DC power supply should not be connected to the AC outlet yet). Reference , and Figure 2-5 Figure 2-20 Figure 2-21 2. Remove the All Weighs™ Platter to gain access to the lift handles. Grasp the platter as shown in and gently lift it from the Figure 2-22...
  • Page 67 Set-Up & Installation 3. Hook the fingers of both hands into the lift handles. The first is located along the inside of the front scanner wall, and the second is behind the scanner hood, as shown in Figure 2-23 DO NOT attempt to lift the unit using the EAS Antenna, plastic edges, scale frame, or any features other than the lift handles.
  • Page 68 Figure 2-23. Using the Lift Handles Marked "Lift Handle" DO NOT use the EAS Antenna to lift the unit 2-40 ® Magellan 9500...

  • Page 69: System Power-Up Recap

    System Power-Up Recap System Power-Up Recap The System Power-Up procedure may vary depending upon the require- ments of your POS system. It is generally a good practice to power-down (switch off ) all equipment prior to connecting cables. Check with your System Supervisor and/or refer to your POS terminal manual for proper power-down and power-up procedures and interface requirements when connecting any peripheral device.
  • Page 70 6. Power-up the scanner or scanner/scale by connecting the power cord to an AC power outlet. Wait for the unit to complete the Self test routine (10 seconds maximum). Successful scanner power-up is sig- nified by any or all of the following: - Facet wheel shows movement - Lasers turn on - Status LED(s) turn on...

  • Page 71: Chapter 3. Operation And Maintenance

    Chapter 3 Operation and Maintenance The information contained in this chapter describes how to operate and maintain the scanner, scale and EAS system. Topics include “how to’s” on scanning, EAS tag deactivation, weighing, re-zeroing the scale, removing the top cover and cleaning the upper and lower windows. Scanning Items To scan items using the scanner, slide or push them through the scan zone as shown in...

  • Page 72: Proper Scanning Technique

    Figure 3-1. Scan Zone Vertical Window Scan Zone Horizontal Window Scan Zone Note that eyes..indicate what the scanner "sees." Top Down Checker Side Scan Zone Scan Zone Proper Scanning Technique The scanner was designed to provide the ultimate in ergonomic enhance- ments for Point-Of-Sale (POS) scanning.

  • Page 73: Deactivating Security Labels

    Deactivating Security Labels ® ® ® Sensormatic Ultra-Max , Ultra-Strip II and III EAS (Electronic Arti- cle Surveillance) tags can be detected and deactivated by the system. This is accomplished by means of a ScanMax deactivation antenna mounted under the scanner platter (single-antenna models) or both behind the ver- tical window and under the scanner platter (dual-antenna models).

  • Page 74: Manual Eas Deactivation Push Button

    EAS Deactivation Indicators The scanner can be programmed to beep in acknowledgement of deactiva- tion or upon deactivation failure. Additionally, the tri-color indicator (the bottom-most LED) displays deactivation status. (For more information about Beeper and LED indications, see the LED/Beeper Indications & Controls chapter of this manual.

  • Page 75: Proper Weighing Technique

    Proper Weighing Technique 1. The L-shaped All-Weighs™ platter allows you to place items any- where on its surface, including leaning against its vertical section, to be weighed accurately. The raised “Produce Rail” also provides a convenient way to ensure items do not rest on the counter or other non-weighing surfaces.

  • Page 76: Operational Controls

    Operational Controls The function of scanner and scale controls and indicators is listed in Appendix A, LED/Beeper Indications & Controls. Turn to that appendix for full details. Operational Modes The scanner or scanner/scale features a number of modes that are impor- tant to both the user and the system support personnel.

  • Page 77: Error Reporting

    Operational Modes Error Reporting If a fatal error is detected during Selftest or operation, the unit will not advance to Normal Operation Mode. Selftest diagnostics will cause the unit to sound a long, low tone and/or display an error message on the 7- segment display indicating where the failure occurred.

  • Page 78: Operating Mode

    • When the scanner or scanner/scale completes its Selftest successfully, it emits a tone (when configured to do so) and enters Operating Mode. Operating Mode Operating Mode includes Normal Operation (scanning, EAS deactivation and weighing) and Sleep Mode. These two modes are most commonly observed by the user/operator.

  • Page 79: Additional Functions

    Additional Functions Sleep Mode After the scanner has been left idle for a preset period of time, the laser and/or motor automatically turns off (goes to sleep). This state is called Sleep Mode, and is indicated by a “slow” blink of the green light (blinking at a 2-second rate).

  • Page 80: Scale Adjustments

    Pressing and holding the Volume/Tone Push Button for approximately eight seconds initiates a reset, which is sounded by a rapid number of beeps. If the motor had been spinning, the lamps will blink while the motor spins down. At that point, the motor will spin back up and the scanner will continue to run the Selftest diagnostics.
  • Page 81 Additional Functions Calibrating the Scale The second adjustment, calibration, defines and sets a standard reference weight range against which all product weights are compared. If your scale is set for weighing in pounds, this range is 0 - 30 pounds, and, if your scale is set for weighing in kilograms, the range is 0 - 15 kilograms.

  • Page 82: Operational Maintenance

    Operational Maintenance The scanner or scanner/scale will provide dependable service for many years. The following maintenance procedures will keep your scanner or scanner/scale operating at peak performance. Cleaning the Weigh Platter and Scan Windows Clean the exterior sur- faces of the horizontal and vertical scan windows at least twice daily with a nonabrasive, mild, water-based glass cleaner and paper towels or lint-free cleaning tissues.

  • Page 83: Vertical Scan Window Replacement

    Operational Maintenance Vertical Scan Window Replacement The Vertical Scan Window enclosed in the All Weighs™ Platter is a replaceable part. Follow these instructions to remove and replace the win- dow: To remove the Vertical Scan Window: 1. Grasp the platter as shown in Figure 3-3 and gently lift it from the scanner.
  • Page 84 3. The vertical scan window is held in place by two tabs each on its top and bottom edges. To remove it, carefully push out on the top as shown in Figure 3-4 and lift it out. Carefully dispose of any dam- aged glass.

  • Page 85: Horizontal Scan Window Replacement (Wrg)

    Operational Maintenance Horizontal Scan Window Replacement (WRG) Wear Resistant Glass (WRG) horizontal scan windows are replaceable and can be removed and replaced following the instructions below. Sapphire glass does not require replacement, so it is permanently fastened in place. Do not attempt to remove Sapphire glass from the platter. NOTE 1.
  • Page 86 Figure 3-5. Removing/Replacing the WRG Window Remove Slide WRG Vertical Bezel Window Out 3-16 ® Magellan 9500...

  • Page 87: Chapter 4. Problem Isolation

    Chapter 4 Problem Isolation In the event of a suspected functional problem, use the troubleshooting references provided in this chapter. This useful information will help you to identify and resolve the cause of the problem. The scanner/scale has a number of features that indicate when a scanner, EAS deactivation system, or scale problem occurs.

  • Page 88: Diagnostic Procedures

    Operational Tests These are the tests that run continually during Normal Operation and Sleep Mode. Firmware checks all subsystems, accessory connections and the POS interface to verify everything is operating normally. If a problem is detected at any time, a long, low tone is sounded, an error code is shown on the 7-segment display, and operation may be halted.

  • Page 89: Error Codes

    Error Codes Error Codes If an error is detected, the scanner will sound a long low tone (for one sec- ond) and alternately flash its LEDs, indicating a failure. Following the long low tone, an error code will appear on the 7-segment display (refer to ).
  • Page 90 Error Probable Cause Corrective Action Code No POS interface has been selected (Null interface). See the topic, Configuration Interface Type, in Chapter 6 to select the required interface using pro- Blinking gramming bar codes. Chapter 6, Programming, for details about configuring the Configuration Error scanner using programming bar codes.

  • Page 91: Scale Error Reporting

    Scale Error Reporting Figure 4-1. 7-Segment LED Display 7-Segment Display Scale Error Reporting Scale diagnostics uses the Remote Scale Display and the Zero Status lamp to communicate specific scale failures. The following chart shows the Remote Display messages, the Scale Status lamp indication, the problem that the scale is experiencing and what action should be taken.

  • Page 92: Flowcharts

    Remote Scale Status Problem Action Required Display Lamp Description Flash, pause, 3 Scale communication lost. Call technical support personnel; E__3 blinks, long pause, Internal scanner/scale prob- report error. repeat sequence. lem. Flash, pause, 4 Call technical support personnel; E__4 blinks, long pause, Scale module failure.
  • Page 93 Flowcharts Figure 4-2. Problem Isolation: Start For units using an AC/DC adapter, verify that... 1. AC power cord is connected to a functional AC outlet. 2. IEC connectors are firmly connected. 3. DC power cord is firmly connected to scanner. If your unit is a model which receives Power Off the START Terminal POT), verify that the I/F cable is securely...
  • Page 94 Figure 4-3. Problem Isolation: Selftest SELFTEST START Scan the Factory Does the Does the Does the Defaults bar code in 7-segment 7-segment 7-segment Section 6 to enable the display show display show display show default configuration file. Restart the unit. No interface selected (Null Interface).
  • Page 95 Flowcharts Figure 4-4. Problem Isolation: Poor/No Reading Have you verified that all scan windows are clean and scratch-free? POOR/NO READING Before proceeding, verify that START bar code samples presented to scanner are of good quality and a symbology the scanner Enter Scanner Diagnostic Mode by can read.
  • Page 96 Figure 4-5. Problem Isolation: No Transmit to POS NO TRANSMIT TO POS START Check the interface (I/F) Verify programmable cable connections. If parameters using the possible, retest the information and programming Does the system using a known- bar codes provided in Section scanner read DONE good I/F cable.
  • Page 97 Flowcharts Figure 4-6. Problem Isolation: Scale If this is a new installation, SCALE START make sure any foam packing pieces have been removed from the scale cavity before proceeding. Lift off the platter View the Remote to verify, then set the platter Call Tech Support Display and/or the back into position.
  • Page 98 Figure 4-7. Problem Isolation: Remote Display REMOTE DISPLAY Scanner-scale models that include a Remote Display when shipped START from the factory, are configured for use with the display. If you're unsure of the settings for your unit, contact Tech Support. Is the Use the programming bar unit configured...
  • Page 99 Flowcharts Figure 4-8. Problem Isolation: EAS System Before proceeding, verify the EAS NO EAS DEACTIVATION Antenna(s) and EAS Control Box START have been correctly installed (ref. Chapter 2). Ensure operator has been trained in proper EAS system use (ref. Chapter 3). Verify programmable If possible, retest the Check all EAS...
  • Page 100 NOTES 4-14 ® Magellan 9500...

  • Page 101: Chapter 5. Calibration

    Chapter 5 Calibration A number of situations require the scale to be calibrated. They are: • at initial installation of the scanner/scale • if the scale cannot be re-zeroed • if you change the weight measure from pounds to kilograms or vice- versa •...

  • Page 102: Description Of Calibration Sequence

    Description of Calibration Sequence The Calibration Sequence sets the scale to an accurate reference point for weighing. This process involves the use of a Field Standard Weight Set (31.5-pounds) for calibration in pounds, (18.5-kilograms) for Metric. Once calibration has been successfully completed, the scanner/scale uses the certified weight as a reference for subsequent weighing activities.

  • Page 103: Motion Test

    Motion Test Motion Test This test verifies that the scale will not ‘zero’ when the weighing surface of the scanner/scale is in motion. 1. Verify that the Yellow LED is on and the Remote Display reads 0.00 pounds or 0.000 kilograms. 2.

