Page 1 ® Magellan 8300/8400 Product Reference Guide...
Page 2 Datalogic reserves the right to change any specification at any time without prior notice. Datalogic is a registered trademark of Datalogic S.p.A. in many countries and the Datalogic logo is a trademark of Datalogic S.p.A. All other brand and product names referred to herein may be trademarks of their respective own- ers.
Page 3: Table Of Contents
Table of Contents Chapter 1. Introduction ..................1-1 Manual Overview ......................1-1 How to Use This Manual ..................1-2 Technical Support ......................1-4 Datalogic Website Support ..................1-4 Datalogic Website TekForum ..................1-4 Reseller Technical Support ..................1-4 Telephone Technical Support ..................1-4 Scanner and Scanner/Scale Nomenclature ...............1-5 Connections .........................1-6...
Page 4 Operational Verification ..................2-23 Diagnostic Modes ....................2-26 Cables & Connections ....................2-27 Remote Scale Display Placement/Installation ..............2-29 Lighting Considerations ..................2-29 Viewing Angle ......................2-30 Remote Display Cabling ..................2-31 Placing and Installing the Remote Scale Display ............2-31 Changing Weighing Modes ..................2-34 Set-Up & Installation ....................2-34 Set-up ........................2-34 Installation ......................2-36 Adaptive Scale Platter Option .................2-38...
Page 5 Calibration Verification (Kilograms) ................5-11 Increasing-Load Test (Phase 1) ................5-11 Shift Test (Metric) ....................5-12 Increasing- Load Test (Phase 2) ................5-13 Blanking Test ....................... 5-14 Decreasing-Load Test .................... 5-15 Return to Zero Test ....................5-15 Chapter 6. Programming................... 6-1 Introduction to Label Programming .................6-1 Understanding the Basics ....................6-1 Integrating the Scanner With Your Host System ..............6-2...
Page 6 EAS Features ......................6-60 EAS Active State ....................6-60 EAS Timeout ......................6-61 Interface Related Features ...................6-62 Interface Type ......................6-62 Number of Host Transmission Buffers ..............6-84 AIM ID ........................6-85 Label ID Control ....................6-87 Global Prefix ......................6-90 Global Suffix ......................6-92 Case Conversion ....................6-94 IBM Features ......................6-96 IBM Interface Options ...................6-96 IBM Number of Host Resets ..................6-97 IBM Scale Address ....................6-98...
Page 7 Single Cable RS-232 Use BCC ................6-147 Single Cable RS-232 Use ACK/NAK ............... 6-148 Single Cable RS-232 Use STX ................6-149 Set Single Cable RS-232 STX Character ..............6-150 Set Single Cable RS-232 ETX Character ..............6-151 Keyboard Wedge/USB Keyboard Features ..............6-152 Keyboard Interface —...
Page 8 EAN-8 2-Digit Supplemental Label ID ..............6-211 EAN-8 5-Digit Supplemental Label ID ..............6-212 EAN-8 128 Supplemental Label ID ................ 6-213 EAN-8 Decoding Levels ..................6-214 EAN-8 Minimum Reads ..................6-217 EAN-8 Minimum Segment Length ................6-219 Other UPC/EAN Options ..................... 6-225 Price Weight Check .....................
Page 9 Pharmacode 39 Enable ....................6-289 Pharmacode 39 Start Stop Character Transmission ..........6-290 Pharmacode 39 Check Character Transmission ............6-291 Pharmacode 39 Label ID ..................6-292 Code 128 Enable ...................... 6-293 Code 128 Transmit Function Characters ..............6-294 Convert Code 128 to Code 39 ................6-295 Code 128 Label ID ....................
Page 10 Code 93 Length Control ..................6-348 Code 93 Length 1 ....................6-349 Code 93 Length 2 ....................6-350 Code 93 Correlation .................... 6-351 Code 93 Stitching ....................6-352 Code 93 Minimum Reads ..................6-353 MSI/Plessey Enable ....................6-355 MSI/Plessey Check Character Calculation ............... 6-356 MSI/Plessey Number of Check Characters ..............
Page 11 Appendix F. Factory Defaults............... F-1 Appendix G. Handheld Data Format Requirements ......G-1 Handheld Data Format Requirements General ............G-1 Datalogic Handheld Data Format Requirements ............G-2 AIM Formats ....................... G-10 Product Reference Guide...
Page 12 NOTES ® Magellan 8300/8400...
Page 13 Agreement. If you do not intend to be bound to the terms of this Agreement, Data- logic is not willing to license the Software to you, you may not use the Datalogic Product or the Software, and you must contact the party from whom you acquired the Datalogic Product for instructions.
Page 14 Software clause at DFARS 252.227-7013(c)(1)(ii), whichever is applicable. If End User is using the Datalogic Product outside of the United States, End User must comply with the applicable local laws of the country in which the Datalogic Product is used, with U.S. export control laws, and with the English language version of this Agreement. The provisions of the "United Nations Convention on International Sale of Goods"...
Page 15: Chapter 1. Introduction
Chapter 1 Introduction This Product Reference Guide contains comprehensive instructions on scanner or scanner/scale installation. Either model may be termed “scan- ner” for the purpose of simplicity in this manual. Also included are feature configuration using special programming feature bar code labels and advanced user information as described in the following chapter descrip- tions.
Page 16: How To Use This Manual
, highlights the function(s) of each programma- Chapter 6, Programming ble feature and provides a dedicated set of bar codes for configuring scan- ner and scanner/scale features. This chapter is organized by the categories: General Features, Interface Related Features and Symbology Related Fea- tures.
Page 17: Manual Conventions
Manual Overview Manual Conventions ‘NOTE’ blocks contain information that is helpful and rec- ommended. They provide information that is critical to operations and/or procedures described in this manual. ‘LEGAL NOTE’ blocks indicate procedures or activities LEGAL NOTE which may be regulated under law by governmental agencies.
Page 18: Technical Support
Datalogic reseller. A reseller is acquainted with specific types of busi- nesses, application software, and computer systems and can provide individualized assistance. Telephone Technical Support If you do not have internet or email access, you may contact Datalogic technical support at (541) 349-8281. ® Magellan...
Page 19: Scanner And Scanner/Scale Nomenclature
Scanner and Scanner/Scale Nomenclature Scanner and Scanner/Scale Nomenclature Controls, indicators and other nomenclature are shown in Figure 1-1 Figure 1-1. Scanner/Scale Nomenclature Weighing Surface — Lean Oversize Produce Here Scanner LED All Weighs™ Platter Vertical Window Bonnet Horizontal Window Volume/Tone Push Button Scale Zero Push Button...
Page 20: Connections
Connections Two connector panels are located on either side of the scanner as shown in . The appearance of these panels will vary depending upon the Figure 1-2 factory options purchased with your model. Additionally, a service “pig- tail” extends from the scanner’s base to connect the control panel cable from the Bonnet area.
Page 21: Physical Parameters
Physical Parameters Physical Parameters This chapter provides specifications for performance, environmental and electrical parameters. Reference Chapter 2, Site Preparation and Installa- , for physical measurements of all models and some accessories. tion Scanning The scanner has a scan zone between the two windows where the scanner projects laser light in order to scan items.
Page 22: Weighing
Weighing Specifications for scale capacity, settling time, minimum and maximum static weight, zeroing, and warm-up time are given below. For more infor- mation regarding the topic: , refer to Proper Weighing Technique in this manual. Chapter 3, Operation and Maintenance Rated Weight Capacity The scale’s operational weight capacity is: •...
Page 23: Warm-Up Time
Physical Parameters Warm-Up Time There are two pertinent warm-up times that apply to the scanner or scan- ner/scale: The two warm-up periods can be performed concurrently, thereby reducing the total required warm-up time to 60 minutes. NOTE Thermal Equilibrium When the unit is moved from a cooler temperature (such as a storage area) to a warmer environment (such as a checkstand location), 60 minutes must be allowed to acclimate the unit to ambient conditions prior to cali- bration or operation.
Page 24: Electrical Specifications
(86,080 LUX) Humidity Hot / Wet 40°C / 95% RH Spill Proof Hot / Dry 40°C / 15% RH (Datalogic MS-0006-13-0004) Cold / Dry 10°C / 1 5% RH Warm / Wet 25%C / 50% RH Storage +70 C +158 F...
Page 25: Power Supply
Electrical Specifications Power Supply Power Off the Terminal (P.O.T) Certain units can receive power directly from the terminal (P.O.T.). A USB adapter “brick” connects the scanner to IBM-USB 12V ports. Power supplied from the terminal does not include auxiliary power for alterna- tive scales.
Page 26: Laser And Product Safety
Laser and Product Safety Laser safety requirements are based on IEC Standard Publication 60825-1 (2001) and CDRH 21CFR, Chapter 1, Subchapter J and (CDRH) Laser Product Performance Standard, User information [1040.10(h)1]: • User Maintenance. No user maintenance of the laser system other than cleaning of the scan windows is required.
Page 27: Canadian Notice
Laser and Product Safety Safety precautions to be taken: No adjustments or alteration of the scanner or scanner/scale housing are to be attempted by the user. The failure of the facet wheel motor while the unit is continuing to emit a laser beam causes the emission levels to exceed those for inherently safe CAUTION operation.
Page 28: Labeling
Labeling Regulatory, reference and safety labeling is shown in Figure 1-4 Figure 1-4. Labeling Product IEC Laser Family Warning Label Model/Serial Number Scale Regulatory I/F Connector ID and Regulatory 1-14 ® Magellan 8300/8400...
Page 29: Agency Compliances
Agency Compliances Agency Compliances The scanner and scanner/scale meets or exceeds the requirements for its device type as set forth by the following agencies and regulations: COUNTRY COMPLIANCE COMMENTS Electrical United States UL 60950 State of California Energy Efficiency Standard Canada CAN/CSA 60950 Europe...
Page 30 Argentina Australia/New Zealand Brazil EC Countries Mexico Puerto Rico Singapore Jamaica OIML R76 Russia ® Contact Datalogic Product Marketing at (541) 683-5700, or your Data- logic representative for a complete listing of approvals for other countries. 1-16 ® Magellan 8300/8400...
Page 31: Bar Codes Supported
Bar Codes Supported Bar Codes Supported The scanner can read/decode the following bar code types (symbologies): Retail Codes • UPC Versions A & E with full expansion E to A, plus A and E to 13 capability • UPC Supplementals and Add-ons (Bookland & Coupon code, UPC two character supplemental encodation and UPC five charac- ter supplemental encodation and supplemental C128) with support for conditional add-ons...
Page 32: Dual Bar Codes For Japan (2 Label Read)
Dual Bar Codes for Japan (2 label read) The following qualifications apply to Dual Bar Codes for Japan: • Two label combined transmission • Two label global midamble (see Chapter 6, Programming, for more details) NOTE • Two label flag is set by selecting any 4 digits as the flag 1-18 ®...