  • Page 104: Preparing The Scanner/Scale For Calibration

    Preparing the Scanner/Scale for Calibration 1. Assure that the scanner/scale is stable, secure and properly installed. (Refer to for instructions Site Preparation and Installation Chapter 2 on the proper installation of the scanner/scale). 2. Power-up the scanner/scale. 3. Allow the unit to reach temperature equilibrium for at least one hour.
  • Page 105 Calibrating the Scale (Pounds & Kilograms) Figure 5-1. Calibration Access Cover Calibration Cover Calibration Switch 4. Press and release the Calibration Switch to place the scanner/scale in Calibration Mode. The scanner/scale will sound a tone indicating it is in Calibration Mode. If the motor was spinning when you initi- ated Calibration Mode, the motor will stop and the Yellow LED will begin flashing indicating the scale is in Calibration Mode.
  • Page 106 8. The Yellow LED will extinguish for approximately 10 seconds and the Remote Display will alternately display until the scale is ready to proceed. 9. If the calibration was successful, the speaker sounds a single tone, the Scale Status LED begins blinking again, and “End-” appears in the Remote Display.

  • Page 107: Calibration Verification (U.s. Pounds)

    Calibration Verification (U.S. Pounds) Calibration Verification (U.S. Pounds) Once you have completed the calibration sequence, you may be required to perform these step-by-step verification procedures. These procedures follow the National Institute of Standards and Technology Handbook-44 guidelines for grocery scale installations. You may be required by state or local law to have these procedures performed by a certified technician or verified by a proper official.

  • Page 108: Shift Test

    Shift Test The Shift Test checks to ensure that items placed anywhere on the weigh- ing surface of the scanner/scale are weighed properly. Refer to Figure 5-2 when performing this test. 1. Place and remove in succession, a fifteen-pound load on the center of each of the four quadrants (A, B, C, and D in Figure 5-2) of the scanner/scale’s weigh platter.

  • Page 109: Increasing- Load Test (Phase 2)

    Calibration Verification (U.S. Pounds) Increasing- Load Test (Phase 2) After completing the Shift Test, you must complete the Increasing Load Test using 20.0, 25.0 and 30.0 pounds of weight. The upper limit of the scale is configurable according to POS interface type and may not necessarily be set at 30 pounds, which is the standard setting.

  • Page 110: Decreasing-Load Test

    Decreasing-Load Test This test ensures that the scanner/scale responds properly when a heavy object is followed by a significantly smaller object. 1. Place a 30.0-pound load on the scale and verify that the display shows between 29.99 and 30.01 pounds. If the upper weight limit for your scale is not set at 30 pounds, begin by plac- ing weight equaling your upper limit setting.

  • Page 111: Calibration Verification (Kilograms)

    Calibration Verification (Kilograms) Calibration Verification (Kilograms) Once you have completed the calibration sequence, you may be required to perform these step-by-step verification procedures. These procedures follow the National Institute of Standards and Technology Handbook-44 guidelines for grocery scale installations. You may be required by state or local law to have these procedures performed by a certified technician or verified by a proper official.

  • Page 112: Shift Test (Metric)

    8. Place an additional 200 grams on the center of the weighing surface and check that the display reads 1.000 kg. 9. Increase the weight on the scale to 7.50 kg on the center of the weighing surface and check that the display reads between 7.495 and 7.505 kg.

  • Page 113: Increasing- Load Test (Phase 2)

    Calibration Verification (Kilograms) Figure 5-3. European Shift Test (Metric) CENTER Increasing- Load Test (Phase 2) After completing the Shift Test, you must complete the Increasing Load Test using 10.00, 12.50 and 15 kilograms of weight. The upper limit of the scale is configurable according to POS interface type and may not necessarily be set at 15 kilograms, which is the standard setting.

  • Page 114: Blanking Test

    Blanking Test This test ensures that the scanner/scale will indicate its weighing capability has been exceeded if a weight greater than 0.82 over its maximum upper weight limit is placed upon the unit. 1. Place weights that total the upper limit plus 0.82 kilograms on the weigh platter.

  • Page 115: Decreasing-Load Test

    Calibration Verification (Kilograms) Decreasing-Load Test This test ensures that the scanner/scale responds properly when a heavy object is followed by a significantly smaller object. 1. Place weights that total 15.8 kilograms. If the upper weight limit for your scale is not set at 15 kilograms, begin by placing weight equaling your upper limit setting plus 0.8 kilograms.
  • Page 116 NOTES 5-16 ® Magellan 9500...

  • Page 117: Chapter 6. Programming

    Chapter 6 Programming Introduction to Label Programming The programming bar code labels contained in this manual will allow you to customize and configure features and settings for your scanner (scan- ner/scale). To ensure full compatibility and proper function, use only the programming bar codes in this manual and other product-specific publi- cations to program scanner features.

  • Page 118: Integrating The Scanner With Your Host System

    Integrating the Scanner With Your Host System Your scanner MUST be equipped with the correct hardware (interface board, cable, etc.) to properly communicate with your host system. Con- tact your dealer for information if you have questions about your scanner’s hardware compatibility.
  • Page 119 Integrating the Scanner With Your Host Sys- • Interface Related Features — are the mandatory settings necessary to allow communication with your host terminal. Examples of these settings are: RS-232 baud rate and parity. It is possible, via programming bar codes, to change the interface type (for example: from RS-232 to IBM Port 17).

  • Page 120: Programming Overview

    The scanner can also accept programming via its auxilliary port using a handheld scanning device. Eligible handheld devices must have the ability to transmit Code 128 function codes such as the programming bar codes ® presented in this manual. Datalogic models QuickScan 1000 and ® QuickScan 6000 support this functionality.

  • Page 121: What Is Programming Mode

    Programming Overview What Is Programming Mode? Programming Mode is a state in which the scanner must be placed in order to accept commands via programming bar code labels. When pro- gramming using the bar code labels in this manual, the scanner is typically placed in Programming Mode by scanning the SWITCH label.

  • Page 122: Programming Session

    Programming Session A typical programming session is conducted as follows: 1. Scan the SWITCH bar code to place the scanner in Programming Mode. Depending upon its current programming, the scanner may emit a beep or beeps, indicating it has read the bar code and the scanner (top) green LED will flash on and off slowly while the scan- ner remains in Programming Mode.
  • Page 123 Programming Overview It is recommended that programming sessions be limited to one feature at a time. Should you make a mistake in the programming sequence, it can be difficult to discover where an error has been made if several features are pro- grammed at once.

  • Page 124: Programming Sequence

    Programming Sequence To modify a scanner feature (item), the programming bar codes contained in this manual must be scanned in a given sequence depending upon the feature being programmed (as shown in ). There are three possi- Table 6-1 ble programming sequences: If the scanner’s interface type must be changed, always be sure that interface configuration is the FIRST item scanned during a programming session.
  • Page 125 Programming Overview Table 6-1. Programming Sequence ITEM TAG ITEM VALUE END/RESET ENABLE NEW FEATURE SWITCH SWITCH 3 4 5 ENABLE NEW FEATURE USING THE FOLLOWING SETTINGS... SWITCH SWITCH ONE BAR CODE CONTAINS SWITCH + ITEM TAG + ITEM VALUE + SWITCH Product Reference Guide...

  • Page 126: Led And Beeper Indicators

    LED and Beeper Indicators The scanner provides a set of indicators that verify/announce the various scanner functions. If You Make a Mistake... If, during a programming session, you find that you are unsure of the scanner’s settings or wish to reset the scanner’s configuration, use the Return to Factory Settings label below to return the scanner’s configura- tion to the factory settings.

  • Page 127: Test Mode

    If You Make a Mistake... Test Mode Use this feature to place the scanner into a testing, or “demo” mode. This special mode disables the scanner interface, meaning that bar code data is not sent out to the host via the scanner interface. This allows the bar code to be scanned continuously without requiring a response from the POS terminal.

  • Page 128: General Scanner And Scale Features

    General Scanner and Scale Features Double Read Timeout The Double Read Timeout feature sets a time limit that determines how much time must pass before reading the same label again (e.g. two identi- cal items in succession). To set the Double Read Timeout: 1.
  • Page 129 General Scanner and Scale Features Double Read Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. DOUBLE READ TIMEOUT = 800ms DOUBLE READ TIMEOUT = 1 SECOND 6-13 Product Reference Guide...

  • Page 130: Laser Timeout

    Laser Timeout The laser timeout feature sets the time for switching the visible laser diodes (VLDs) off if the scanner is idle. Using this feature can prolong the life of the VLDs. To set the Laser Timeout: 1. Scan the SWITCH bar code. 2.
  • Page 131 General Scanner and Scale Features Laser Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LASER TIMEOUT = 10 MINUTES LASER TIMEOUT = 15 MINUTES 6-15 Product Reference Guide...

  • Page 132: Motor Timeout

    Motor Timeout The Motor Timeout feature sets the time for automatically switching the motor off when the scanner is not in use. Laser safety requires that the laser switch off before the motor. If you set the motor timeout shorter than the laser timeout, the motor and the laser will both shut off when the motor timeout expires.
  • Page 133 General Scanner and Scale Features Motor Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. MOTOR TIMEOUT = 10 MINUTES MOTOR TIMEOUT = 15 MINUTES 6-17 Product Reference Guide...
  • Page 134 Motor Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. MOTOR TIMEOUT = 30 MINUTES MOTOR TIMEOUT = 60 MINUTES 6-18 ®...

  • Page 135: Green Led Idle State

    General Scanner and Scale Features Green LED Idle State This feature specifies the state of the green scanner LED when the scanner is idle and ready to read a label. Options are: • • On dim To set the LED Idle State: 1.

  • Page 136: Scanner Button Options

    Scanner Button Options Configure the scanner volume button to one of the following modes of operation: • Enable all functions: Volume, tone, diagnostics and reset. • Enable only volume, tone and reset. • Enable reset only. • Disable all button functions To set the desired Scanner Button Option: 1.
  • Page 137 General Scanner and Scale Features Scanner Button Options — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCANNER BUTTON OPTION = ENABLE RESET ONLY SCANNER BUTTON OPTION = DISABLE ALL BUTTON FUNCTIONS 6-21 Product Reference Guide...

  • Page 138: Power-Up Beep Control

    Power-up Beep Control Specifies the type of audible indication that is made when entering scan- ner-active mode on power-up. Choices are: • No beep • One beep • Three beeps To set the Power-up Beep: 1. Scan the SWITCH bar code. 2.
  • Page 139 General Scanner and Scale Features Power-up Beep Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. POWER-UP BEEP = ONE BEEP POWER-UP BEEP = THREE BEEPS 6-23 Product Reference Guide...

  • Page 140: Good Read Beep Control

    Good Read Beep Control This feature enables/disables scanner beep upon successfully decoding of a label. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the two bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 141: Good Read Beep Frequency

    General Scanner and Scale Features Good Read Beep Frequency Adjusts the scanner’s good read beep to sound at low, medium, or high fre- quency (controls the beeper’s pitch/tone). • Low = 660 Hz • Medium = 860 Hz • High = 1050 Hz To set the Good Read Beep Frequency: 1.
  • Page 142 Good Read Beep Frequency — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ BEEP FREQUENCY = MEDIUM GOOD READ BEEP FREQUENCY = HIGH 6-26 ®...

  • Page 143: Good Read Beep Length

    General Scanner and Scale Features Good Read Beep Length Specifies the duration of a good read beep. To set the good read beep length: 1. Scan the SWITCH bar code. 2. Scan the bar code, . You’ll need SET GOOD READ BEEP LENGTH to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 144: Good Read Beep Volume

    Good Read Beep Volume Selects the beeper volume upon a good read beep. There are five selectable volumes, with each volume increment adding approximately five decibels to the previous level: • 0 = Lowest Volume • 1 = Medium-Low Volume •...
  • Page 145 General Scanner and Scale Features Good Read Beep Volume — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ BEEP VOLUME = MEDIUM LOW GOOD READ BEEP VOLUME = MEDIUM 6-29 Product Reference Guide...
  • Page 146 Good Read Beep Volume — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ BEEP VOLUME = MEDIUM HIGH GOOD READ BEEP VOLUME = HIGHEST 6-30 ®...

  • Page 147: Good Read When To Indicate

    General Scanner and Scale Features Good Read When to Indicate This feature specifies when the scanner will provide indication (beep and/ or flash its green LED) upon successfully reading a bar code. • Good Read = Indicate after decode • Good Read = Indicate after transmit •...
  • Page 148 Good Read When to Indicate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ = INDICATE AFTER TRANSMIT GOOD READ = INDICATE AFTER CTS GOES INACTIVE, THEN ACTIVE (RS-232 ONLY) 6-32...

  • Page 149: Scale Enable

    General Scanner and Scale Features Scale Enable Use this feature to enable or disable scale operation. Recalibration/recertification may be required when adding scale functional- ity. Consult your local Weights and Measures authority. If this feature is enabled the scanner will expect that it is to function as a scanner-scale, and will indicate an error if it is not a scale-equipped unit.

  • Page 150: Scale Country Mode

    Scale Country Mode When a weight is presented, the scanner/scale will apply the country-spe- cific weighing rules specified via this feature. Scale Country Mode applies only when a scale is enabled. RS-232 SASI scale interface supports only U.S.A. mode. NOTE SCALE COUNTRY MODE = U.S.A.
  • Page 151 General Scanner and Scale Features Scale Country Mode — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE COUNTRY MODE = AUSTRALIA 6-35 Product Reference Guide...

  • Page 152: Scale Enforced Zero Return

    Scale Enforced Zero Return This feature enables/disables the enforced zero return of the scale. Three settings are available for this feature: • Disable • Scale Must Return to Zero Weight Within Four Minutes — Scale will require re-zeroing if a non-zero weight is left on for more than 4 minutes •...
  • Page 153 General Scanner and Scale Features Scale Enforced Zero Return — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE ENFORCED ZERO RETURN = SCALE MUST RETURN TO ZERO WEIGHT WITHIN 4 MINUTES SCALE ENFORCED ZERO RETURN = SCALE MUST RETURN TO ZERO WEIGHT BETWEEN WEIGHT REQUESTS...

  • Page 154: Scale Interface Type

    Scale Interface Type Use this feature to select the scale interface type. Choices are: • No Scale Interface • RS-232 — SASI • RS-232 — ICL To set the Scale Interface Type: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 155 General Scanner and Scale Features Scale Interface Type — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE INTERFACE TYPE = RS-232 — ICL 6-39 Product Reference Guide...

  • Page 156: Scale Motion Level Filter

    Scale Motion Level Filter In environments where checkstands generate excessive vibration, the scale can be set to filter a certain amount of the motion with regard to its oper- ation. This filter is generally used only in applications where scale error E_1 (too much motion at power-up) has occurred.
  • Page 157 General Scanner and Scale Features Scale Motion Level Filter — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE MOTION LEVEL FILTER = MEDIUM HIGH SCALE MOTION LEVEL FILTER = HIGH 6-41 Product Reference Guide...

  • Page 158: Scale Led Enable

    Scale LED Enable This feature enables/disables Scale LED (Yellow LED) operation. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the two bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 159: Remote Display - Enable/Disable

    General Scanner and Scale Features Remote Display — Enable/Disable The scanner-scale can be configured to operate with or without a Remote Display. Recalibration/recertification may be required when adding a Remote Display. Consult your local Weights and Measures authority. If this feature is enabled the scanner-scale will expect that it is connected to NOTE a Remote Display, and will indicate an error if one is not.

  • Page 160: Aux Port Mode

    (only one option can be active at a time). • Disabled — Port is inactive ® • External Handheld Input — Supports Datalogic handheld scan- ners (QuickScan 1000, QuickScan 6000, PowerScan) as well as ® other models such as the Symbol HotShot. Call your dealer for more information about supported devices.
  • Page 161 General Scanner and Scale Features Aux Port Mode — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. AUX PORT MODE = EXTERNAL HANDHELD INPUT AUX PORT MODE = PIR 6-45 Product Reference Guide...

  • Page 162: Laser Failure Mode

    Laser Failure Mode This configuration item selects whether the scanner should continue oper- ating if only one laser is functional. (The scanner has two lasers: One for the horizontal window, and one for the vertical window.) Options for this feature are: •...

  • Page 163: Productivity Index Reporting (Pir)/Cashier Training (Ct)

    General Scanner and Scale Features Productivity Index Reporting (PIR)/Cashier Training (CT) When PIR/CT is enabled, label quality data is appended to decoded data before being presented to the POS. The PIR feature allows the scanner to provide information to an external computer indicating how easy the label was to read.

  • Page 164: Eas Features

    EAS Features EAS Mode This controls the mode of operation for interfacing with the Sensor- ® matic ScanMax Pro EAS device. Choices are: • Disabled = EAS deactivation turned off. • Coupled Mode = EAS tag is deactivated only upon successful scan- ning of an item’s barcode or via manual push button.
  • Page 165 EAS Features EAS Mode — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAS MODE = DISABLE EAS MODE = COUPLED MODE 6-49 Product Reference Guide...
  • Page 166 EAS Mode — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAS MODE = DECOUPLED MODE EAS MODE = HYBRID MODE 6-50 ®...

  • Page 167: Eas Beep Duration

    EAS Features EAS Beep Duration Sets the duration of the EAS successful deactivation beep, specified in 10ms increments. The beep only occurs if EAS mode is not disabled. To set the EAS Beep Duration: 1. Scan the SWITCH bar code. 2.

  • Page 168: Eas Retry Count

    EAS Retry Count This feature sets the number of times the deactivation sequence (defined by the feature, “EAS Deactivation Duration — Retry ”) is restarted after a failed deactivation attempt. To set the EAS Retry Count: 1. Scan the SWITCH bar code. 2.

  • Page 169: Manual Eas Deactivation Push Button

    EAS Features Manual EAS Deactivation Push Button This feature is for use in Coupled Mode . When it is enabled, EAS deacti- vation can be manually initiated by placing the item with the EAS tag downstream of the horizontal scan window and pushing the Manual EAS Deactivation Push Button.
  • Page 170 Manual EAS Deactivation Push Button — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. To set this feature: 1. Scan the SWITCH bar code. 2.
  • Page 171 EAS Features Manual EAS Deactivation Push Button — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. MANUAL EAS DEACTIVATON PUSH BUTTON = ENABLE ONLY WHEN SCANNER ENABLED 6-55 Product Reference Guide...

  • Page 172: Eas Deactivation Duration - Coupled

    EAS Deactivation Duration — Coupled Specifies the amount of time EAS deactivation is operative once the func- tion has been initiated following a bar code read. This setting pertains only to units configured for EAS Coupled Mode. Refer- ence the EAS Mode description for more information about Coupled and Decoupled EAS operation.

  • Page 173: Eas Deactivation Duration - Retry

    EAS Features EAS Deactivation Duration — Retry Specifies the amount of time EAS deactivation is operative once the func- tion has been initiated following EAS tag detection (prior to bar code read).. This setting pertains only to units configured for EAS Coupled Mode. Refer- ence the “EAS Mode ”...

  • Page 174: Eas Deactivation Duration - Manual

    EAS Deactivation Duration — Manual Specifies the amount of time EAS deactivation is operative upon pushing the Manual EAS Deactivation Push Button. This setting pertains only to units configured for EAS Coupled Mode. Refer- ence the “EAS Mode ” description for more information about Coupled and Decoupled EAS operation.

  • Page 175: Interface Related Features

    Interface Related Features Interface Related Features Interface Type Specifies the current scanner interface. Selections are: INTERFACE TYPE INTERFACE IDENTIFICATION NUMBER RS-232 Standard RS-232 Wincor-Nixdorf RS-232 Single Cable IBM USB Port 17 NOT USER-SELECTABLE Indicated by 7-segment FRU display flashing Null Interface 0 at start-up a.
  • Page 176 Interface Type — continued To select the desired interface: Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED.
  • Page 177 Interface Related Features RS-232 Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
  • Page 178 RS-232 Wincor-Nixdorf Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
  • Page 179 Interface Related Features RS-232 Single Cable Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.

  • Page 180: Ibm Port 17 Interface Selection

    IBM Port 17 Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.

  • Page 181: Ibm Usb Interface Selection

    Interface Related Features IBM USB Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.

  • Page 182: Maximum Host-Transmitted Message Length

    Maximum Host-Transmitted Message Length Specifies the maximum number of data characters allowed in messages transmitted to the host. To set the Maximum Host-Transmitted Message Length: 1. Scan the SWITCH bar code. 2. Scan the bar code, SET MAXIMUM HOST-TRANSMITTED MES- below.

  • Page 183: Number Of Host Transmission Buffers

    Interface Related Features Number of Host Transmission Buffers Specifies the number of host transmission(s) that may be buffered. By buffering data from a bar code, the scanner can continue to read a new bar code while the old one is being transmitted to the host. Selecting BUFF- ERS = 1 means that the first bar code must be transmitted before a new one can be read.

  • Page 184: Global Prefix

    Global Prefix This feature applies to RS-232 interfaces (Standard, Wincor-Nixdorf, and Single Cable). It specifies the prefix that is added to beginning of label transmission. To specify the Global Prefix Character(s): 1. Scan the SWITCH bar code. 2. Scan the bar code, below.
  • Page 185 Interface Related Features Global Prefix — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SET GLOBAL PREFIX TERMINATE SEQUENCE 6-69 Product Reference Guide...

  • Page 186: Global Suffix

    Global Suffix This feature applies to RS-232 interfaces (Standard, Wincor-Nixdorf, and Single Cable). It specifies the suffix that is added to end of a label trans- mission. Three standard options are available below. Contact your dealer for other alternate settings for this feature. •...
  • Page 187 Interface Related Features Global Suffix — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GLOBAL SUFFIX = CR GLOBAL SUFFIX = CR LF 6-71 Product Reference Guide...

  • Page 188: Ibm Features

    IBM Features IBM Interface Options IBM interfaces offer specific control over interaction with certain devices. The IBM USB interface provides its own set of options. Refer to the feature, IBM USB Interface Options, in this chapter. NOTE Options for this feature are as follows: •...

  • Page 189: Ibm Scale Address

    IBM Features IBM Scale Address This feature applies to IBM Port 17 ONLY. NOTE Specifies IBM scale address for IBM Port 17. The following three addresses are available: • • • To set the IBM Scale Address: 1. Scan the SWITCH bar code. 2.
  • Page 190 IBM Scale Address — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. IBM SCALE ADDRESS = 6B IBM SCALE ADDRESS = 6E 6-74 ®...

  • Page 191: Ibm Transmit Labels In Code 39 Format

    IBM Features IBM Transmit Labels in Code 39 Format This feature enables/disables scanner's ability to set a symbology identifier for a specified label to Code 39 before transmitting that label data to an IBM host. This applies to: Code 128, Code 93 and Codabar for IBM Port 5B;...

  • Page 192: Ibm Usb Interface Options

    IBM USB Interface Options The IBM-USB interface offers specific control over interaction with cer- tain devices. Options for this feature are as follows: • FULL host interface support — Accepts scanner and scale config- uration host commands. • Compatible with Magellan SL host interface support — Uses Magellan SL host interface support.
  • Page 193 IBM Features IBM USB Interface Options — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. IBM USB INTERFACE OPTION = COMPATIBLE W/MAGELLAN SL HOST I/F SUP- PORT IBM USB INTERFACE OPTION = IGNORE HOST I/F CONFIG OF SCANNER &...

  • Page 194: Ibm Usb Scanner Device Type

    IBM USB Scanner Device Type The IBM-USB protocol allows for the scanner to be identified as one of two different types of barcode scanners. Depending on what other scan- ners you may already have connected to a USB POS, you may need to change this setting to enable all scanners to communicate.