Page 33: Chapter 2. Site Preparation And Installation
Chapter 2 Site Preparation and Installation This chapter provides a reference for preparing most checkstands to receive the scanner or scanner/scale. Included are physical parameters and instructions for checkstand preparation, power and ventilation consider- ations, cable routing information and unit installation. Site Preparation lists all procedures necessary to prepare the checkstand.
Page 34: Models
Scanner and scanner/scale models (reference Figure 2-1) are available in different lengths, allowing them to fit with little or no modification into ® openings cut for previously installed scanners such as Datalogic Magel- ® ® scanners, or NCR scanner models 7820/24 and 7870. Other mod- els are designed for applications with smaller footprint requirements.
Page 35: Pre-Installation Considerations
Pre-Installation Considerations Figure 2-3. Produce Bar and Produce Rail Produce Produce Bar Option Rail Option Pre-Installation Considerations It should be noted that the scope of this manual does not encompass all factors related to worker safety and checkstand design. It does, however, offer a list of considerations that may be helpful in ensuring greater safety and productivity.
Page 36: Checkstand Design
Checkstand Design 1. Select a design which allows load-sharing by several muscle groups (for example designs which allow the cashier to use both hands for scanning and bagging). 2. Select checkstands which deliver products to the cashier on an input belt and do not require the unloading of items from a cart.
Page 37: Scanner Installation
Scanner Installation Scanner Installation 1. Mount the horizontal surface of the scanner flush with the counter- top to encourage slide scanning rather than lifting. 2. Position the centerline of the scanner read area 8 - 10 inches (20.3 - 25.4 cm) from the edge of the checkstand (cashier side). Scanner Maintenance 1.
Page 38: Site Preparation Overview
• Develop a smooth fluid motion during scanning, sharing work equally between hands. • Use the entire hand for grasping and lifting items. • Since the scanner reads labels on all four sides plus the top and bottom, there is no need to turn a bar code toward either of the scanner windows.
Page 39 Site Preparation Overview Recommended Power Installation — Since the typical grocery envi- ronment includes conveyor belts and electric motors, care should be taken to ensure that the scanner has a supply of “clean” power (power without excessive electrical noise). A wiring diagram shows the recommended wir- ing that will provide the scanner with a “clean”...
Page 40: Ventilation And Spacing
unavoidable, an alternate method of platter removal using two coins may be employed, however a minimum vertical clearance of 1.5” (3.8 cm) MUST be provided (reference Figure 2-4). Another consideration is that the scan zone must be kept free of obstructions such as enclosures, key- board mounts, etc.
Page 41 Ventilation and Spacing • A source of air that provides adequate cooling by convective air flow. DO NOT place the scanner in a close-fitting, fully enclosed checkstand. Pro- vide a MINIMUM of 16 square inches (103.2 square centimeters) of air intake from below the installation for sufficient convective cooling.
Page 42: Service Access
Service Access The scanner and scanner/scale have been engineered to allow performance of all routine service and maintenance (such as “zeroing” and calibration) without removing the scanner from the checkstand. Additionally all cable connections made at the scanner can be connected and removed while the unit is sitting on the countertop.
Page 43: Power Installation
Power Installation Power Installation Reference the wiring diagram in Figure 2-6 for the recommended fusing arrangement. Grounding The AC/DC Power Supply should have an AC outlet with a clean earth ground. If you are not sure how to verify the amount of electrical noise (interference) on the power line, ask a qualified electrician to measure the input line voltage.
Page 44: Checkstand Preparation
Checkstand Preparation Reference Figure 2-7. When performing a first time installation into a new checkstand, verify before cutting that room will be allowed for cabling, the AC/DC Power Supply, and any EAS peripheral equipment (such as controller boxes, etc.). When making the opening, take extra care to accurately cut to the correct dimensions.
Page 45: Liquid Spills And Moisture
Counter Cutout Liquid Spills and Moisture Select a checkstand design which allows fluids to flow through, and directs liquids away from any electronic equipment or storage areas. Counter Cutout The most important consideration when planning the counter opening for the scanner is the operator’s comfortable reaching distance. The ideal, ergonomically sound installation allows items to be directed within easy reach, and a scanning area requiring no lifting or special orientation of items.
Page 46 3. Install the AC/DC Power Supply, the Remote Scale Display cable (if Remote Display is used) and the interface cable(s) observing the fol- lowing: Interface cables (and display cable, if applicable) should be routed away from all highly inductive electrical devices, like motors and conveyor belts, and even away from the unit’s power cable if possible.
Page 47 Counter Cutout Figure 2-8. Typical Checkstand Design & Cutout Location Remote Display Conveyor POS Terminal & Printer Optional Item Diverter Deadplate 6.3" (16.0cm) Scanner Keyboard Cash Drawer (Below Scanner) Scan & Bag Well (Optional) Check Writing Flush — Correct Stand Take-Away (Optional) Belt...
Page 48 Figure 2-9. Short Shelf Model 8301/8401 Cutout Dimensions Model 8301/8401 (Short) Max. Radius = 0.25" Minimum Cutout (0.635cm) 4x Dimensions 14.00" (35.6cm) min. 11.625" (29.53cm) min. Model 8301/8401 (Short) 4.08" (10.36cm) Supports Liquid Drainage Liquid Drainage Support Rails Figure 2-10. Short Shelf Model 8301/8401 Scanner Reference Dimensions Model 8301/8401 (Short) Scanner Reference Dimensions...
Page 49 Counter Cutout Figure 2-11. Medium Shelf Models 8302/8304/8402/8404 Cutout Dimensions Models 8302/8304/8402/8404 (Medium Shelf) Optional Leveling Feet Minimum Cutout Max. Radius = 0.25" Dimensions (0.635cm) 15.825" (40.2cm) min. 11.625" (29.53cm) min. 1.76" Leveling (4.47cm) Feet 6.89" (17.5cm) Models 8302/8304/8402/8404 (Medium Shelf) Supports 4.08"...
Page 50 Figure 2-13. Medium Flanged Models 8302/8304/8402/8404 Cutout Dimensions Models 8302/8304/8402/8404 (Medium Flanged) 18.00" (45.7cm) Minimum Cutout Dimensions 16.625" Rail Max. Radius = 0.25" (42.23cm) (0.635cm) 3.06" (7.77cm) 0.75" (1.905cm) 11.625" (29.53cm) (Center Line) Rail 3.06" If leveling feet are needed, 0.75"...
Page 51 Counter Cutout Figure 2-15. Long Shelf Models 8303/8305/8403/8405 Cutout Dimensions Models 8303/8305/8403/8405 (Long Shelf) Optional Leveling Feet Cutout Max. Radius = 0.25" (0.635cm) 17.87" (45.4cm) 11.625" (29.53cm) 1.76" Leveling (4.47cm) Feet 6.89" (17.5cm) Models 8303/8305/8403/8405 (Long Shelf) Supports 4.08" ( 10.36 cm) Shelf/ 10.83"...
Page 52 Figure 2-17. Long Flanged Models 8303/8305/8403/8405 Cutout Dimensions Model 8303/8305/8403/8405 (Long Flanged) Cutout 20.00" (50.8cm) Max. Radius = 0.25" 18.625" (0.635cm) 4x Rail (47.308cm) 3.06" (7.77cm) 0.75" (1.905cm) 11.625" (Center Line) (29.53cm) Rail 3.06" (7.77cm) 0.75" If leveling feet are needed, (1.905cm) use the placement shown here, 0.375"...
Page 53: Checkstand Mounting
Installation Overview Checkstand Mounting There are a number of things to take into account when installing the unit into a checkstand. Key factors are ergonomic/worker safety, loading capac- ity and stability. Consider the scanner or scanner/scale’s weight when cal- culating the robustness of construction needed to support it as well as maximum capacity of weighed and scanned items.
Page 54: Unpacking
6. Functional testing to verify operation when connected to the POS system. The following text describes each of these steps. Unpacking To unpack the unit: • Inspect the package for signs of damage that may have occurred dur- ing shipping. If damage is found, report it to your carrier immedi- ately.
Page 55: Operational Verification
Installation Overview Figure 2-19. Remove Protective Vinyl Protective vinyl MUST be removed from the platter before use. • Proceed to the Operational Verification instructions below. Operational Verification Follow these steps to ensure that your unit has arrived undamaged and is fully functional before installing it in the counter and connecting it to your POS system.
Page 56 When power is applied to the unit, the normal indicator sequence is: • The scanner indicator (top-most, green LED) will be lit (dim) steadily. • The 7-segment display will flash the number ‘8’. indicating initial- ization. • If the Selftest detects a problem, the 7-segment display will display a number code.
Page 57 Installation Overview Scanner — Pass UPC/EAN bar code labels in front of the scanner’s win- dows. Since the interface cable is not yet connected to the POS ter- minal, the scanner may be limited to reading only one or two labels (see the note that follows).
Page 58: Diagnostic Modes
Diagnostic Modes Two diagnostic modes are available which allow you to initiate scanner or scale diagnostic tests, as well as verify the scanner’s ability to read bar codes. Scanner Diagnostic Mode While in Scanner Diagnostic Mode, continuous scanning of labels is allowed, permitting the user to scan an unlimited number of bar codes while troubleshooting problems.
Page 59: Cables & Connections
Installation Overview Scale Diagnostic Mode To enter Scale Diagnostic Mode, press the Scale Zero Push Button for approximately four seconds. Six rapid tones will be sounded, indicating the unit is leaving normal operation and entering Scale Diagnostic Mode. The Remote Display will flash a ‘1’ across the display while the dignostic routine is being run.
Page 60 Figure 2-20. Cable Routing POS Terminal, Printer & Cash Drawer Keyboard Remote Display Scanner AC Power Switch Remote Scale (recommended) Display Cable Scanner (optional Interface AC/DC Scanner/Scale) Cable Power Supply Scale Interface Cable (Scanner/Scale) AC Power Optional To EAS System 2-28 ®...
Page 61: Remote Scale Display Placement/Installation
Remote Scale Display Placement/Installation Figure 2-21 provides physical dimensions for the AC/DC Adapter (part number 8-0582). Figure 2-21. Physical Measurements: AC/DC Adapter 1.23" (3.1 cm) Remote Scale Display Placement/Installation The modular Remote Display is designed so that single display heads can be stacked to form a dual display as shown in 2-22a in order to Figure...
Page 62: Viewing Angle
Viewing Angle The optimum display angle is directly facing the viewer. Tilt and rotatioin adjustments can be made as shown in Figure 2-22b. To ensure that dis- plays are easily readable for customers/cashiers of average height, display heads should be between 48” to 60” (122 to 152 cm) from the floor. Check with local Weights and Measures authorities regarding proper posi- tioning of scale displays used in retail trade.
Page 63: Remote Display Cabling
Remote Scale Display Placement/Installation Remote Display Cabling Your installation should also take into account the routing of Remote Dis- play cabling. Ensure that distance and obstacles spanned by the routed cable will not kink, pinch or stretch it. Also keep in mind you may need to drill a hole through which to route it.
Page 64 Figure 2-23. Physical Measurements: Remote Display 18.5mm Dual Display Single Display 28.4mm 60mm 60mm 112mm 112mm 329mm 264mm 292.5mm 325mm 227.5mm 116.39mm 116.39mm 25.5mm 41.99mm 85.1mm 5. Feed the entire length of the Remote Scale Display interface cable through the cable routing hole so that the assembled Remote Scale Display can be positioned over the mounting screw holes.
Page 65 Remote Scale Display Placement/Installation Figure 2-24. Remote Scale Display Mounting Mounting Example Dual Display Heads Single Display Head (optional cable routing) Figure 2-25. Remote Scale Display Mounting Template 116.39mm 41.99mm 85.1mm 25.5mm 2-33 Product Reference Guide...
Page 66: Changing Weighing Modes
Changing Weighing Modes Your scanner/scale has been programmed for weighing in either pounds or kilograms depending upon the initial operating environment that was specified when you ordered your scanner/scale. If you need to change from pounds to kilograms or vice-versa, call technical support. You can verify that the scale is set correctly for your country’s requirements by observing that the Remote Scale Display shows the appropriate mea- surement symbol (lb or kg) when the power-up Selftest is completed.
Page 67 Set-Up & Installation If you have a scanner with no scale, there will be only one interface cable to the POS terminal. 4. Connect the power cord to the scanner and route the other end down through the checkstand to the AC power outlet. DO NOT plug the power cord in at this time.
Page 68: Installation
Installation 1. Make sure that all cables are firmly attached (except that the AC/ DC power supply should not be connected to the AC outlet yet). Reference Figure 2-7 Figure 2-26. 2. Remove the platter to gain access to the interior lift handle. Grasp the platter in the positions shown in Figure 2-27 and gently lift it...
Page 69 Set-Up & Installation 3. Rotate the Interior Lift Handle up as shown in Figure 2-28 hook the fingers of both hands in the lift handles indicated. DO NOT attempt to lift the unit using the plastic edges, scale frame, or any features other than the lift handles.
Page 70: Adaptive Scale Platter Option
Adaptive Scale Platter Option Some Platters have been shipped with installed spacers on their undersides at all four corners. These specially-configured Platters are provided for customers wishing to add an adaptive scale to their unit at a later date. Until such time as the adaptive scale is installed, the four spacers should be left in place to ensure that the Platter rests evenly at its correct height when positioned on the scanner.
Page 71: System Power-Up Recap
System Power-Up Recap System Power-Up Recap The System Power-Up procedure may vary depending upon the require- ments of your POS system. It is generally a good practice to power-down (switch off ) all equipment prior to connecting cables. Check with your System Supervisor and/or refer to your POS terminal manual for proper power-down and power-up procedures and interface requirements when connecting any peripheral device.
Page 72 6. Power-up the scanner or scanner/scale by connecting the power cord to an AC power outlet. Wait for the unit to complete the Self test routine (10 seconds maximum). Successful scanner power-up is sig- nified by any or all of the following: - Facet wheel shows movement - Lasers turn on - Status LED(s) turn on...
Page 73: Chapter 3. Operation And Maintenance
Chapter 3 Operation and Maintenance The information contained in this chapter describes how to operate and maintain the scanner, and optional scale and EAS systems. Topics include “how to’s” on scanning, EAS label deactivation, weighing, re-zeroing the scale, removing the top cover and cleaning the upper and lower windows. Scanning Items To scan items using the scanner, slide or push them through the scan zone as shown in...
Page 74: Proper Scanning Technique
Figure 3-1. Scan Zone Note that eyes..indicate what the scanner "sees." Vertical Window Scan Zone Horizontal Window Scan Zone Checker Side Scan Zone Proper Scanning Technique The scanner was designed to provide the ultimate in ergonomic enhance- ments for Point-Of-Sale (POS) scanning. To take advantage of these advancements: Practice the techniques below to improve scanning efficiency: •...
Page 75: Deactivating Security Labels
• Develop efficient scanning motions, not necessarily faster hand movements. • Learn typical locations for bar codes on packages; avoid “flipping” or rotating the items during scanning. • Learn how the scanner functions and where the scanning area is located. Deactivating Security Labels EAS (Electronic Article Surveillance) labels can be detected and deacti- vated by a system equipped with this option.
Page 76: Proper Weighing Technique
Proper Weighing Technique 1. The L-shaped All-Weighs™ platter allows you to place items any- where on its surface, including leaning against its vertical section, to be weighed accurately. The “Produce Rail” or (when raised) the “Produce Bar” also provide a convenient way to ensure items do not rest on the counter or other non-weighing surfaces.
Page 77: Operational Controls
Operational Controls Operational Controls The function of scanner and scale controls and indicators is listed in Appendix A, LED/Beeper Indications & Controls. Turn to that appendix for full details. Operational Modes The scanner or scanner/scale features a number of modes that are impor- tant to both the user and the system support personnel.
Page 78: Error Reporting
Error Reporting If a fatal error is detected during Selftest or operation, the unit will not advance to Normal Operation Mode. Selftest diagnostics will cause the unit to sound a long, low tone and/or display an error message on the 7- segment display indicating where the failure occurred.
Page 79: Operating Mode
Operational Modes • When the scanner or scanner/scale completes its Selftest successfully, it emits a tone (when configured to do so) and enters Operating Mode. Operating Mode Operating Mode includes Normal Operation (scanning, EAS deactivation and weighing) and Sleep Mode. These two modes are most commonly observed by the user/operator.
Page 80: Additional Functions
Sleep Mode After the scanner has been left idle for a preset period of time, the laser and/or motor automatically turns off (goes to sleep). This state is called Sleep Mode, and is indicated by a “slow” blink of the green light (blinking at a 2-second rate).
Page 81: Scanner And Scale Reset
Additional Functions Scanner and Scale Reset The reset procedures and indicators are identical for scanner and scanner/ scale models. As with any electronic equipment, it is sometimes necessary to reset the electronics. The reset procedure allows you to initiate a reset command to the scanner.
Page 82 With the scanner/scale powered-up and at operating temperature: 1. Remove everything from the weighing surface of the scanner/scale. 2. Press the Scale Zero Push Button. (See Figure 1-1). 3. The Zero light will turn on and the display will show 0.00 lb (0.000 kg).
Page 83: Operational Maintenance
Operational Maintenance Operational Maintenance The scanner or scanner/scale will provide dependable service for many years. The following maintenance procedures will keep your scanner or scanner/scale operating at peak performance. Cleaning the Platter and Scan Windows Clean the exterior surfaces of the horizontal and vertical scan windows at least twice daily with a nonabra- sive, mild, water-based glass cleaner and paper towels or lint-free cleaning tissues.
Page 84: Vertical Scan Window Replacement
Vertical Scan Window Replacement The Vertical Scan Window is a replaceable part. Follow the instructions below to remove and replace a standard or L-Platter Vertical Scan Win- dow. Standard Vertical Scan Window Removal 1. Lift up on the vertical bezel as shown in Figure 3-3a and tilt its top up and away from the scanner as shown in...
Page 85 Operational Maintenance 4. Fully seat the new Vertical Scan Window into the window channel, engaging it within the retention tabs. Reference Figure 3-3d and Figure 3-3c. 5. Clean both sides of the new Vertical Scan Window using a paper towel or lint free cleaning tissues dampened with a mild, water- based glass cleaner.
Page 86 2. If the top edge of the platter is blocked, you may find it easier to use a coin to lift up an edge of the platter as shown in Figure 3-4b, then grasp the platter vertical bezel or other exposed edge. Use caution to avoid damage to the now exposed horizontal and Vertical Scan Windows.
Page 87: Horizontal Scan Window Replacement (Wrg)
Operational Maintenance Horizontal Scan Window Replacement (WRG) Wear Resistant Glass (WRG) horizontal scan windows are replaceable and can be removed and replaced following the instructions below. Sapphire glass does not require replacement, so it is permanently fastened in place. Do not attempt to remove Sapphire glass from the platter. NOTE 1.
Page 88 Figure 3-6. Removing/Replacing the WRG Window Window Retainer Window Platter Gasket Window 3-16 ® Magellan 8300/8400...
Page 89: Chapter 4. Problem Isolation
Chapter 4 Problem Isolation In the event of a suspected functional problem, use the troubleshooting references provided in this chapter. This useful information will help you to identify and resolve the cause of the problem. The scanner/scale has a number of features that indicate when a scanner or scale problem occurs.
Page 90: Diagnostic Procedures
Operational Tests These are the tests that run continually during Normal Operation and Sleep Mode. Firmware checks all subsystems, accessory connections and the POS interface to verify everything is operating normally. If a problem is detected at any time, a long, low tone is sounded, an error code is shown on the 7-segment display, and operation may be halted.
Page 91: Error Codes
Error Codes Error Codes If an error is detected, the scanner will sound a long low tone (for one sec- ond) and alternately flash its LEDs, indicating a failure. Following the long low tone, an error code will appear on the 7-segment display (refer to ).
Page 92 Table 4-1. Error Codes Error Probable Cause Corrective Action Code No POS interface has been selected (Null interface). See Chapter 6, Configuration Interface Type to select the required interface using programming Blinking bar codes. Chapter 6, Programming, for details about configuring the Configuration Error scanner using programming bar codes.
Page 93 Error Codes Figure 4-1. 7-Segment LED Display Vertical Window Seven-Segment Display Horizontal Window Product Reference Guide...
Page 94: Scale Error Reporting
Scale Error Reporting Scale diagnostics uses the Remote Scale Display and the Zero Status lamp to communicate specific scale failures. The following chart shows the Remote Display messages, the Scale Status lamp indication, the problem that the scale is experiencing and what action should be taken. When troubleshooting, always remember to check all cable connections first before proceeding with other problem isolation steps.
Page 95: Flowcharts
Flowcharts Remote Scale Status Problem Action Required Display Lamp Description - Check debris chutes. - Verify that the weigh platter moves Cannot zero at power- up or freely. weight remains on scale for - Remove item(s) from scale more than 2 minutes or - Press Scale Zero Push Button - 0 - weight has not returned to...
Page 96 Figure 4-2. Problem Isolation: Start For units using an AC/DC adapter, verify that... 1. AC power cord is connected to a functional AC outlet. 2. IEC connectors are firmly connected. 3. DC power cord is firmly connected to scanner. If your unit is a model which receives Power Off the START Terminal POT), verify that the I/F cable is securely Power-up...
Page 97 Flowcharts Figure 4-3. Problem Isolation: Selftest SELFTEST START Scan the Factory Does the Does the Does the Defaults bar code in 7-segment 7-segment 7-segment Section 6 to enable the display show display show display show default configuration file. Restart the unit. No interface selected (Null Interface).