  • Page 195: Features

    RS-232 Features RS-232 Features RS-232 Baud Rate This feature selects the baud rate required for sending and receiving data. Single cable interfaces are limited to Baud Rate selections up to 19200. They cannot communicate at Baud Rates of 38400 and up. NOTE To specify the RS-232 Baud Rate: 1.
  • Page 196 RS-232 Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 4800 RS-232 BAUD RATE = 9600 6-80 ®...
  • Page 197 RS-232 Features RS-232 Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 19200 RS-232 BAUD RATE = 38400 6-81 Product Reference Guide...
  • Page 198 RS-232 Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 57600 RS-232 BAUD RATE = 115200 6-82 ®...

  • Page 199: Number Of Data Bits

    RS-232 Features RS-232 Number of Data Bits Specifies number of data bits required for sending and receiving data. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below representing the desired Data Bit setting. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 200: Number Of Stop Bits

    RS-232 Number of Stop Bits Specifies number of stop bits required for sending and receiving data. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below representing the desired Stop Bit setting. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 201: Parity

    RS-232 Features RS-232 Parity Specifies parity required for sending and receiving data. Options for this setting are: • RS-232 PARITY = NONE • RS-232 PARITY = EVEN • RS-232 PARITY = ODD To set this feature: 1. Scan the SWITCH bar code. 2.
  • Page 202 RS-232 Parity — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 PARITY = EVEN RS-232 PARITY = ODD 6-86 ®...

  • Page 203: Hardware Control

    RS-232 Features RS-232 Hardware Control Enables/disables use of the RS-232 CTS signal for flow control and/or scan control. Options are: • Disable — The scanner transmits to the host regardless of any activ- ity on the CTS line. • Enable CTS Flow Control — The CTS signal controls transmission of data to the host.
  • Page 204 RS-232 Hardware Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 HARDWARE CONTROL = ENABLE CTS FLOW CONTROL RS-232 HARDWARE CONTROL = ENABLE CTS SCAN CONTROL 6-88 ®...

  • Page 205: Intercharacter Delay

    RS-232 Features RS-232 Intercharacter Delay Specifies delay between the end of one character and the beginning of the next in 10-millisecond increments. To set the RS-232 Intercharacter Delay: 1. Scan the SWITCH bar code. 2. Scan the bar code below, SET RS-232 INTERCHARACTER DELAY You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend...

  • Page 206: Software Flow Control

    RS-232 Software Flow Control Enables/disables RS-232 Flow Control using XON/ XOFF characters. . This item will be ignored when the feature, RS-232 NAK Character, is enabled NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 207: Host Echo

    RS-232 Features RS-232 Host Echo When enabled, this feature passes all data through the scanner to the host as it comes in. This feature is used for applications where “daisy chaining” of RS-232 devices onto the same cable is necessary. If, for example, one of the devices in the chain is a terminal where someone is entering data while another person is simultaneously scanning a bar code requiring transmis- sion to the host, the scanner will wait for the RS-232 channel to be quiet...

  • Page 208: Host Echo Quiet Interval

    RS-232 Host Echo Quiet Interval This setting specifies the time interval of RS-232 channel inactivity which must transpire before the scanner will break the host echo loop to transmit the bar code data that has just been scanned to the host. •...

  • Page 209: Ignore Host Commands

    RS-232 Features RS-232 Ignore Host Commands When set to ignore host commands, the scanner will ignore all host com- mands except for the minimum set necessary to keep the interface active, transmit labels, and transmit scale information. For normal operation of the interface, disable this feature.

  • Page 210: Ttl

    RS-232 TTL Specifies whether RS-232 interface provides TTL levels on the output pins TxD and RTS. Choices are: • Normal RS-232 levels • TTL levels To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below which represents the desired setting for this feature.

  • Page 211: Ttl Invert

    RS-232 Features RS-232 TTL Invert Enables/disables inversion of TTL. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below which represents the desired setting for this feature. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 212: Beep On Ascii Bel

    RS-232 Beep on ASCII BEL Enables/disables ability of scanner to beep (sound a good read tone) on receiving an ASCII BEL (07 hex). • Disable • Enable To enable/disable this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 213: Beep After Weigh

    RS-232 Features RS-232 Beep After Weigh Enables/disables the ability of the scanner to beep after weight data is transmitted to the host. Scale interfaces that support this item are: RS-232 ICL, RS-232 SASI, and RS-232 Single Cable. To enable/disable the Beep After Weigh feature: 1.

  • Page 214: Beep On Not On File

    RS-232 Beep on Not on File Select for the host to beep (or not) when a not-on-file condition is detected by the host. This feature is also applicable to single cable RS-232. RS-232 BEEP ON NOT ON FILE = DISABLE RS-232 BEEP ON NOT ON FILE = ENABLE 6-98 ®...

  • Page 215: Ack Nak Enable

    RS-232 Features RS-232 ACK NAK Enable This enables/disables the ability of the scanner to support the RS-232 ACK/NAK protocol. When configured, the scanner and/or host sends an “ACK” when it receives data properly, and sends “NAK” when the data is in error.
  • Page 216 RS-232 ACK NAK Enable — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 ACK/NAK = HOST ACKNOWLEDGEMENT RS-232 ACK/NAK = LABEL & HOST 6-100 ®...

  • Page 217: Ack Character

    RS-232 Features RS-232 ACK Character This feature specifies which ASCII character will be used as an ACK char- acter. DO NOT set this feature to use previously defined characters such as XON, XOFF or host commands as this will conflict with normal operation of these characters.

  • Page 218: Nak Character

    RS-232 NAK Character This feature specifies which ASCII character will be used as a NAK char- acter. DO NOT set this feature to use previously defined characters such as XON, XOFF or host commands as this will conflict with normal operation of these characters.

  • Page 219: Retry On Ack Nak Timeout

    RS-232 Features RS-232 Retry on ACK NAK Timeout This option specifies the action scanner performs on expiration of the 232 ACK NAK Timeout Value To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 220: Ack Nak Timeout Value

    RS-232 ACK NAK Timeout Value This item specifies the time the scanner will wait for an ACK character from the host following a label transmission. • 0 = Infinite timeout • 1 - 75 = Timeout in 200-millisecond increments To set the ACK NAK Timeout Value: 1.

  • Page 221: Ack Nak Retry Count

    RS-232 Features RS-232 ACK NAK Retry Count This feature sets the number of times for the scanner to retry a label trans- mission under a retry condition. To set the RS-232 ACK NAK Retry Count: 1. Scan the SWITCH bar code. 2.

  • Page 222: Ack Nak Error Handling

    RS-232 ACK NAK Error Handling This item specifies the method the scanner will use to handle errors detected while waiting to receive the ACK character from the host. Errors include unrecognized host commands and communication errors such as parity or framing errors. •...
  • Page 223 RS-232 Features RS-232 ACK NAK Error Handling — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 ACK NAK ERROR HANDLING = ASSUME ACK RS-232 ACK NAK ERROR HANDLING = ASSUME NAK 6-107 Product Reference Guide...

  • Page 224: Label Id Control

    RS-232 Label ID Control This feature specifies whether or not Label IDs are transmitted to the host and if so, whether to attach them as a prefix or suffix. RS-232 LABEL ID CONTROL = DISABLE RS-232 LABEL ID CONTROL = ENABLE AS PREFIX 6-108 ®...
  • Page 225 RS-232 Features RS-232 Label ID Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 LABEL ID CONTROL = ENABLE AS SUFFIX 6-109 Product Reference Guide...
  • Page 226 Single Cable RS-232 Options The RS-232 Single Cable interface shares some configuration options with other RS-232 interfaces. Rather than repeat them in this chapter as Single Cable options, please find them referenced as follows: • RS-232 Baud Rate on page 79 •...

  • Page 227: Single Cable Rs-232 Options

    Single Cable RS-232 Options Single Cable RS-232 Scanner Only Protocol This sets the type of interface protocol that will be used in Single Cable RS-232. Options are: • Scanner/scale RS-232 protocol • Scanner only RS-232 protocol To set this feature: 1.

  • Page 228: Single Cable Rs-232 Rts Cts Selection

    Single Cable RS-232 RTS CTS Selection Specifies how RTS and CTS are used to control the data flow. RTS is con- trolled by the Scanner and can be continuously held high/low, or can be asserted during label transmission. The scanner looks at CTS, as the con- figuration values state, to determine when to send label data.
  • Page 229 Single Cable RS-232 Options Single Cable RS-232 RTS CTS Selection — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RTS CTS SELECTION = OPTION 2 RTS CTS SELECTION = OPTION 3 6-113 Product Reference Guide...
  • Page 230 Single Cable RS-232 RTS CTS Selection — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RTS CTS SELECTION = OPTION 4 RTS CTS SELECTION = OPTION 5 6-114 ®...

  • Page 231: Single Cable Rs-232 Use Bcc

    Single Cable RS-232 Options Single Cable RS-232 Use BCC Enables/disables the ability of the scanner to use BCC. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 232: Single Cable Rs-232 Use Ack/Nak

    Single Cable RS-232 Use ACK/NAK Enables/disables the ability of the scanner to use ACK/NAK. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 233: Single Cable Rs-232 Use Stx

    Single Cable RS-232 Options Single Cable RS-232 Use STX Enables/disables the ability of the scanner to use STX. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 234: Set Single Cable Rs-232 Stx Character

    Set Single Cable RS-232 STX Character This feature selects the STX character. To specify the STX Character: 1. Scan the SWITCH bar code. 2. Scan the bar code, SET SINGLE CABLE RS-232 STX CHARACTER below. You’ll need to cover any unused bar codes on this and the fac- ing page to ensure the scanner reads only the bar code you intend to scan.

  • Page 235: Single Cable Rs-232 Use Etx

    Single Cable RS-232 Options Single Cable RS-232 Use ETX Enables/disables the ability of the scanner to use ETX. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 236: Set Single Cable Rs-232 Etx Character

    Set Single Cable RS-232 ETX Character Allows selection of the ETX character. To specify the ETX Character: 1. Scan the SWITCH bar code. 2. Scan the bar code, SET SINGLE CABLE RS-232 ETX CHARACTER below. You’ll need to cover any unused bar codes on this and the fac- ing page to ensure the scanner reads only the bar code you intend to scan.

  • Page 237: Symbology Programming

    Symbology Programming Symbology Programming If the scanner’s interface type must be changed, always be sure that inter- face configuration is the FIRST item scanned during a programming ses- sion. (Selecting an interface type resets ALL other configuration items — including symbology programming — to the factory default for that inter- NOTE face type.) UPC-A Enable...

  • Page 238: Upc-A Number System Character Transmission

    UPC-A Number System Character Transmission Enables/disables transmission of a UPC-A number system character. This feature MUST be enabled for IBM interfaces for proper function. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1.