Page 98 Figure 4-4. Problem Isolation: Poor/No Reading Have you verified that all scan windows are clean and scratch-free? POOR/NO READING Before proceeding, verify that START bar code samples presented to scanner are of good quality and a symbology the scanner Enter Scanner Diagnostic Mode by can read.
Page 99 Flowcharts Figure 4-5. Problem Isolation: No Transmit to POS NO TRANSMIT TO POS START Check the interface (I/F) Verify programmable cable connections. If parameters using the possible, retest the information and programming Does the system using a known- bar codes provided in Section scanner read DONE good I/F cable.
Page 100 Figure 4-6. Problem Isolation: Scale If this is a new installation, SCALE START make sure any foam packing pieces have been removed from the scale cavity before proceeding. Lift off the platter View the Remote to verify, then set the platter Call Tech Support Display and/or the back into position.
Page 101 Flowcharts Figure 4-7. Problem Isolation: Remote Display REMOTE DISPLAY Scanner-scale models that include a Remote Display when shipped START from the factory, are configured for use with the display. If you're unsure of the settings for your unit, contact Tech Support. Is the Use the programming bar unit configured...
Page 102 Figure 4-8. Problem Isolation: EAS System Before proceeding, verify the EAS NO EAS DEACTIVATION Antenna and associated equipment START have been correctly installed (ref. Chapter 2). Ensure operator has been trained in proper EAS system use (ref. Chapter 3). Verify programmable If possible, retest the Check all EAS parameters using the...
Page 103: Chapter 5. Calibration
Chapter 5 Calibration A number of situations require the scale to be calibrated. They are: • at initial installation of the scanner/scale • if the scale cannot be re-zeroed • if you change the weight measure from pounds to kilograms or vice- versa •...
Page 104: Description Of Calibration Sequence
Description of Calibration Sequence The Calibration Sequence sets the scale to an accurate reference point for weighing. This process involves the use of a Field Standard Weight Set (31.5-pounds) for calibration in pounds, (18.5-kilograms) for Metric. Once calibration has been successfully completed, the scanner/scale uses the certified weight as a reference for subsequent weighing activities.
Page 105: Motion Test
Motion Test • Lead/Wire or Paper Seal (as required by law). Motion Test This test verifies that the scale will not ‘zero’ when the weighing surface of the scanner/scale is in motion. 1. Verify that the Yellow LED is on and the Remote Display reads 0.00 pounds or 0.000 kilograms.
Page 106: Preparing The Scanner/Scale For Calibration
Preparing the Scanner/Scale for Calibration 1. Assure that the scanner/scale is stable, secure and properly installed. (Refer to , for instruc- Chapter 2, Site Preparation and Installation tions on the proper installation of the scanner/scale). 2. Power-up the scanner/scale. 3. Allow the unit to reach temperature equilibrium for at least one hour.
Page 107 Calibrating the Scale (Pounds & Kilograms) Figure 5-1. Calibration Switch Access Spider Calibration Switch 4. Press and release the Calibration Switch to place the scanner/scale in Calibration Mode. The scanner/scale will sound a tone indicating it is in Calibration Mode. If the motor was spinning when you initi- ated Calibration Mode, the motor will stop and the Yellow LED will begin flashing indicating the scale is in Calibration Mode.
Page 108 8. The Yellow LED will extinguish for approximately 10 seconds and the Remote Display will alternately display until the scale is ready to proceed. 9. If the calibration was successful, the speaker sounds a single tone, the Scale Status LED begins blinking again, and “End-” appears in the Remote Display.
Page 109: Calibration Verification (U.s. Pounds)
Calibration Verification (U.S. Pounds) Calibration Verification (U.S. Pounds) Once you have completed the calibration sequence, you may be required to perform these step-by-step verification procedures. These procedures follow the National Institute of Standards and Technology Handbook-44 guidelines for grocery scale installations. You may be required by state or local law to have these procedures performed by a certified technician or verified by a proper official.
Page 110: Shift Test
Shift Test The Shift Test checks to ensure that items placed anywhere on the weigh- ing surface of the scanner/scale are weighed properly. Refer to Figure 5-2 when performing this test. 1. Place and remove in succession, a fifteen-pound load on the center of each of the four quadrants (A, B, C, and D in Figure 5-2) of the scanner/scale’s weigh platter.
Page 111: Increasing- Load Test (Phase 2)
Calibration Verification (U.S. Pounds) Increasing- Load Test (Phase 2) After completing the Shift Test, you must complete the Increasing Load Test using 20.0, 25.0 and 30.0 pounds of weight. The upper limit of the scale is configurable according to POS interface type and may not necessarily be set at 30 pounds, which is the standard setting.
Page 112: Decreasing-Load Test
Decreasing-Load Test This test ensures that the scanner/scale responds properly when a heavy object is followed by a significantly smaller object. 1. Place a 30.0-pound load on the scale and verify that the display shows between 29.99 and 30.01 pounds. If the upper weight limit for your scale is not set at 30 pounds, begin by plac- ing weight equaling your upper limit setting.
Page 113: Calibration Verification (Kilograms)
Calibration Verification (Kilograms) Calibration Verification (Kilograms) Once you have completed the calibration sequence, you may be required to perform these step-by-step verification procedures. These procedures follow the National Institute of Standards and Technology Handbook-44 guidelines for grocery scale installations. You may be required by state or local law to have these procedures performed by a certified technician or verified by a proper official.
Page 114: Shift Test (Metric)
8. Place an additional 200 grams on the center of the weighing surface and check that the display reads 1.000 kg. 9. Increase the weight on the scale to 7.50 kg on the center of the weighing surface and check that the display reads between 7.495 and 7.505 kg.
Page 115: Increasing- Load Test (Phase 2)
Calibration Verification (Kilograms) Figure 5-3. European Shift Test (Metric) CENTER Increasing- Load Test (Phase 2) After completing the Shift Test, you must complete the Increasing Load Test using 10.00, 12.50 and 15 kilograms of weight. The upper limit of the scale is configurable according to POS interface type and may not necessarily be set at 15 kilograms, which is the standard setting.
Page 116: Blanking Test
5. You have completed phase two of the increasing load test. Blanking Test This test ensures that the scanner/scale will indicate its weighing capability has been exceeded if a weight greater than 0.82 over its maximum upper weight limit is placed upon the unit. 1.
Page 117: Decreasing-Load Test
Calibration Verification (Kilograms) Decreasing-Load Test This test ensures that the scanner/scale responds properly when a heavy object is followed by a significantly smaller object. 1. Place weights that total 15.8 kilograms. If the upper weight limit for your scale is not set at 15 kilograms, begin by placing weight equaling your upper limit setting plus 0.8 kilograms.
Page 118 NOTES 5-16 ® Magellan 8300/8400...
Page 119: Chapter 6. Programming
Chapter 6 Programming Introduction to Label Programming The programming bar code labels contained in this manual will allow you to customize and configure features and settings for your scanner (scan- ner/scale). To ensure full compatibility and proper function, use only the programming bar codes in this manual and other product-specific publi- cations to program scanner features.
Page 120: Integrating The Scanner With Your Host System
Integrating the Scanner With Your Host System Your scanner MUST be equipped with the correct hardware (interface board, cable, etc.) to properly communicate with your host system. Con- tact your dealer for information if you have questions about your scanner’s hardware compatibility.
Page 121 Integrating the Scanner With Your Host Sys- • — are the mandatory settings necessary Interface Related Features to allow communication with your host terminal. Examples of these settings are: RS-232 baud rate and parity. It is possible, via programming bar codes, to change the interface type (for example: from RS-232 to IBM Port 17).
Page 122: Programming Overview
The scanner can also accept programming via its auxilliary port using a handheld scanning device. Eligible handheld devices must have the ability to transmit Code 128 function codes such as the programming bar codes ® presented in this manual. Datalogic models QuickScan 1000 and ® QuickScan 6000 support this functionality.
Page 123: What Is Programming Mode
Programming Overview What Is Programming Mode? Programming Mode is a state in which the scanner must be placed in order to accept commands via programming bar code labels. When pro- gramming using the bar code labels in this manual, the scanner is typically placed in Programming Mode by scanning the SWITCH label.
Page 124: Programming Session
Programming Session A typical programming session is conducted as follows: 1. Scan the SWITCH bar code to place the scanner in Programming Mode. Depending upon its current programming, the scanner may emit a beep or beeps, indicating it has read the bar code and the scanner (top) green LED will flash on and off slowly while the scan- ner remains in Programming Mode.
Page 125 Programming Overview It is recommended that programming sessions be limited to one feature at a time. Should you make a mistake in the programming sequence, it can be difficult to discover where an error has been made if several features are pro- grammed at once.
Page 126: Programming Sequence
Programming Sequence To modify a scanner feature (item), the programming bar codes contained in this manual must be scanned in a given sequence depending upon the feature being programmed (as shown in ). There are three possi- Table 6-1 ble programming sequences: If the scanner’s interface type must be changed, always be sure that interface configuration is the FIRST item scanned during a programming session.
Page 127 Programming Overview Table 6-1. Programming Sequence ITEM TAG ITEM VALUE END/RESET ENABLE NEW FEATURE SWITCH SWITCH 3 4 5 ENABLE NEW FEATURE USING THE FOLLOWING SETTINGS... SWITCH SWITCH ONE BAR CODE CONTAINS SWITCH + ITEM TAG + ITEM VALUE + SWITCH Product Reference Guide...
Page 128: Led And Beeper Indicators
LED and Beeper Indicators The scanner provides a set of indicators that verify/announce the various scanner functions. If You Make a Mistake... If, during a programming session, you find that you are unsure of the scanner’s settings or wish to reset the scanner’s configuration, use the Return to Factory Settings label below to return the scanner’s configura- tion to the factory settings.
Page 129: Test Mode
If You Make a Mistake... Test Mode Use this feature to place the scanner into a testing, or “demo” mode. This special mode disables the scanner interface, meaning that bar code data is not sent out to the host via the scanner interface. This allows the bar code to be scanned continuously without requiring a response from the POS terminal.
Page 130: General Scanner Features
General Scanner Features Scanner Button Options Allows configuration of the scanner (volume) button to different modes of operation. • Disable Scanner Button — Disables all button functions • Enable Standard Functions — Enables volume, tone, and reset. • Enable Reset Only — The button’s sole function will be to reset the scanner.
Page 131 General Scanner Features Scanner Button Options — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCANNER BUTTON OPTIONS = ENABLE STANDARD FUNCTIONS SCANNER BUTTON OPTIONS = ENABLE RESET ONLY 6-13 Product Reference Guide...
Page 132: Double Read Timeout
Double Read Timeout The Double Read Timeout feature sets a time limit that determines how much time must pass before reading the same label again (e.g. two identi- cal items in succession). To set the Double Read Timeout: 1. Scan the SWITCH bar code. 2.
Page 133 General Scanner Features Double Read Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. DOUBLE READ TIMEOUT = 800ms DOUBLE READ TIMEOUT = 1 SECOND 6-15 Product Reference Guide...
Page 134: Laser Timeout
Laser Timeout The laser timeout feature sets the time for switching the visible laser diodes (VLDs) off if the scanner is idle. Using this feature can prolong the life of the VLDs. To set the Laser Timeout: 1. Scan the SWITCH bar code. 2.
Page 135 General Scanner Features Laser Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LASER TIMEOUT = 10 MINUTES LASER TIMEOUT = 15 MINUTES 6-17 Product Reference Guide...
Page 136: Motor Timeout
Motor Timeout The Motor Timeout feature sets the time for automatically switching the motor off when the scanner is not in use. Laser safety requires that the laser switch off before the motor. If you set the motor timeout shorter than the laser timeout, the motor and the laser will both shut off when the motor timeout expires.
Page 137 General Scanner Features Motor Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. MOTOR TIMEOUT = 10 MINUTES MOTOR TIMEOUT = 15 MINUTES 6-19 Product Reference Guide...
Page 138 Motor Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. MOTOR TIMEOUT = 30 MINUTES MOTOR TIMEOUT = 60 MINUTES 6-20 ®...
Page 139: Label Gone Timeout
General Scanner Features Label Gone Timeout Specifies the amount of time that data segments are stored by the software before being discarded if a label has not been successfully decoded during the current “label in volume session,” which is defined as the time between when the label gone time is first started until the label gone timer expires.
Page 140 Label Gone Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LABEL GONE TIMEOUT = 160 mS LABEL GONE TIMEOUT = 250 mS 6-22 ®...
Page 141 General Scanner Features Label Gone Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LABEL GONE TIMEOUT = 500 mS LABEL GONE TIMEOUT = 1 Second 6-23 Product Reference Guide...
Page 142: Auxiliary Port Mode
(only one option can be active at a time). • Disabled — Port is inactive ® • External Handheld Input — Supports Datalogic handheld scan- ners (QuickScan 1000, QuickScan 6000, PowerScan) as well as ® other models such as the Symbol HotShot. Call your dealer for more information about supported devices.
Page 143 General Scanner Features Auxiliary Port Mode — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. AUXILIARY PORT MODE = EXTERNAL HANDHELD INPUT AUXILIARY PORT MODE = PIR/CT 6-25 Product Reference Guide...
Page 144: Auxiliary Port Baud Rate
Auxiliary Port Baud Rate Specifies the baud rate of the auxillary port when operating in PIR/CT mode. PIR/CT is a value-added feature which may not have been activated on your model. NOTE To specify the Auxiliary Port Baud Rate: 1. Scan the SWITCH bar code. 2.
Page 145 General Scanner Features Auxiliary Port Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 4800 RS-232 BAUD RATE = 9600 6-27 Product Reference Guide...
Page 146 Auxiliary Port Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 19200 RS-232 BAUD RATE = 38400 6-28 ®...
Page 147 General Scanner Features Auxiliary Port Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 57600 RS-232 BAUD RATE = 115200 6-29 Product Reference Guide...
Page 148: Laser Failure Mode
Laser Failure Mode This configuration item selects whether the scanner should continue oper- ating if only one laser is functional. (The scanner has two lasers: One for the horizontal window, and one for the vertical window.) Options for this feature are: •...
Page 149: Productivity Index Reporting (Pir)/Cashier Training (Ct)
General Scanner Features Productivity Index Reporting (PIR)/Cashier Training (CT) When PIR/CT is enabled, label quality data is appended to decoded data before being presented to the POS. The PIR feature allows the scanner to provide information to an external computer indicating how easy the label was to read.
Page 150: Indication Features
Indication Features Green LED Idle State This feature specifies the state of the green scanner LED when the scanner is idle and ready to read a label. Options are: • • On dim To set the LED Idle State: 1. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 151: Power-Up Beep Control
Indication Features Power-up Beep Control Specifies the type of audible indication that is made when entering scan- ner-active mode on power-up. Choices are: • No beep • One beep • Three beeps To set the Power-up Beep: 1. Scan the SWITCH bar code. 2.
Page 152: Good Read Beep Control
Good Read Beep Control This feature enables/disables scanner beep upon successfully decoding of a label. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the two bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 153: Good Read Beep Frequency
Indication Features Good Read Beep Frequency Adjusts the scanner’s good read beep to sound at low, medium, or high fre- quency (controls the beeper’s pitch/tone). • Low = 660 Hz • Medium = 860 Hz • High = 1050 Hz To set the Good Read Beep Frequency: 1.
Page 154 Good Read Beep Frequency — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ BEEP FREQUENCY = MEDIUM GOOD READ BEEP FREQUENCY = HIGH 6-36 ®...
Page 155: Good Read Beep Length
Indication Features Good Read Beep Length Specifies the duration of a good read beep. To set the good read beep length: 1. Scan the SWITCH bar code. 2. Scan the bar code, . You’ll need SET GOOD READ BEEP LENGTH to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 156: Good Read Beep Volume
Good Read Beep Volume Selects the beeper volume upon a good read beep. There are five selectable volumes, with each volume increment adding approximately five decibels to the previous level: • 0 = Lowest Volume • 1 = Medium-Low Volume •...
Page 157 Indication Features Good Read Beep Volume — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ BEEP VOLUME = MEDIUM LOW GOOD READ BEEP VOLUME = MEDIUM 6-39 Product Reference Guide...
Page 158 Good Read Beep Volume — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ BEEP VOLUME = HIGHEST 6-40 ®...
Page 159: Good Read When To Indicate
Indication Features Good Read When to Indicate This feature specifies when the scanner will provide indication (beep and/ or flash its green LED) upon successfully reading a bar code. • Good Read = Indicate after decode • Good Read = Indicate after transmit •...
Page 160 Good Read When to Indicate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ = INDICATE AFTER TRANSMIT GOOD READ = INDICATE AFTER CTS GOES INACTIVE, THEN ACTIVE (RS-232 ONLY) 6-42...
Page 161: Scale Features
Scale Features Scale Features Scale Enable Use this feature to enable or disable scale operation. Recalibration/recertification may be required when adding scale functional- ity. Consult your local Weights and Measures authority. If this feature is enabled the scanner will expect that it is to function as a scanner-scale, and will indicate an error if it is not a scale-equipped unit.
Page 162: Scale Country Mode
Scale Country Mode When a weight is presented, the scanner/scale will apply the country-spe- cific weighing rules specified via this feature. Scale Country Mode applies only when a scale is enabled. RS-232 SASI scale interface supports only U.S.A. mode. NOTE SCALE COUNTRY MODE = U.S.A.
Page 163 Scale Features Scale Country Mode — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE COUNTRY MODE = AUSTRALIA 6-45 Product Reference Guide...
Page 164: Scale Enforced Zero Return
Scale Enforced Zero Return This feature enables/disables the enforced zero return of the scale. Three settings are available for this feature: • Disable • Scale Must Return to Zero Weight Within Two Minutes — Scale will require re-zeroing if a non-zero weight is left on for more than two minutes or if the scale is below zero.
Page 165 Scale Features Scale Enforced Zero Return — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE ENFORCED ZERO RETURN = NON-ZERO FOR 2 MINUTES OR BELOW ZERO SCALE ENFORCED ZERO RETURN = NON-ZERO FOR 2 MINUTES OR BELOW ZERO OR NO ZERO BETWEEN WEIGHTS...
Page 166 Scale Enforced Zero Return — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE ENFORCED ZERO RETURN = NON-ZERO FOR 2 MINUTES 6-48 ®...
Page 167: Scale Interface Type
Scale Features Scale Interface Type Use this feature to select the scale interface type. Choices are: • No Scale Interface • RS-232 — SASI • RS-232 — ICL To set the Scale Interface Type: 1. Scan the SWITCH bar code. 2.
Page 168 Scale Interface Type — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE INTERFACE TYPE = RS-232 — ICL 6-50 ®...
Page 169: Scale Motion Level Filter
Scale Features Scale Motion Level Filter In environments where checkstands generate excessive vibration, the scale can be set to filter a certain amount of the motion with regard to its oper- ation. This filter is generally used only in applications where scale error E_1 (too much motion at power-up) has occurred.
Page 170 Scale Motion Level Filter — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE MOTION LEVEL FILTER = MEDIUM HIGH SCALE MOTION LEVEL FILTER = HIGH 6-52 ®...
Page 171: Scale Warm-Up Time
Scale Features Scale Warm-up Time Specifies the amount of time after entering scale warm-up mode before the scale enters scale-active mode. Applies only when Scale Enable is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. 3.
Page 172 Scale Warm-up Time — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCALE WARM-UP TIME = 10 SECONDS SCALE WARM-UP TIME = 15 SECONDS 6-54 ®...
Page 173: Scale Led Enable
Scale Features Scale LED Enable This feature enables/disables Scale LED (Yellow LED) operation. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the two bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 174: Scale Diagnostics Mode Enable
Scale Diagnostics Mode Enable Enables/disables the ability for the operator to initiate scale diagnostics. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the two bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 175: Scale Calibration Notification
Scale Features Scale Calibration Notification When enabled, this feature allows the host to be notified of a calibration event. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the two bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 176: Scale Intercharacter Delay
Scale Intercharacter Delay Sets the delay between the end of one character and the beginning of the next, in 10 millisecond increments. To specify the intercharacter delay: 1. Scan the SWITCH bar code. 2. Scan the bar code below, SET KEYBOARD WEDGE INTERCHAR- .
Page 177: Remote Display - Enable/Disable
Scale Features Remote Display — Enable/Disable The scanner-scale can be configured to operate with or without a Remote Display. Recalibration/recertification may be required when adding a Remote Display. Consult your local Weights and Measures authority. If this feature is enabled the scanner-scale will expect that it is connected to NOTE a Remote Display, and will indicate an error if one is not.
Page 178: Eas Features
EAS Features EAS Active State Specifies the active state polarity of EAS (Electronic Article Survellance); the inactive state is its opposite polarity. EAS output goes active during the good read indication of a bar code, allowing the EAS device to deactivate a tag on the product.
Page 179: Eas Timeout
EAS Features EAS Timeout Specifies the amount of time that an EAS (Electronic Article Survellance) signal is held in its active state for a good read indication. To set the EAS Timeout: 1. Scan the SWITCH bar code. 2. Scan the bar code, below.
Page 180: Interface Related Features
Interface Related Features Interface Type Specifies the current scanner interface. Selections are: INTERFACE (I/F) TYPE INTERFACE (I/F) TYPE I/F I.D. NUMBER I/F I.D. NUMBER RS-232 Standard Keyboard Wedge A RS-232 Wincor-Nixdorf Keyboard Wedge B RS-232 Single Cable Keyboard Wedge C IBM USB Keyboard Wedge D Port 17...
Page 181 Interface Related Features Interface Type — continued A new scanner may have been shipped from the factory with a Null Interface (no interface type selected) to ensure system compatibility at installation. In this case, the correct Interface Type programming bar code must be scanned first before the scanner can be used with a POS system.