  • Page 239: Upc-A Check Character Transmission

    UPC-A Enable UPC-A Check Character Transmission Enables/disables transmission of a UPC-A check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 240: Expand Upc-A To Ean-13

    Expand UPC-A to EAN-13 Enables/disables expansion of UPC-A labels to EAN/JAN-13. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 241: Upc/Ean Aim Id

    UPC-A Enable UPC/EAN AIM ID This feature enables/disables transmission of the UPC/EAN AIM symbol- ogy identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 242: Upc-A Label Id

    UPC-A Label ID This feature specifies a UPC-A label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 243: Upc-A 2-Digit Supplemental Label Id

    UPC-A Enable UPC-A 2-Digit Supplemental Label ID This feature specifies a UPC-A 2-Digit Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 244: Upc-A 5-Digit Supplemental Label Id

    UPC-A 5-Digit Supplemental Label ID This feature specifies a UPC-A 5-Digit Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 245: Upc-A 128 Supplemental Label Id

    UPC-A Enable UPC-A 128 Supplemental Label ID This feature specifies a UPC-A 128 Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 246: Upc-E Enable

    UPC-E Enable Enables/disables the ability of the scanner to decode UPC-E labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 247: Upc-E Number System Character Transmission

    UPC-E Enable UPC-E Number System Character Transmission Enables/disables transmission of a UPC-E number system character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 248: Upc-E Check Character Transmission

    UPC-E Check Character Transmission Enables/disables transmission of a UPC-E check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 249: Expand Upc-E To Upc-A

    UPC-E Enable Expand UPC-E to UPC-A Enables/disables expansion of UPC-E labels to UPC-A. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 250: Expand Upc-E To Ean-13

    Expand UPC-E to EAN-13 Enables/disables expansion of UPC-E labels to EAN/JAN-13. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 251: Upc-E Label Id

    UPC-E Enable UPC-E Label ID This feature specifies a UPC-E label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 252: Upc-E 2-Digit Supplemental Label Id

    UPC-E 2-Digit Supplemental Label ID This feature specifies a UPC-E 2-Digit Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 253: Upc-E 5-Digit Supplemental Label Id

    UPC-E Enable UPC-E 5-Digit Supplemental Label ID This feature specifies a UPC-E 5-Digit Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 254: Upc-E 128 Supplemental Label Id

    UPC-E 128 Supplemental Label ID This feature specifies a UPC-E 128 Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 255: Enable

    EAN-13 Enable EAN-13 Enable Enables/disables the ability of the scanner to decode EAN/JAN-13 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 256: First Character Transmission

    EAN-13 First Character Transmission Enables/disables transmission of EAN/JAN-13 first character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 257: Check Character Transmission

    EAN-13 Enable EAN-13 Check Character Transmission Enables/disables transmission of an EAN/JAN-13 check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 258: Isbn Conversion Enable

    EAN-13 ISBN Conversion Enable Enables/disables conversion of EAN/JAN-13 labels starting with 978 to Bookland ISBN labels. If any add-on information is present on the label prior to the conversion to ISBN, the add-on data will be discarded. Only the base label will be con- verted.

  • Page 259: Ean 13 Label Id

    EAN-13 Enable EAN 13 Label ID This feature specifies an EAN 13 label ID to be added to bar code data. To set this feature: The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 260: 2-Digit Supplemental Label Id

    EAN-13 2-Digit Supplemental Label ID This feature specifies an EAN-13 2-Digit Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 261: 5-Digit Supplemental Label Id

    EAN-13 Enable EAN-13 5-Digit Supplemental Label ID This feature specifies an EAN-13 5-Digit Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 262: 128 Supplemental Label Id

    EAN-13 128 Supplemental Label ID This feature specifies an EAN-13 128 Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 263: Bookland Aim Id

    EAN-13 Enable Bookland AIM ID This feature enables/disables transmission of the Bookland AIM symbol- ogy identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 264: Bookland Label Id

    Bookland Label ID This feature specifies a Bookland label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 265: Enable

    EAN-8 Enable EAN-8 Enable Enables/disables the ability of the scanner to decode EAN/JAN-8 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 266: Check Character Transmission

    EAN-8 Check Character Transmission Enables/disables transmission of an EAN/JAN-8 check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 267: Expand Ean-8 To Ean-13

    EAN-8 Enable Expand EAN-8 to EAN-13 Enables/disables expansion of EAN/JAN-8 labels to EAN/JAN-13. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 268: Ean 8 Label Id

    EAN 8 Label ID This feature specifies an EAN 8 label ID to be added to bar code data. To set this feature: The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 269: 2-Digit Supplemental Label Id

    EAN-8 Enable EAN-8 2-Digit Supplemental Label ID This feature specifies an EAN-8 2-Digit Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 270: 5-Digit Supplemental Label Id

    EAN-8 5-Digit Supplemental Label ID This feature specifies an EAN-8 5-Digit Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 271: 128 Supplemental Label Id

    EAN-8 Enable EAN-8 128 Supplemental Label ID This feature specifies an EAN-8 128 Supplemental label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 272: Decoding Levels

    EAN-8 Decoding Levels Decoding levels allow the decoder to be set to perform at one of four selectable levels: • Very Conservative — Slower scan time, virtually eleminates mis- reads. The most secure setting. • Slightly More Aggressive — Faster scanning, more aggressive, yet minimizes misreads.
  • Page 273 EAN-8 Enable EAN-8 Decoding Levels — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 DECODING LEVELS = VERY CONSERVATIVE EAN-8 DECODING LEVELS = SLIGHTLY MORE AGGRESSIVE 6-157 Product Reference Guide...
  • Page 274 EAN-8 Decoding Levels — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 DECODING LEVELS = MODERATELY AGGRESSIVE EAN-8 DECODING LEVELS = VERY AGGRESSIVE 6-158 ®...

  • Page 275: Other Upc/Ean Options

    Other UPC/EAN Options Other UPC/EAN Options The following pages contain other selectable features for UPC/EAN sym- bologies: • UPC/EAN Reconstruction • Price Weight Check • Enable EAN Two Label • Addons • UPC-A and EAN-13 Decoding Levels 6-159 Product Reference Guide...

  • Page 276: Upc/Ean Reconstruction

    UPC/EAN Reconstruction Enables/disables the ability of the scanner to decode a class of UPC/EAN labels with voids. The label voids may be caused by printing defects or physical damage. This feature may be helpful in environments with in- store printed labels. Enabling this feature increases the potential of misreads.

  • Page 277: Price Weight Check

    Other UPC/EAN Options Price Weight Check Enables/disables calculation and verification of price/weight check digits. Applies to all UPC-A and EAN/JAN-13 labels with eligible Number Sys- tem/First Character digits. Options are: • Disable • 4-digit price/weight • 5-digit price/weight • 4-digit European price/weight •...
  • Page 278 Price Weight Check — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. PRICE WEIGHT CHECK = 4-DIGIT PRICE/WEIGHT PRICE WEIGHT CHECK = 5-DIGIT PRICE/WEIGHT 6-162 ®...
  • Page 279 Other UPC/EAN Options Price Weight Check — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. PRICE WEIGHT CHECK = 4-DIGIT EUROPEAN PRICE/WEIGHT PRICE WEIGHT CHECK = 5-DIGIT EUROPEAN PRICE/WEIGHT 6-163 Product Reference Guide...

  • Page 280: Enable Ean Two Label

    Enable EAN Two Label Enables/disables the ability of the scanner to decode EAN two-label pairs. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 281: Addons

    Other UPC/EAN Options Addons The scanner is capable of processing different types of addon codes, including: • 2-Digit Supplemental • 5-Digit Supplemental Options are provided on the following pages for your convenience: • Disable all addons — The scanner will not look for or read addons. •...
  • Page 282 Addons — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. ADDONS = OPTIONAL 2-DIGIT AND 5-DIGIT SUPPLEMENTAL 6-166 ® Magellan 9500...

  • Page 283: Upc-A And Ean-13 Decoding Levels

    Other UPC/EAN Options UPC-A and EAN-13 Decoding Levels Decoding levels allow the decoder to be set to perform at one of four selectable levels: • Very Conservative — Slower scan time, virtually eleminates mis- reads. The most secure setting. • Slightly More Aggressive —...
  • Page 284 UPC-A and EAN-13 Decoding Levels — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC-A/EAN-13 DECODING LEVELS = VERY CONSERVATIVE UPC-A/EAN-13 DECODING LEVELS = SLIGHTLY MORE AGGRESSIVE 6-168 ®...
  • Page 285 Other UPC/EAN Options UPC-A and EAN-13 Decoding Levels — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC-A/EAN-13 DECODING LEVELS = MODERATELY AGGRESSIVE UPC-A/EAN-13 DECODING LEVELS = VERY AGGRESSIVE 6-169 Product Reference Guide...

  • Page 286: Gtin Enable

    GTIN Enable Enables/Disables the ability to convert UPCE, UPCA, EAN8, and EAN13 labels into the GTIN 14-character format. If add-on information is present on the base label prior to the conversion taking place, the add-on information will be appended to the converted GTIN bar code.

  • Page 287: Gtin Label Id

    GTIN Enable GTIN Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 288: Gtin 2-Digit Supplemental Label Id

    GTIN 2-Digit Supplemental Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled and 2-digit supplemental addon bar code labels are converted. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.

  • Page 289: Gtin 5-Digit Supplemental Label Id

    GTIN Enable GTIN 5-Digit Supplemental Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled and 5-digit supplemental addon bar code labels are converted. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.

  • Page 290: Gtin Code 128 Supplemental Label Id

    GTIN Code 128 Supplemental Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled and Code 128 supplemental addon bar code labels are converted The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.

  • Page 291: Enable

    RSS-14 Enable RSS-14 Enable Enables/disables the ability of the scanner to decode RSS-14 labels. This value-added feature is a factory-programmed option. Contact your dealer for information about upgrading your system to include this advanced capability. NOTE To set this feature: 1.

  • Page 292: Check Character Transmission

    RSS-14 Check Character Transmission Enables/disables transmission of the RSS-14 check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 293: Rss-14/Ean-128 Emulation

    RSS-14 Enable RSS-14/EAN-128 Emulation Enables/disables the ability of RSS-14 to be transmitted as EAN-128. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 294: Component Enable

    RSS-14 2D Component Enable When this feature is enabled, and the software reads an RSS-14 bar code that has a 2D component associated with it, the RSS-14 bar code will not be reported to the terminal. To set this feature: 1.

  • Page 295: Aim Id

    RSS-14 Enable RSS-14 AIM ID This feature enables/disables transmission of the RSS-14 AIM symbology identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 296: Label Id

    RSS-14 Label ID This feature specifies an RSS-14 label ID to be added to bar code data. To set this feature: The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 297: Rss Expanded Enable

    RSS Expanded Enable RSS Expanded Enable Enables/disables the ability of the scanner to decode RSS-Expanded labels. This value-added feature is a factory-programmed option. Contact your dealer for information about upgrading your system to include this advanced capability. NOTE To set this feature: 1.

  • Page 298: Rss Expanded Ean-128 Emulation

    RSS Expanded EAN-128 Emulation Enables/disables EAN-128 emulation for RSS Expanded. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 299: Rss Expanded 2D Component Enable

    RSS Expanded Enable RSS Expanded 2D Component Enable When this feature is enabled, and the software reads an RSS Expanded bar code that has a 2D component associated with it, the RSS Expanded bar code will not be reported to the terminal. To set this feature: 1.

  • Page 300: Rss Expanded Aim Id

    RSS Expanded AIM ID This feature enables/disables transmission of the RSS Expanded AIM symbology identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 301: Rss Expanded Label Id

    RSS Expanded Enable RSS Expanded Label ID This feature specifies an RSS Expanded label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 302: Rss Expanded Length Control

    RSS Expanded Length Control This feature specifies either variable-length or fixed-length decoding for RSS Expanded. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 303: Rss Expanded Maximum Label Length

    RSS Expanded Enable RSS Expanded Maximum Label Length This feature specifies the maximum allowable length of an RSS Expanded label. Length in this case includes check and data characters. This applies when RSS Expanded Length Control is set to variable-length decoding. Maximum Label Length should be greater than or equal to Minimum Label NOTE Length.

  • Page 304: Rss Expanded Minimum Label Length

    RSS Expanded Minimum Label Length This feature specifies the minimum allowable length of an RSS Expanded label. Length in this case includes check and data characters. This applies when RSS Expanded Length Control is set to variable-length decoding. Minimum Label Length should be less than or equal to Maximum Label NOTE Length.

  • Page 305: Rss Expanded Fixed Length 1

    RSS Expanded Enable RSS Expanded Fixed Length 1 This feature specifies RSS Expanded first fixed length. This applies when RSS Expanded Length Control is set to fixed-length decoding. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code, below.

  • Page 306: Rss Expanded Fixed Length 2

    RSS Expanded Fixed Length 2 This feature specifies RSS Expanded second fixed length. This applies when RSS Expanded Length Control is set to fixed-length decoding. If Fixed Length 2 is set to 00 (zero), then Fixed Length 1 will apply. NOTE To set this feature: 1.

  • Page 307: Code 39 Enable

    Code 39 Enable Code 39 Enable Enables/disables the ability of the scanner to decode Code 39 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 308: Code 39 Start Stop Character Transmission

    Code 39 Start Stop Character Transmission Enables/disables transmission of Code 39 start and stop characters. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 309: Code 39 Check Character Calculation

    Code 39 Enable Code 39 Check Character Calculation Enables/disables calculation and verification of an optional Code 39 check character. When disabled, any check character in label is treated as a data character. If check calculation is disabled, the risk is increased that a misread can occur.

  • Page 310: Code 39 Check Character Transmission

    Code 39 Check Character Transmission Enables/disables transmission of optional Code 39 check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 311: Code 39 Full Ascii

    Code 39 Enable Code 39 Full ASCII Enables/disables the ability of the scanner to translate to Code 39 full ASCII labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 312: Code 39 Aim Id

    Code 39 AIM ID This feature enables/disables transmission of the Code 39 AIM symbology identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 313: Code 39 Label Id

    Code 39 Enable Code 39 Label ID This feature specifies a Code 39 label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 314: Code 39 Length Control

    Code 39 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 39. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 315: Code 39 Maximum Label Length

    Code 39 Enable Code 39 Maximum Label Length This feature specifies the maximum allowable length of a Code 39 label. Length in this case includes check, data and ASCII characters, but does not include start, or stop characters. This feature applies when Code 39 Length Control is set to variable-length decoding.

  • Page 316: Code 39 Minimum Label Length

    Code 39 Minimum Label Length This feature specifies the minimum allowable length of a Code 39 label. Length in this case includes check, data and ASCII characters, but does not include start, or stop characters. This feature applies when Code 39 Length Control is set to variable-length decoding.

  • Page 317: Code 39 Fixed Length 1

    Code 39 Enable Code 39 Fixed Length 1 This feature specifies Code 39 first fixed length. This applies when Code 39 Length Control is set to fixed-length decoding. The minimum decodable length is four when an optional check character is present.

  • Page 318: Code 39 Fixed Length 2

    Code 39 Fixed Length 2 This feature specifies Code 39 second fixed length. This applies when Code 39 Length Control is set to fixed-length decoding. If Fixed Length 2 is set to 00, then Fixed Length 1 will apply NOTE To set this feature: 1.

  • Page 319: Code 39 Stitching

    Code 39 Enable Code 39 Stitching Enables/disables stitching for Code 39 labels. When parts of a Code 39 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.

  • Page 320: Pharmacode 39 Enable

    Pharmacode 39 Enable Enables/disables the ability of the scanner to decode Italian Pharmacode 39 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 321: Pharmacode 39 Start Stop Character Transmission

    Pharmacode 39 Enable Pharmacode 39 Start Stop Character Transmission Enables/ disables transmission of start and stop characters for Pharmacode This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2.

  • Page 322: Pharmacode 39 Check Character Transmission

    Pharmacode 39 Check Character Transmission Enables/disables transmission of Pharmacode 39 check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 323: Pharmacode 39 Label Id

    Pharmacode 39 Enable Pharmacode 39 Label ID This feature specifies a Pharmacode 39 label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 324: Code 128 Enable

    Code 128 Enable Enables/disables the ability of the scanner to decode Code 128 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 325: Code 128 Transmit Function Characters

    Code 128 Enable Code 128 Transmit Function Characters Enables/disables transmission of Code 128 function characters 1, 2, 3, and 4. Disabled is the recommended setting for all interfaces. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 326: Convert Code 128 To Code 39

    Convert Code 128 to Code 39 Enables/disables conversion of Code 128 labels to Code 39. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 327: Code 128 Aim Id

    Code 128 Enable Code 128 AIM ID This feature enables/disables transmission of the Code 128 AIM symbol- ogy identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 328: Code 128 Label Id

    Code 128 Label ID This feature specifies a Code 128 label ID to be added to bar code data.. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 329: Code 128 Length Control

    Code 128 Enable Code 128 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 128. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 330: Code 128 Maximum Label Length

    Code 128 Maximum Label Length This feature specifies the maximum allowable length of a Code 128 label. Length in this case includes function characteres and data characters, but does not include function code change or check character. This feature applies when Code 128 Length Control is set to variable-length decoding. Maximum label length should be greater than or equal to minimum label NOTE length.

  • Page 331: Code 128 Minimum Label Length

    Code 128 Enable Code 128 Minimum Label Length This feature specifies the minimum allowable length of a Code 128 label. Length in this case includes function characteres and data characters, but does not include function code change or check character. This feature applies when Code 128 Length Control is set to variable-length decoding.

  • Page 332: Code 128 Fixed Length 1

    Code 128 Fixed Length 1 This feature specifies Code 128 first fixed length. This applies when Code 128 Length Control is set to fixed-length decoding. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code, below.

  • Page 333: Code 128 Fixed Length 2

    Code 128 Enable Code 128 Fixed Length 2 This feature specifies Code 128 second fixed length. This applies when Code 128 Length Control is set to fixed-length decoding. If Fixed Length 2 is set to 00 (zero), then Fixed Length 1 will apply. NOTE To set this feature: 1.

  • Page 334: Code 128 Stitching

    Code 128 Stitching Enables/disables stitching for Code 128 labels. When parts of a Code 128 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.

  • Page 335: Enable

    EAN-128 Enable EAN-128 Enable Enables/disables the ability of the scanner to decode EAN-128 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 336: Aim Id

    EAN-128 AIM ID This feature enables/disables transmission of the EAN-128 AIM symbol- ogy identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 337: Label Id

    EAN-128 Enable EAN-128 Label ID This feature specifies an EAN-128 label ID to be added to bar code data.. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 338: Interleaved 2 Of 5 (I 2 Of 5) Enable

    Interleaved 2 of 5 (I 2 of 5) Enable Enables/disables the ability of the scanner to decode Interleaved 2 of 5 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 339: I 2 Of 5 Check Character Calculation

    Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Check Character Calculation Enables/disables calculation and verification of an optional Interleaved 2 of 5 check character. If check character calculation is disabled, the risk is increased that a misread can occur.

  • Page 340: I 2 Of 5 Check Character Transmission

    I 2 of 5 Check Character Transmission Enables/disables transmission of an optional Interleaved 2 of 5 check char- acter. This feature applies only when I 2 of 5 Check Character Calculation is enabled. This item is ignored when the advanced feature, Full Label Edit, is enabled.

  • Page 341: I 2 Of 5 Aim Id

    Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 AIM ID This feature enables/disables transmission of the I 2 of 5 AIM symbology identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 342: I 2 Of 5 Label Id

    I 2 of 5 Label ID This feature specifies an I 2 of 5 label ID to be added to bar code data.. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 343: I 2 Of 5 Length Control

    Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for I 2 of 5. To set this feature: 1. Scan the SWITCH bar code. 2.

  • Page 344: I 2 Of 5 Maximum Label Length

    I 2 of 5 Maximum Label Length This feature specifies the maximum allowable length of an I 2 of 5 label. Length in this case includes check and data characters, but does not include start or stop characters. This feature applies when I 2 of 5 Length Control is set to variable-length decoding.

  • Page 345: I 2 Of 5 Minimum Label Length

    Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Minimum Label Length This feature specifies the minimum allowable length of an I 2 of 5 label. Length in this case includes check and data characters, but does not include start or stop characters.

  • Page 346: I 2 Of 5 Fixed Length 1

    I 2 of 5 Fixed Length 1 This feature specifies I 2 of 5 first fixed length. This applies when I 2 of 5 Length Control is set to fixed-length decoding. NOTE To set this feature: 1. Scan the SWITCH bar code. 2.

  • Page 347: I 2 Of 5 Fixed Length 2

    Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Fixed Length 2 This feature specifies I 2 of 5 second fixed length. This applies when I 2 of 5 Length Control is set to fixed-length decoding. If Fixed Length 2 is set to 00 (zero), then Fixed Length 1 will apply.

  • Page 348: I 2 Of 5 Stitching

    I 2 of 5 Stitching Enables/disables stitching for I 2 of 5 labels. When parts of an I 2 of 5 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.

  • Page 349: Codabar Enable

    Codabar Enable Codabar Enable Enables/disables the ability of the scanner to decode Codabar labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 350: Codabar Start Stop Character Transmission

    Codabar Start Stop Character Transmission Enables/disables transmission of Codabar start and stop characters. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 351: Codabar Start Stop Character Set

    Codabar Enable Codabar Start Stop Character Set This feature selects the format of transmitted Codabar start/stop charac- ters. Options are: • ABCD/TN* E • ABCD/ABCD • abcd/tn* e • abcd/abcd To set this feature: 1. Scan the SWITCH bar code. 2.
  • Page 352 Codabar Start Stop Character Set — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODABAR START STOP CHARACTER = abcd/tn* e CODABAR START STOP CHARACTER = abcd/abcd 6-236 ®...

  • Page 353: Codabar Start Stop Character Match

    Codabar Enable Codabar Start Stop Character Match Enables/disables the requirement that start and stop characters match. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 354: Codabar Check Character Calculation

    Codabar Check Character Calculation Enables/disables calculation and verification of an optional Codabar check character. If check character calculation is disabled, the risk is increased that a misread can occur. When disabled, any check characters in a bar code are treated as data characters.

  • Page 355: Codabar Check Character Transmission

    Codabar Enable Codabar Check Character Transmission Enables/disables transmission of an optional Codabar check character. Applies only when Codabar Check Character Calculation is enabled. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1.

  • Page 356: Codabar Aim Id

    Codabar AIM ID This feature enables/disables transmission of the Codabar AIM symbology identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 357: Codabar Label Id

    Codabar Enable Codabar Label ID This feature specifies a Codabar label ID to e added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 358: Codabar Length Control

    Codabar Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Codabar. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 359: Codabar Maximum Label Length

    Codabar Enable Codabar Maximum Label Length This feature specifies the maximum allowable length of a Codabar label. Length in this case includes start, stop or check and data characters, but does not include full ASCII shift characters. This feature applies when Coda- bar Length Control is set to variable-length decoding.

  • Page 360: Codabar Minimum Label Length

    Codabar Minimum Label Length This feature specifies the minimum allowable length of a Codabar label. Length in this case includes start, stop or check and data characters, but does not include full ASCII shift characters. This feature applies when Coda- bar Length Control is set to variable-length decoding.

  • Page 361: Codabar Fixed Length 1

    Codabar Enable Codabar Fixed Length 1 This feature specifies Codabar first fixed length. Length in this case includes start, stop or check and data characters, but does not include full ASCII shift characters. This feature applies when Codabar Length Control is set to fixed-length decoding.

  • Page 362: Codabar Fixed Length 2

    Codabar Fixed Length 2 This feature specifies Codabar second fixed length. Length in this case includes start, stop or check and data characters, but does not include full ASCII shift characters. This feature applies when Codabar Length Control is set to fixed-length decoding.

  • Page 363: Codabar Stitching

    Codabar Enable Codabar Stitching Enables/disables stitching for Codabar labels. When parts of a Codabar bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.

  • Page 364: Code 93 Enable

    Code 93 Enable Enables/disables the ability of the scanner to decode Code 93 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 365: Code 93 Aim Id

    Code 93 Enable Code 93 AIM ID This feature enables/disables transmission of the Code 93 AIM symbology identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 366: Code 93 Label Id

    Code 93 Label ID This feature specifies a Code 93 label ID to be added to bar code data.. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 367: Code 93 Length Control

    Code 93 Enable Code 93 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 93. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 368: Code 93 Maximum Label Length

    Code 93 Maximum Label Length This feature specifies the maximum allowable length of a Code 93 label. Length in this case includes data characters, but does not include start, stop, full ASCII shift, or check characters. This feature applies when Code 93 Length Control is set to variable-length decoding.