Page 182 Interface Type — continued 4. Complete the programming sequence by scanning the SWITCH bar code. Once the correct interface has been set, it will be necessary to proceed to the appropriate pages in this manual that select parameters and options for that interface.
Page 183 Interface Related Features RS-232 Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 184 RS-232 Wincor-Nixdorf Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 185 Interface Related Features RS-232 Single Cable Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 186: Ibm Usb Interface Selection
IBM USB Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 187: Ibm Port 17 Interface Selection
Interface Related Features IBM Port 17 Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 188 IBM Port 5B Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 189 Interface Related Features IBM Port 9B Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 190 USB Keyboard Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 191 Interface Related Features Keyboard Wedge A Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 192 Keyboard Wedge B Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 193 Interface Related Features Keyboard Wedge C Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 194 Keyboard Wedge D Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 195 Interface Related Features Keyboard Wedge E Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 196 Keyboard Wedge F Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 197 Interface Related Features Keyboard Wedge G Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 198 Keyboard Wedge H Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 199 Interface Related Features Keyboard Wedge I Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 200 Keyboard Wedge J Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempting to change to an incompatible interface.
Page 201 Interface Related Features Maximum Host-Transmitted Message Length Specifies the maximum number of data characters allowed in messages transmitted to the host. To set the Maximum Host-Transmitted Message Length: 1. Scan the SWITCH bar code. 2. Scan the bar code, SET MAXIMUM HOST-TRANSMITTED MES- below.
Page 202: Number Of Host Transmission Buffers
Number of Host Transmission Buffers Specifies the number of host transmission(s) that may be buffered. By buffering data from a bar code, the scanner can continue to read a new bar code while the old one is being transmitted to the host. Selecting BUFF- ERS = 1 means that the first bar code must be transmitted before a new one can be read.
Page 203: Aim Id
Interface Related Features AIM ID AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. AIM label identifiers consist of three characters as follows: • A close brace character (ASCII ‘]’), followed by... •...
Page 204 AIM ID — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. AIM ID: DISABLE AIM ID: ENABLE 6-86 ® Magellan 8300/8400...
Page 205: Label Id Control
Interface Related Features Label ID Control A Label ID is a customizable code of up to two ASCII characters (00-FF), used to identify a bar code (symbology) type, available for all except IBM interfaces. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled.
Page 206 Figure 6-2. Label ID Position Options SCANNER Prefix Label ID Aim ID Bar Code Data Label ID Suffix Label ID Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LABEL ID TRANSMISSION: DISABLE LABEL ID TRANSMISSION: BEFORE BAR CODE DATA 6-88...
Page 207 Interface Related Features Label ID Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LABEL ID TRANSMISSION: AFTER BAR CODE DATA 6-89 Product Reference Guide...
Page 208: Global Prefix
Global Prefix This feature specifies the prefix that is added to beginning of label trans- mission. To specify the Global Prefix Character(s): 1. Scan the SWITCH bar code. 2. Scan the bar code, below. You’ll need to SET GLOBAL PREFIX cover any unused bar codes to ensure the scanner reads only the bar code you intend to scan.
Page 209 Interface Related Features Global Prefix — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SET GLOBAL PREFIX TERMINATE SEQUENCE 6-91 Product Reference Guide...
Page 210: Global Suffix
Global Suffix This feature specifies the suffix that is added to end of a label transmis- sion. Three standard options are available below. Contact your dealer for other alternate settings for this feature. • No Global Suffix • CR — Carriage Return •...
Page 211 Interface Related Features Global Suffix — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GLOBAL SUFFIX = CR GLOBAL SUFFIX = CR LF 6-93 Product Reference Guide...
Page 212: Case Conversion
Case Conversion Changes the case of all alphabetic characters to upper or lower case. Choices are: • No case conversion • Upper case • Lower case To configure this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the case conversion bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 213 Interface Related Features Case Conversion — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CASE CONVERSION = UPPER CASE CASE CONVERSION = LOWER CASE 6-95 Product Reference Guide...
Page 214: Ibm Features
IBM Features IBM Interface Options IBM interfaces offer specific control over interaction with certain devices. The IBM USB interface provides its own set of options. Refer to the feature, IBM USB Scanner Device Type, in this chapter. NOTE Options for this feature are as follows: •...
Page 215: Ibm Number Of Host Resets
IBM Features IBM Number of Host Resets Specifies how many consecutive resets are processed before the scanner starts a five-second period during which a user is allowed to enter label- programming mode and configure the scanner. To set the number of host resets: 1.
Page 216: Ibm Scale Address
IBM Scale Address This feature applies to IBM Port 17 ONLY. NOTE Specifies IBM scale address for IBM Port 17. The following three addresses are available: • • • To set the IBM Scale Address: 1. Scan the SWITCH bar code. 2.
Page 217 IBM Features IBM Scale Address — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. IBM SCALE ADDRESS = 6B IBM SCALE ADDRESS = 6E 6-99 Product Reference Guide...
Page 218: Ibm Transmit Labels In Code 39 Format
IBM Transmit Labels in Code 39 Format This feature enables/disables scanner's ability to set a symbology identifier for a specified label to Code 39 before transmitting that label data to an IBM host. This applies to: Code 128, Code 93 and Codabar for IBM Port 5B;...
Page 219: Ibm Label Slicing Control
IBM Features IBM Label Slicing Control Enables/disables the slicing of IBM-46XX host transmission data into multiple pieces when a label is longer than the length specified by Maximum Label Slice Length Options are: • Disable Label Slicing — Send data to host in one piece. •...
Page 220: Ibm Maximum Label Slice Length
IBM Maximum Label Slice Length Specifies the maximum allowable length of host transmit data in each sliced frame. is enabled. This setting only applies when IBM Label Slicing Control NOTE 1. Scan the SWITCH bar code. 2. Scan the bar code below, SET IBM MAXIMUM LABEL SLICE .
Page 221: Ibm Usb Scanner Device Type
IBM Features IBM USB Scanner Device Type The IBM-USB protocol allows for the scanner to be identified as one of two different types of barcode scanners. Depending on what other scan- ners you may already have connected to a USB POS, you may need to change this setting to enable all scanners to communicate.
Page 222: Features
RS-232 Features RS-232 Baud Rate This feature selects the baud rate required for sending and receiving data. Single cable interfaces are limited to Baud Rate selections up to 19200. They cannot communicate at Baud Rates of 38400 and up. NOTE To specify the RS-232 Baud Rate: 1.
Page 223 RS-232 Features RS-232 Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 4800 RS-232 BAUD RATE = 9600 6-105 Product Reference Guide...
Page 224 RS-232 Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 19200 RS-232 BAUD RATE = 38400 6-106 ®...
Page 225 RS-232 Features RS-232 Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 57600 RS-232 BAUD RATE = 115200 6-107 Product Reference Guide...
Page 226: Number Of Data Bits
RS-232 Number of Data Bits Specifies number of data bits required for sending and receiving data. 8 data bits with 2 stop bits and parity enabled is not a valid configuration. NOTE To set this feature: 1. Scan the SWITCH bar code. 2.
Page 227: Number Of Stop Bits
RS-232 Features RS-232 Number of Stop Bits Specifies number of stop bits required for sending and receiving data. 8 data bits with 2 stop bits and parity enabled is not a valid configuration. NOTE To set this feature: 1. Scan the SWITCH bar code. 2.
Page 228: Parity
RS-232 Parity Specifies parity required for sending and receiving data. 8 data bits with 2 stop bits and parity enabled is not a valid configuration. NOTE Options for this setting are: • RS-232 PARITY = NONE • RS-232 PARITY = EVEN •...
Page 229 RS-232 Features RS-232 Parity — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 PARITY = EVEN RS-232 PARITY = ODD 6-111 Product Reference Guide...
Page 230: Hardware Control
RS-232 Hardware Control Enables/disables use of the RS-232 CTS signal for flow control and/or scan control. Options are: • Disable — The scanner transmits to the host regardless of any activ- ity on the CTS line. • Enable CTS Flow Control — The CTS signal controls transmission of data to the host.
Page 231 RS-232 Features RS-232 Hardware Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 HARDWARE CONTROL = ENABLE CTS FLOW CONTROL RS-232 HARDWARE CONTROL = ENABLE CTS SCAN CONTROL 6-113 Product Reference Guide...
Page 232 RS-232 Hardware Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 HARDWARE CONTROL = ENABLE MGL SL CTS SCAN CONTROL 6-114 ®...
Page 233: Intercharacter Delay
RS-232 Features RS-232 Intercharacter Delay Specifies delay between the end of one character and the beginning of the next in 10-millisecond increments. To set the RS-232 Intercharacter Delay: 1. Scan the SWITCH bar code. 2. Scan the bar code below, SET RS-232 INTERCHARACTER .
Page 234: Software Flow Control
RS-232 Software Flow Control Enables/disables RS-232 Flow Control using XON/ XOFF characters. . This item will be ignored when the feature, RS-232 NAK Character, is enabled NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 235: Host Echo
RS-232 Features RS-232 Host Echo When enabled, this feature passes all data through the scanner to the host as it comes in. This feature is used for applications where “daisy chaining” of RS-232 devices onto the same cable is necessary. If, for example, one of the devices in the chain is a terminal where someone is entering data while another person is simultaneously scanning a bar code requiring transmis- sion to the host, the scanner will wait for the RS-232 channel to be quiet...
Page 236: Host Echo Quiet Interval
RS-232 Host Echo Quiet Interval This setting specifies the time interval of RS-232 channel inactivity which must transpire before the scanner will break the host echo loop to transmit the bar code data that has just been scanned to the host. •...
Page 237: Ignore Host Commands
RS-232 Features RS-232 Ignore Host Commands When set to ignore host commands, the scanner will ignore all host com- mands except for the minimum set necessary to keep the interface active, transmit labels, and transmit scale information. For normal operation of the interface, disable this feature.
Page 238: Ttl
RS-232 TTL Specifies whether RS-232 interface provides TTL levels on the output pins TxD and RTS. Choices are: • Normal RS-232 levels • TTL levels To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below which represents the desired setting for this feature.
Page 239: Ttl Invert
RS-232 Features RS-232 TTL Invert Enables/disables inversion of TTL. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below which represents the desired setting for this feature. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 240: Icl Dc1 Character Delay Enable
RS-232 ICL DC1 Character Delay Enable Enables/disables the ability of the scanner to delay a DC1 response for 40 milliseconds. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below which represents the desired setting for this feature.
Page 241: Team Pos Icl Scale
RS-232 Features RS-232 Team POS ICL Scale Enables/disables the ability of the scanner to enter TEAM POS ICL Scale mode. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below which represents the desired setting for this feature.