  • Page 369: Code 93 Minimum Label Length

    Code 93 Enable Code 93 Minimum Label Length This feature specifies the minimum allowable length of a Code 93 label. Length in this case includes data characters, but does not include start, stop, full ASCII shift, or check characters. This feature applies when Code 93 Length Control is set to variable-length decoding.

  • Page 370: Code 93 Fixed Length 1

    Code 93 Fixed Length 1 This feature specifies Code 93 first fixed length. This applies when Code 93 Length Control is set to fixed-length decoding. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code, below.

  • Page 371: Code 93 Fixed Length 2

    Code 93 Enable Code 93 Fixed Length 2 This feature specifies Code 93 second fixed length. This applies when Code 93 Length Control is set to fixed-length decoding. If Fixed Length 2 is set to 00 (zero), then Fixed Length 1 will apply. NOTE To set this feature: 1.

  • Page 372: Code 93 Stitching

    Code 93 Stitching Enables/disables stitching for Code 93 labels. When parts of a Code 93 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.

  • Page 373: Msi/Plessey Enable

    MSI/Plessey Enable MSI/Plessey Enable Enables/disables the ability of the scanner to decode MSI/Plessey labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 374: Msi/Plessey Check Character Calculation

    MSI/Plessey Check Character Calculation Enables/disables calculation and verification of optional MSI/Plessey check characters. If check character calculation is disabled, the risk is increased that a misread can occur. When disabled, any check characters in a bar code are treated as data characters.

  • Page 375: Msi/Plessey Number Of Check Characters

    MSI/Plessey Enable MSI/Plessey Number of Check Characters Specifies number of MSI/Plessey check characters to be calculated and verified. Check characters are always modulus 10. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below representing the desired number of MSI/ Plessey check characters to be calculated and verified.

  • Page 376: Msi/Plessey Check Character Transmission

    MSI/Plessey Check Character Transmission Enables/disables transmission of optional MSI/Plessey check characters. This feature applies only when MSI/Plessey Check Character Calculation is enabled. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1.

  • Page 377: Msi/Plessey Aim Id

    MSI/Plessey Enable MSI/Plessey AIM ID This feature enables/disables transmission of the MSI/Plessey AIM sym- bology identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 378: Msi/Plessey Label Id

    MSI/Plessey Label ID This feature specifies an MSI/Plessey label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 379: Msi/Plessey Length Control

    MSI/Plessey Enable MSI/Plessey Length Control This feature specifies whether variable-length or fixed-length decoding will be set for MSI/Plessey. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 380: Msi/Plessey Maximum Label Length

    MSI/Plessey Maximum Label Length This feature specifies the maximum allowable length of an MSI/Plessey label. Length in this case includes check and data characters, but does not include start, stop or full ASCII shift characters. This feature applies when MSI/ Plessey Length Control is set to variable-length decoding.

  • Page 381: Msi/Plessey Minimum Label Length

    MSI/Plessey Enable MSI/Plessey Minimum Label Length This feature specifies the minimum allowable length of an MSI/Plessey label. Length in this case includes check and data characters, but does not include start, stop or full ASCII shift characters. This applies when MSI/Plessey Length Control is set to variable-length decoding.

  • Page 382: Msi/Plessey Fixed Length 1

    MSI/Plessey Fixed Length 1 This feature specifies MSI/Plessey first fixed length. This applies when MSI/Plessey Length Control is set to fixed-length decod- ing. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code, below. SET MSI/PLESSEY FIXED LENGTH 1 You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend...

  • Page 383: Msi/Plessey Fixed Length 2

    MSI/Plessey Enable MSI/Plessey Fixed Length 2 This feature specifies MSI/Plessey second fixed length. This applies when MSI/Plessey Length Control is set to fixed-length decod- ing. If Fixed Length 2 is set to 00 (zero), then Fixed Length 1 will apply. NOTE To set this feature: 1.

  • Page 384: Msi/Plessey Stitching

    MSI/Plessey Stitching Enables/disables stitching for MSI/Plessey labels. When parts of an MSI/ Plessey bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met. To set this feature: 1.

  • Page 385: Standard 2 Of 5 Enable

    Standard 2 of 5 Enable Standard 2 of 5 Enable Enables/disables the ability of the scanner to decode Standard 2 of 5 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 386: Standard 2 Of 5 Check Character Calculation

    Standard 2 of 5 Check Character Calculation Enables/disables calculation and verification of an optional Standard 2 of 5 check character. If check character calculation is disabled, the risk is increased that a mis- read can occur. When disabled, any check character in a bar code is treated as data character.

  • Page 387: Standard 2 Of 5 Check Character Transmission

    Standard 2 of 5 Enable Standard 2 of 5 Check Character Transmission Enables/disables transmission of an optional Standard 2 of 5 check charac- ter. This feature applies only when Standard 2 of 5 Check Character Cal- culation is enabled. This item is ignored when the advanced feature, Full Label Edit, is enabled.

  • Page 388: Standard 2 Of 5 Aim Id

    Standard 2 of 5 AIM ID This feature enables/disables transmission of the Standard 2 of 5 AIM symbology identifier. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 389: Standard 2 Of 5 Label Id

    Standard 2 of 5 Enable Standard 2 of 5 Label ID This feature specifies an Standard 2 of 5 label ID to be added to bar code data. The programming feature, RS-232 Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.

  • Page 390: Standard 2 Of 5 Length Control

    Standard 2 of 5 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for 2 of 5. Standard To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 391: Standard 2 Of 5 Maximum Label Length

    Standard 2 of 5 Enable Standard 2 of 5 Maximum Label Length This feature specifies the maximum allowable length of a Standard 2 of 5 label. Length in this case includes check and data characters, but does not include start or stop characters. This feature applies when Standard 2 of 5 Length Control is set to variable-length decoding.

  • Page 392: Standard 2 Of 5 Minimum Label Length

    Standard 2 of 5 Minimum Label Length This feature specifies the minimum allowable length of an Standard 2 of 5 label. Length in this case includes check and data characters, but does not include start or stop characters. This feature applies when Standard 2 of 5 Length Control is set to variable-length decoding.

  • Page 393: Standard 2 Of 5 Fixed Length 1

    Standard 2 of 5 Enable Standard 2 of 5 Fixed Length 1 This feature specifies Standard 2 of 5 first fixed length. This applies when Standard 2 of 5 Length Control is set to fixed- length decoding. NOTE To set this feature: 1.

  • Page 394: Standard 2 Of 5 Fixed Length 2

    Standard 2 of 5 Fixed Length 2 This feature specifies Standard 2 of 5 second fixed length. This applies when Standard 2 of 5 Length Control is set to fixed-length decoding. If Fixed Length 2 is set to 00 (zero), then Fixed Length 1 will apply. NOTE To set this feature: 1.

  • Page 395: Standard 2 Of 5 Stitching

    Standard 2 of 5 Enable Standard 2 of 5 Stitching Enables/disables stitching for Standard 2 of 5 labels. When parts of a Stan- dard 2 of 5 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.
  • Page 396 NOTES 6-280 ® Magellan 9500...
  • Page 397 Appendix A LED/Beeper Indications & Controls shows the operator’s controls and indicators. The descriptions Figure A-1 following identify the use or function of each component. Figure A-1. Scanner and Scale Controls Volume/Tone Push Button Scale Zero Push Button Scanner LED (Green) Scale LED (Yellow) EAS LED (Tri-Color) Manual EAS...

  • Page 398: Controls And Indicators

    Controls and Indicators The control panel consists of three indicator LEDs and three push buttons as described in the following pages. The unit also includes a beeper which can be configured to sound indications of scanning, weighing, and deacti- vation activities. Since beeper indications are configurable, your unit may not be pro- grammed to sound all the indications listed.
  • Page 399 Controls and Indicators Table A-1. Scanner and Scale LED Indications DURATION COMMENT INDICATION Scanner (Green) LED 1-second off, 1/ Host Disabled 10-second on Host has disabled scanning. Audible low tone 1 second. Serves notice that a fatal FRU failure has been Field Replace- detected.
  • Page 400 Deactivator LED The Deactivator LED (tri-color, bottom-most) designates EAS deactiva- ). The table also provides information about spe- tion status (see Table A-2 EAS (Tri-Color) LED cial beeper indications which can be sounded in response to changes in deactivation status. Table A-2.
  • Page 401 Controls and Indicators Table A-2. EAS Indications COUPLED MODE ONLY The EAS antenna Good read beep fol- Deactivation (Tri-color) LED has been triggered lows deactivation. flashes Red, then Orange, Deactivation ON to deactivate a then returns to Green. Indicated label following suc- cessful bar code read.

  • Page 402: Volume/Tone Push Button

    Table A-2. EAS Indications HYBRID MODE Deactivation (Tri-color) LED High frequency beep An EAS tag has flashes Red, then Orange, Deactivation been successfully then returns to Green. Indicated deactivated. a. Additionally, the FRU LED (7-segment display located in the bottom of the optic cavity — visi- ble through the horizontal scan window) blinks the number ‘9’.
  • Page 403 Controls and Indicators Table A-3. Volume/Tone Push Button Functions (Continued) PRESS FUNCTION COMMENT DURATION Press the push button for approximately 2 seconds, Hold, then release then release. Each time this is done, the beeper will when the beeper Increments tone sound at one of three tones.

  • Page 404: Manual Eas Deactivation Push Button

    Manual EAS Deactivation Push Button Using the programming bar codes contained in the Product Refer- ence Guide (PRG) the button can be configured to operate always, or only function when the scanner is enabled. PRESS FUNCTION COMMENT DURATION Manually initiates EAS Place the item with the EAS tag downstream of the Momentary...

  • Page 405: Scale Zero Push Button

    Controls and Indicators Scale Zero Push Button The Scale Zero Push Button is used for multiple functions as listed in Table A-4 The Scale Zero Push Button has no function in a “scanner only” model. NOTE Table A-4. Scale Zero Push Button Functions PRESS FUNCTION COMMENT...

  • Page 406: Calibration Switch

    Calibration Switch This switch initiates the scale’s calibration routine. A certified weight set is needed to perform the scale calibration steps detailed in Chapter 5 Cali- . This switch is not included in scanners without scale modules. bration Calibration Switch Seal This seal allows you to secure the Calibration Switch access cover and restrict access to the Calibration Switch.

  • Page 407: Appendix B. Cable Information

    Appendix B Cable Information Introduction The following pages contain pinout information, enabling you to create standard interface cables for use in interconnecting the scanner, scale, external handheld scanner, and POS terminal. General Specifications Wire Requirements • Cable length should not exceed 15 feet. •...

  • Page 408: Cable Pinout

    RS-232 Cable Pinout Scanner Connector Hardware RJ45, 10 Position Cable Pinout Table B-1RS-232 Cable Pinouts PIN # FUNCTION DESCRIPTION No Connection CTS in Clear To Send (input) No Connection RTS out Request To Send (output) RxD in Receive Data (Input) TxD out Transmit Data (output) No Connection...

  • Page 409: Cable Pinout - Continued

    RS-232 Cable Pinout — continued RS-232 Cable Pinout — continued Scale Connector Hardware RJ45, 10 Position Cable Pinout Table B-2RS-232 Scale Cable Pinouts PIN # FUNCTION DESCRIPTION +5V pullup +5V pullup CTS IN Clear To Send (input) No Connection RTS OUT Request To Send (output) RxD IN Receive Data (Input)

  • Page 410: Ibm Cable Pinout

    IBM Cable Pinout Scanner and Scale Connector Hardware RJ45, 10 Position Cable Pinout Table B-3IBM Cable Pinouts PIN # FUNCTION DESCRIPTION No Connection No Connection No Connection LINEB Line B No Connection LINEA Line A No Connection +5V out +5V out Signal Ground No Connection ®...

  • Page 411: Ibm Usb Cable Pinout

    IBM USB Cable Pinout IBM USB Cable Pinout Scanner and Scale Connector Hardware RJ45, 10 Position Cable Pinout Table B-4IBM USB Cable Pinouts PIN # FUNCTION DESCRIPTION No Connection No Connection No Connection USB D- USB D- No Connection USB D+ USB D+ No Connection +5V out...

  • Page 412: Auxilliary Port

    Auxilliary Port External Handheld Input Connector Hardware RJ45, 10 Position Cable Pinout Table B-5Auxilliary Port Cable Pinouts PIN # FUNCTION DESCRIPTION +5V pullup +5V pullup CTS in Clear To Send (input) No Connection - Reserved RTS out Request To Send (output) RxD in Receive Data (Input) TxD out...

  • Page 413: Power Cable

    Power Cable Power Cable Connector Hardware 6 pin Molex Cable Pinout Table B-6Power Cable Pinouts PIN # FUNCTION DESCRIPTION EARTH GND Earth Ground SIGNAL GND Signal Ground +5V IN +5V in No Connection No Connection +12V IN +12V in Product Reference Guide...

  • Page 414: Remote Display

    Remote Display Connector Hardware 4 pin SDL Cable Pinout Table B-7Remote Display Cable Pinouts PIN # FUNCTION DESCRIPTION +12V OUT +12V out LINE_A_DSPLY LINE A Display LINE_B_DSPLY LINE B Display Ground ® Magellan 9500...

  • Page 415: Eas Comm Port

    EAS Comm Port EAS Comm Port EAS Deactivator Control Box Connection Connector Hardware RJ10 Cable Pinout Table B-8EAS Comm Port Cable Pinouts PIN # FUNCTION DESCRIPTION VCC5 VCC5 EAS DEACT EN~ EAS Deactivation VCC5 VCC5 EAS DETECT EN~ EAS Detection EAS LBL DETECT EN~ EAS tag Detect Signal Ground...
  • Page 416 NOTES B-10 ® Magellan 9500...

  • Page 417: Appendix C Keypad

    Appendix C Keypad Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 418 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 419 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 420 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 421 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 422 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 423 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 424 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 425: Appendix D Host Commands

    Appendix D Host Commands Accepting Commands from an RS-232 Scanner Host The scanner responds to the following RS-232 commands: COMMAND ASCII COMMENT Enable Scanner 0x45 Disable Scanner 0x44 Reset Scanner 0x52 Not On File Indication 0x46 Long series of beeps Beep Good Read Tone 0x42 Beeps if Good Read Beep is enabled...
  • Page 426 NOTES ® Magellan 9500...

  • Page 427: Appendix E. Factory Defaults

    Appendix E Factory Defaults The following table provides a listing of the most common factory settings for the interfaces shown. Table E-1Factory Default Settings Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable Double Read Time- (600ms) (600ms) (600ms) (600ms) (600ms) (600ms) Laser Timeout...
  • Page 428 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable Good Read When to 1 (after 1 (after 1 (after 1 (after 1 (after 1 (after Indicate transmit) transmit) transmit) transmit) transmit) transmit) Scale Enable 0 (disable) 1 (enable) 0 (disable) 1 (enable) 1 (enable) 1 (enable)
  • Page 429 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable EAS Deactivation Duration — Coupled (500ms) (500ms) (500ms) (500ms) (500ms) (500ms) EAS Deactivation Duration — Retry (500ms) (500ms) (500ms) (500ms) (500ms) (500ms) EAS Deactivation 100 (5sec) 100 (5sec) 100 (5sec) 100 (5sec) 100 (5sec) 100 (5sec) Duration —...
  • Page 430 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable RS-232 Number of 0 (1 stop 0 (1 stop 0 (1 stop 0 (1 stop Stop Bits bit) bit) bit) bit) RS-232 Parity 0 (none) 0 (none) 2 (odd) 2 (odd) RS-232 Hardware 1 (enable 0 (disable)
  • Page 431 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable RS-232 Retry on 1 (enable) 1 (enable) 1 (enable) ACK NAK Timeout RS-232 ACK NAK 1 (200ms) 1 (200ms) 1 (200ms) Timeout Value RS-232 ACK NAK 3 resets 3 resets 3 resets Retry Count RS-232 ACK NAK 0 (ignore...
  • Page 432 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable UPC-A Number Sys- tem Character Trans- 0 (disable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) mission UPC-A Check Char- 1 (enable) 1 (enable) 1 (enable) 0 (disable) 1 (enable) 1 (enable) acter Transmission Expand UPC-A to...
  • Page 433 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable UPC-E 128 Supple- 4500("E") 4500("E") 4300("C") 4500("E") mental Label ID EAN-13 Enable 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) EAN-13 First Charac- 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
  • Page 434 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable EAN-8 128 Supple- 4646 4646 4646 4200 ("B") mental Label ID ("FF") ("FF") ("FF") 2 (Slightly 2 (Slightly 2 (Slightly 2 (Slightly 2 (Slightly 2 (Slightly EAN-8 Decoding Lev- More More More More More...
  • Page 435 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable 5234 5234 5234 RSS-14 Label ID 4500 ("E") ("R4") ("R4") ("R4") RSS Expanded 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) Enable RSS Expanded EAN- 0 (disable) 0 (disable) 0 (disable) 0 (disable)
  • Page 436 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable Code 39 Full ASCII 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) Code 39 AIM ID 0 (disable) 0 (disable) 0 (disable) 4D00 4231 Code 39 Label ID 2A00 ("*") 2A00 ("*") ("M")
  • Page 437 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable Code 128 AIM ID 0 (disable) 0 (disable) 0 (disable) 4233 Code 128 Label ID 2300 ("#") 2300 ("#") 4B00 ("K") ("B3") Code 128 Length Control (variable) (variable) (variable) (variable) (variable) (variable) Code 128 Maximum Label Length...
  • Page 438 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable I 2 of 5 Maximum Label Length I 2 of 5 Minimum Label Length I 2 of 5 Fixed Length I 2 of 5 Fixed Length I 2 of 5 Stitching 0 (disable) 0 (disable) 0 (disable)
  • Page 439 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable Codabar Fixed Length 1 Codabar Fixed Length 2 Codabar Stitching 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) Code 93 Enable 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
  • Page 440 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable 4000 4000 4000 MSI/Plessey Label ID 4F00 ("O") ("@") ("@") ("@") MSI/Plessey Length Control (variable) (variable) (variable) (variable) MSI/Plessey Maxi- mum Label Length MSI/Plessey Mini- mum Label Length MSI/Plessey Fixed Length 1 MSI/Plessey Fixed Length 2 MSI/Plessey Stitch-...
  • Page 441 Wincor- Single RS-232 IBM 17 IBM USB Nixdorf Cable Standard 2 of 5 Mini- mum Label Length Standard 2 of 5 Fixed Length 1 Standard 2 of 5 Fixed Length 2 Standard 2 of 5 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
  • Page 442 NOTES E-16 ® Magellan 9500...

  • Page 443: Appendix F. Handheld Data Format Requirements

    Maximum label lengths will be enforced for label validation (i.e. labels longer than the maximum label size will not be validated). • Standard Datalogic formats generally use a single prefix character. The specific formats are provided below. Product Reference Guide...

  • Page 444: Datalogic Handheld Data Format Requirements

    Datalogic Handheld Data Format Requirements The following sections describe label transmission formats that are typi- cally observed in factory configurations of Datalogic handheld scanners. RSS-14 • Prefix must be ASCII characters ‘R4’ • Check character must be included in label •...
  • Page 445 UPC-A with 5-Digit Supplemental • Number system must be included in label data • Check digit must be included in label data and is assumed to be cor- rect • Prefix must be an ASCII character 'A' - total length including prefix must be 18 •...
  • Page 446 UPC-E with 2-Digit Supplemental • Number system must be included in label data. • Check digit must be included in label data and is assumed to be cor- rect. • Supplemental data is appended to base label. • Prefix must be an ASCII character 'E' - total length including prefix must be 11.
  • Page 447 EAN-8 • Check digit must be included in label data and is assumed to be cor- rect • Prefix must be an ASCII characters 'FF' - total length including pre- fix must be 10 • Example: 'FF00210126' EAN-8 with 2-Digit Supplemental •...
  • Page 448 EAN-13 • Check digit must be included in label data and is assumed to be cor- rect • Prefix must be an ASCII character 'F'- total length including prefix must be 14 • Example: 'F1101234567891' EAN-13 with 2-Digit Supplemental • Check digit must be included in label data and is assumed to be cor- rect •...
  • Page 449 Code 39 • Check character must be included in label data. • Label length including start, stop and check characters and exclud- ing prefix character must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type.
  • Page 450 Codabar • Check character must be included in label data. • Label length including check character and excluding prefix charac- ter must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. • Prefix must be an ASCII character '%'.
  • Page 451 MSI/Plessey • Check character must be included in label data. • Label length including check character and excluding prefix charac- ter must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. • Prefix must be an ASCII character '@'.

  • Page 452: Aim Formats

    AIM Formats AIM specifies a 3-character string that is attached as a prefix to the label data for transmission. Because AIM specifies one identifier for UPC-A, UPC-E and EAN-13 labels, UPC-A, UPC-E and EAN-13 will be received from the handheld and transmitted by the scanner as EAN-13. The ']' character must be the first character received in the label transmission from the handheld.

  • Page 453: Digit Supplemental

    2-Digit Supplemental • Supplemental data is appended to any EAN base label. • Prefix must be ASCII characters ']E1'. • length of Supplemental data including prefix must be 5. Total required length is 21 for EAN-13 and 16 for EAN-8. •...

  • Page 454: Code 128 Supplemental

    Code 128 Supplemental • Supplemental data is appended to any EAN base label. • Prefix must be ASCII characters ']C0'. • length of Supplemental data including prefix is variable but must be at least 9. • Examples: addon portion is highlighted data is underlined. UPC-A Code 128 addon ']E00060992011187]C08100000951' UPC-E Code 128 addon...
  • Page 455 Codabar • Check character must be included in label data. • Label length including check character and excluding prefix charac- ters must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. • Prefix must be ASCII characters ']F0'.

  • Page 456: Rss Expanded

    RSS-14 • Prefix must be ASCII characters ']e0'. • Check character must be included in label. • Label length excluding prefix characters must be 14 characters. • Example: ']e001044123456789'. RSS Expanded • Prefix must be ASCII characters ']e0'. • Label length excluding prefix characters must be at least 1 character. Maximum length is the maximum label size supported by the scan- ner.
  • Page 457 Code 128 / EAN128 • Prefix must be either ASCII characters ']C0', ']C1' or ']C2'. • Label length excluding prefix character must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. • If EAN-128 Symbology is Enabled and prefix is ']C1', label will be identified as an EAN128 otherwise it is identified as a Code 128.
  • Page 458 NOTES F-16 ® Magellan 9500...

  • Page 459: Ascii Character Set

    ASCII Character Set The table on this page shows a set of ASCII characters and their corresponding Hex Values. The Hex Values in this table are needed for setting symbology specific label identifiers, as well as enabling custom prefix and suffix characters. Table 1 ASCII ASCII...
  • Page 460 Datalogic Scanning, Inc Telephone: [33].01.64.86.71.00 Telephone: (305) 591-3222 france.scanning@datalogic.com latinamerica.scanning@datalogic.com Germany Singapore Datalogic Scanning GmbH Datalogic Scanning Singapore PTE LTD Telephone: 49 (0) 61 51/93 58-0 Telephone: (65) 6435-1311 germany.scanning@datalogic.com singapore.scanning@datalogic.com India Spain and Portugal Datalogic Scanning India Datalogic Scanning Sarl Sucursal en Telephone: 91- 22 - 64504739 España...