Page 242: Beep On Ascii Bel
RS-232 Beep on ASCII BEL Enables/disables ability of scanner to beep (sound a good read tone) on receiving an ASCII BEL (07 hex). • Disable • Enable To enable/disable this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 243: Beep After Weigh
RS-232 Features RS-232 Beep After Weigh Enables/disables the ability of the scanner to beep after weight data is transmitted to the host. Scale interfaces that support this item are: RS-232 ICL, RS-232 SASI, and RS-232 Single Cable. To enable/disable the Beep After Weigh feature: 1.
Page 244: Beep On Not On File
RS-232 Beep on Not on File Select for the host to beep (or not) when a not-on-file condition is detected by the host. This feature is also applicable to single cable RS-232. RS-232 BEEP ON NOT ON FILE = DISABLE RS-232 BEEP ON NOT ON FILE = ENABLE 6-126 ®...
Page 245: Ack Nak Enable
RS-232 Features RS-232 ACK NAK Enable This enables/disables the ability of the scanner to support the RS-232 ACK/NAK protocol. When configured, the scanner and/or host sends an “ACK” when it receives data properly, and sends “NAK” when the data is in error.
Page 246 RS-232 ACK NAK Enable — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 ACK/NAK = HOST ACKNOWLEDGEMENT RS-232 ACK/NAK = LABEL & HOST 6-128 ®...
Page 247: Ack Character
RS-232 Features RS-232 ACK Character This feature specifies which ASCII character will be used as an ACK char- acter. DO NOT set this feature to use previously defined characters such as XON, XOFF or host commands as this will conflict with normal operation of these characters.
Page 248: Nak Character
RS-232 NAK Character This feature specifies which ASCII character will be used as a NAK char- acter. DO NOT set this feature to use previously defined characters such as XON, XOFF or host commands as this will conflict with normal operation of these characters.
Page 249: Retry On Ack Nak Timeout
RS-232 Features RS-232 Retry on ACK NAK Timeout This option specifies the action scanner performs on expiration of the 232 ACK NAK Timeout Value To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 250: Ack Nak Timeout Value
RS-232 ACK NAK Timeout Value This item specifies the time the scanner will wait for an ACK character from the host following a label transmission. • 0 = Infinite timeout • 1 - 75 = Timeout in 200-millisecond increments To set the ACK NAK Timeout Value: 1.
Page 251: Ack Nak Retry Count
RS-232 Features RS-232 ACK NAK Retry Count This feature sets the number of times for the scanner to retry a label trans- mission under a retry condition. To set the RS-232 ACK NAK Retry Count: 1. Scan the SWITCH bar code. 2.
Page 252: Ack Nak Error Handling
RS-232 ACK NAK Error Handling This item specifies the method the scanner will use to handle errors detected while waiting to receive the ACK character from the host. Errors include unrecognized host commands and communication errors such as parity or framing errors. •...
Page 253 RS-232 Features RS-232 ACK NAK Error Handling — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 ACK NAK ERROR HANDLING = ASSUME ACK RS-232 ACK NAK ERROR HANDLING = ASSUME NAK 6-135 Product Reference Guide...
Page 254: Indicate Transmission Failure
RS-232 Indicate Transmission Failure Enables/disables an audible error indication upon a transmission failure. RS-232 INDICATE TRANSMISSION FAILURE = DISABLE RS-232 INDICATE TRANSMISSION FAILURE = ENABLE 6-136 ® Magellan 8300/8400...
Page 255: Single Cable Rs-232 Options
Single Cable RS-232 Options Single Cable RS-232 Options The RS-232 Single Cable interface shares some configuration options with other RS-232 interfaces. Rather than repeat them in this chapter as Single Cable options, please find them referenced as follows: • RS-232 Baud Rate on page 104 •...
Page 256: Single Cable Rs-232 Scanner Only Protocol
Single Cable RS-232 Scanner Only Protocol This sets the type of interface protocol that will be used in Single Cable RS-232. Options are: • Scanner/scale RS-232 protocol • Scanner only RS-232 protocol To set this feature: 1. Scan the SWITCH bar code. 2.
Page 257: Single Cable Rs-232 Stale Weight Timeout
Single Cable RS-232 Options Single Cable RS-232 Stale Weight Timeout Specifies the amount of time (in 10 msec increments) that scale data is presented to the host before being discarded. To set the Timeout: 1. Scan the SWITCH bar code. 2.
Page 258 Single Cable RS-232 Stale Weight Timeout — contin- Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. STALE WEIGHT TIMEOUT = 250 msec STALE WEIGHT TIMEOUT = 330 msec 6-140 ®...
Page 259: Single Cable Rs-232 Scale - Transmit Weight Digits
Single Cable RS-232 Options Single Cable RS-232 Scale — Transmit Weight Digits Specifies whether the scale transmits weight data as five digits or as four digits. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below representing the desired option. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 260: Single Cable Manufacturer Extensions
Single Cable Manufacturer Extensions Enables/Disables manufacturer extensions to the Single Cable RS-232 interface. These extensions communicate scale calibration information to the host. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 261: Single Cable Pacesetter Plus Enable
Single Cable RS-232 Options Single Cable Pacesetter Plus Enable Enables/disables the scanner’s ability to send Pacesetter Plus information as trailers to UPC/EAN label data. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 262: Single Cable Rs-232 Rts Cts Selection
Single Cable RS-232 RTS CTS Selection Specifies how RTS and CTS are used to control the data flow. RTS is con- trolled by the Scanner and can be continuously held high/low, or can be asserted during label transmission. The scanner looks at CTS, as the con- figuration values state, to determine when to send label data.
Page 263 Single Cable RS-232 Options Single Cable RS-232 RTS CTS Selection — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RTS CTS SELECTION = OPTION 2 RTS CTS SELECTION = OPTION 3 6-145 Product Reference Guide...
Page 264 Single Cable RS-232 RTS CTS Selection — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RTS CTS SELECTION = OPTION 4 RTS CTS SELECTION = OPTION 5 6-146 ®...
Page 265: Single Cable Rs-232 Use Bcc
Single Cable RS-232 Options Single Cable RS-232 Use BCC Enables/disables the ability of the scanner to use BCC. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 266: Single Cable Rs-232 Use Ack/Nak
Single Cable RS-232 Use ACK/NAK Enables/disables the ability of the scanner to use ACK/NAK. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 267: Single Cable Rs-232 Use Stx
Single Cable RS-232 Options Single Cable RS-232 Use STX Enables/disables the ability of the scanner to use STX. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 268: Set Single Cable Rs-232 Stx Character
Set Single Cable RS-232 STX Character This feature selects the STX character. To specify the STX Character: 1. Scan the SWITCH bar code. 2. Scan the bar code, SET SINGLE CABLE RS-232 STX CHARAC- below. You’ll need to cover any unused bar codes on this and the facing page to ensure the scanner reads only the bar code you intend to scan.
Page 269: Set Single Cable Rs-232 Etx Character
Single Cable RS-232 Options Set Single Cable RS-232 ETX Character Allows selection of the ETX character. To specify the ETX Character: 1. Scan the SWITCH bar code. 2. Scan the bar code, SET SINGLE CABLE RS-232 ETX CHARAC- below. You’ll need to cover any unused bar codes on this and the facing page to ensure the scanner reads only the bar code you intend to scan.
Page 270: Keyboard Wedge/Usb Keyboard Features
Keyboard Wedge/USB Keyboard Features Features listed in this section apply to both the Keyboard Wedge and USB Keyboard interfaces unless otherwise noted. Keyboard Interface — Keyboard Layout This feature specifies the country/language to be supported by the key- board. To set this feature: 1.
Page 271 Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = BRITAIN KEYBOARD LAYOUT = DENMARK 6-153 Product Reference Guide...
Page 272 Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = FRANCE KEYBOARD LAYOUT = GERMANY 6-154 ®...
Page 273 Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = ITALY KEYBOARD LAYOUT = NORWAY 6-155 Product Reference Guide...
Page 274 Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = PORTUGAL KEYBOARD LAYOUT = SPAIN 6-156 ®...
Page 275 Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = SWEDEN KEYBOARD LAYOUT = SWITZERLAND 6-157 Product Reference Guide...
Page 276 Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = JAPANESE 106 KEY KEYBOARD LAYOUT = HUNGARY 6-158 ®...
Page 277 Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = CZECH KEYBOARD LAYOUT = SLOVAKIA 6-159 Product Reference Guide...
Page 278 Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = ROMANIA KEYBOARD LAYOUT = CROATIA 6-160 ®...
Page 279: Keyboard Interface Quiet Interval
Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = POLAND Keyboard Interface Quiet Interval Specifies amount of time to look for keyboard activity before scanner breaks keyboard connection in order to transmit data to host.
Page 280: Keyboard Interface Caps Lock State
Keyboard Interface Caps Lock State Specifies the format in which the scanner sends character data.. Choices are: • CAPS LOCK OFF — send character data in normal format. • CAPS LOCK ON — send character data in reverse case. • SHIFT LOCK ON —...
Page 281 Keyboard Wedge/USB Keyboard Features Keyboard Interface Caps Lock State — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CAPS LOCK STATE = SHIFT LOCK ON CAPS LOCK STATE = CAPS LOCK COMPENSATION MODE 6-163 Product Reference Guide...
Page 282: Keyboard Interface - Keyboard Simulation
Keyboard Interface — Keyboard Simulation Enables/disables ability of scanner to perform host communications nor- mally performed by attached keyboard. This feature does not apply to the USB Keyboard interface. NOTE All PCs check the keyboard status during the power-on Selftest. It is rec- ommended that you enable this function if you are working without a keyboard installation.
Page 283: Keyboard Interface - Control Characters
Keyboard Wedge/USB Keyboard Features Keyboard Interface — Control Characters Specifies how the scanner transmits ASCII control characters to the host. This feature does not apply to the USB Keyboard interface. NOTE Choices are: • Disable Control Characters • Enable transmission of control characters to host •...
Page 284 Keyboard Interface — Control Characters — contin- Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CONTROL CHARACTERS = ENABLE TRANSMISSION OF CTL CHARACTERS CONTROL CHARACTERS = ENABLE FUNCTION KEY MAPPING 6-166 ®...
Page 285: Keyboard Interface - Intercharacter Delay
Keyboard Wedge/USB Keyboard Features Keyboard Interface — Intercharacter Delay Sets the delay between the end of one character and the beginning of the next, in 10 millisecond increments. To specify the intercharacter delay: 1. Scan the SWITCH bar code. 2. Scan the bar code below, SET KEYBOARD WEDGE INTERCHAR- .
Page 286: Symbology Programming
Symbology Programming If the scanner’s interface type must be changed, always be sure that inter- face configuration is the FIRST item scanned during a programming ses- sion. (Selecting an interface type resets ALL other configuration items — including symbology programming — to the factory default for that inter- NOTE face type.) Coupon Control...
Page 287 Symbology Programming Coupon Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. COUPON CONTROL = ENABLE UPC/EAN COUPON DECODING COUPON CONTROL = ENABLE DATABAR COUPON DECODING 6-169 Product Reference Guide...
Page 288: Upc-A Enable
UPC-A Enable Enables/disables the ability of the scanner to decode UPC-A labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 289: Upc-A Number System Character Transmission
UPC-A Enable UPC-A Number System Character Transmission Enables/disables transmission of a UPC-A number system character. This feature MUST be enabled for IBM interfaces for proper function. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 290: Upc-A Check Character Transmission
UPC-A Check Character Transmission Enables/disables transmission of a UPC-A check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 291: Expand Upc-A To Ean-13
UPC-A Enable Expand UPC-A to EAN-13 Enables/disables expansion of UPC-A labels to EAN/JAN-13. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 292: Upc-A Label Id
UPC-A Label ID This feature specifies a UPC-A label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 293: Upc-A 2-Digit Supplemental Label Id
UPC-A Enable UPC-A 2-Digit Supplemental Label ID This feature specifies a UPC-A 2-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 294: Upc-A 5-Digit Supplemental Label Id
UPC-A 5-Digit Supplemental Label ID This feature specifies a UPC-A 5-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 295: Upc-A 128 Supplemental Label Id
UPC-A Enable UPC-A 128 Supplemental Label ID This feature specifies a UPC-A 128 Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 296: Upc-A Minimum Reads
UPC-A Minimum Reads Specifies the minimum number of consecutive times a UPC-A label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 297 UPC-A Enable UPC-A Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC-A MINIMUM READS = 3 UPC-A MINIMUM READS = 4 6-179 Product Reference Guide...
Page 298: Upc-E Enable
UPC-E Enable Enables/disables the ability of the scanner to decode UPC-E labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 299: Upc-E Number System Character Transmission
UPC-E Enable UPC-E Number System Character Transmission Enables/disables transmission of a UPC-E number system character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 300: Upc-E Check Character Transmission
UPC-E Check Character Transmission Enables/disables transmission of a UPC-E check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 301: Expand Upc-E To Upc-A
UPC-E Enable Expand UPC-E to UPC-A Enables/disables expansion of UPC-E labels to UPC-A. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 302: Expand Upc-E To Ean-13
Expand UPC-E to EAN-13 Enables/disables expansion of UPC-E labels to EAN/JAN-13. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 303: Upc-E Label Id
UPC-E Enable UPC-E Label ID This feature specifies a UPC-E label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 304: Upc-E 2-Digit Supplemental Label Id
UPC-E 2-Digit Supplemental Label ID This feature specifies a UPC-E 2-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 305: Upc-E 5-Digit Supplemental Label Id
UPC-E Enable UPC-E 5-Digit Supplemental Label ID This feature specifies a UPC-E 5-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 306: Upc-E 128 Supplemental Label Id
UPC-E 128 Supplemental Label ID This feature specifies a UPC-E 128 Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 307: Upc-E Minimum Reads
UPC-E Enable UPC-E Minimum Reads Specifies the minimum number of consecutive times a UPC-E label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 308 UPC-E Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC-E MINIMUM READS = 3 UPC-E MINIMUM READS = 4 6-190 ®...
Page 309: Enable
EAN-13 Enable EAN-13 Enable Enables/disables the ability of the scanner to decode EAN/JAN-13 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 310: First Character Transmission
EAN-13 First Character Transmission Enables/disables transmission of EAN/JAN-13 first character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 311: Check Character Transmission
EAN-13 Enable EAN-13 Check Character Transmission Enables/disables transmission of an EAN/JAN-13 check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 312: Isbn Conversion Enable
EAN-13 ISBN Conversion Enable Enables/disables conversion of EAN/JAN-13 labels starting with 978 to Bookland ISBN labels. If any add-on information is present on the label prior to the conversion to ISBN, the add-on data will be discarded. Only the base label will be con- verted.
Page 313: Ean 13 Label Id
EAN-13 Enable EAN 13 Label ID This feature specifies an EAN 13 label ID to be added to bar code data. To set this feature: The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 314: 2-Digit Supplemental Label Id
EAN-13 2-Digit Supplemental Label ID This feature specifies an EAN-13 2-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 315: 5-Digit Supplemental Label Id
EAN-13 Enable EAN-13 5-Digit Supplemental Label ID This feature specifies an EAN-13 5-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 316: 128 Supplemental Label Id
EAN-13 128 Supplemental Label ID This feature specifies an EAN-13 128 Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 317: Minimum Reads
EAN-13 Enable EAN-13 Minimum Reads Specifies the minimum number of consecutive times an EAN-13 label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 318 EAN-13 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-13 MINIMUM READS = 3 EAN-13 MINIMUM READS = 4 6-200 ®...
Page 319: Bookland Label Id
EAN-13 Enable Bookland Label ID This feature specifies a Bookland label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 320: Enable
EAN-8 Enable Enables/disables the ability of the scanner to decode EAN/JAN-8 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 321: Check Character Transmission
EAN-8 Enable EAN-8 Check Character Transmission Enables/disables transmission of an EAN/JAN-8 check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 322: Expand Ean-8 To Ean-13
Expand EAN-8 to EAN-13 Enables/disables expansion of EAN/JAN-8 labels to EAN/JAN-13. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 323: Ean-8/Jan-8 Guard Insertion
EAN-8 Enable EAN-8/JAN-8 Guard Insertion Enables/Disables the ability of the scanner to insert a guard pattern into an otherwise complete EAN-8 segment it has received. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 324: Ean-8/Jan-8 Guard Substitution
EAN-8/JAN-8 Guard Substitution Enables/disables the ability of the scanner to substitute a guard pattern for even-parity 6 when an EAN-8/JAN-8 label is presented. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 325: Ean-8/Jan-8 Both Guards Substitution
EAN-8 Enable EAN-8/JAN-8 Both Guards Substitution Enables/disables the ability of the scanner to find an EAN/JAN8 guard pattern in cases where the EAN/JAN8 margin makes the guard look like a character. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 326: Stitch Exact Label Halves
EAN-8 Stitch Exact Label Halves When enabled, this allows the scanner the ability to stitch exact EAN-8 label haves with no overlapping characters. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 327: Stitch Unlike Label Halves
EAN-8 Enable EAN-8 Stitch Unlike Label Halves When enabled, this allows the scanner the ability to stitch two EAN-8 label halves together that may contain differing characters. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 328: Ean 8 Label Id
EAN 8 Label ID This feature specifies an EAN 8 label ID to be added to bar code data. To set this feature: The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 329: 2-Digit Supplemental Label Id
EAN-8 Enable EAN-8 2-Digit Supplemental Label ID This feature specifies an EAN-8 2-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 330: 5-Digit Supplemental Label Id
EAN-8 5-Digit Supplemental Label ID This feature specifies an EAN-8 5-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 331: 128 Supplemental Label Id
EAN-8 Enable EAN-8 128 Supplemental Label ID This feature specifies an EAN-8 128 Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 332: Decoding Levels
EAN-8 Decoding Levels Decoding levels allow the decoder to be set to perform at one of four selectable levels: • Very Conservative — Slower scan time, virtually eleminates mis- reads. The most secure setting. • Slightly More Aggressive — Faster scanning, more aggressive, yet minimizes misreads.
Page 333 EAN-8 Enable EAN-8 Decoding Levels — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 DECODING LEVELS = VERY CONSERVATIVE EAN-8 DECODING LEVELS = SLIGHTLY MORE AGGRESSIVE 6-215 Product Reference Guide...
Page 334 EAN-8 Decoding Levels — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 DECODING LEVELS = MODERATELY AGGRESSIVE EAN-8 DECODING LEVELS = VERY AGGRESSIVE 6-216 ®...
Page 335: Minimum Reads
EAN-8 Enable EAN-8 Minimum Reads Specifies the minimum number of consecutive times an EAN-8 label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 336 EAN-8 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM READS = 3 EAN-8 MINIMUM READS = 4 6-218 ®...
Page 337: Minimum Segment Length
EAN-8 Enable EAN-8 Minimum Segment Length Specifies the minimum number of characters necessary in an EAN-8/ JAN-8 label segment in order for the scanner to accept a label for decod- ing. Selectable from 5 to 15 characters. To set this feature: 1.
Page 338 EAN-8 Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 7 CHARACTERS EAN-8 MINIMUM SEGMENT LENGTH = 8 CHARACTERS 6-220 ®...
Page 339 EAN-8 Enable EAN-8 Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 9 CHARACTERS EAN-8 MINIMUM SEGMENT LENGTH = 10 CHARACTERS 6-221 Product Reference Guide...
Page 340 EAN-8 Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 11 CHARACTERS EAN-8 MINIMUM SEGMENT LENGTH = 12 CHARACTERS 6-222 ®...
Page 341 EAN-8 Enable EAN-8 Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 13 CHARACTERS EAN-8 MINIMUM SEGMENT LENGTH = 14 CHARACTERS 6-223 Product Reference Guide...
Page 342 EAN-8 Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 15 CHARACTERS 6-224 ®...
Page 343: Other Upc/Ean Options
Other UPC/EAN Options Other UPC/EAN Options The following pages contain other selectable features for UPC/EAN sym- bologies: • Price Weight Check • In-Store Label Minimum Reads • Enable EAN Two Label • EAN Two Label Minimum Reads • Addons 6-225 Product Reference Guide...
Page 344: Price Weight Check
Price Weight Check Enables/disables calculation and verification of price/weight check digits. Applies to all UPC-A and EAN/JAN-13 labels with eligible Number Sys- tem/First Character digits. Options are: • Disable • 4-digit price/weight • 5-digit price/weight • 4-digit European price/weight • 5-digit European price/weight To set this feature: 1.
Page 345 Other UPC/EAN Options Price Weight Check — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. PRICE WEIGHT CHECK = 4-DIGIT PRICE/WEIGHT PRICE WEIGHT CHECK = 5-DIGIT PRICE/WEIGHT 6-227 Product Reference Guide...
Page 346 Price Weight Check — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. PRICE WEIGHT CHECK = 4-DIGIT EUROPEAN PRICE/WEIGHT PRICE WEIGHT CHECK = 5-DIGIT EUROPEAN PRICE/WEIGHT 6-228 ®...
Page 347: In-Store Label Minimum Reads
Other UPC/EAN Options In-Store Label Minimum Reads Specifies the minimum number of consecutive times an In-Store label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 348 In-Store Label Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. IN-STORE MINIMUM READS = 3 IN-STORE MINIMUM READS = 4 6-230 ®...
Page 349: Enable Ean Two Label
Other UPC/EAN Options Enable EAN Two Label Enables/disables the ability of the scanner to decode EAN two-label pairs. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 350: Ean Two Label Combined Transmission
EAN Two Label Combined Transmission Enables/disables the transmitting of an EAN two label pair as one label. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 351: Upc/Ean Guard Insertion
Other UPC/EAN Options UPC/EAN Guard Insertion Enables/Disables the ability of the scanner to insert either a missing lead- ing or trailing guard on an otherwise complete UPC-A/EAN-13 segment it has received. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 352: Upc/Ean Stitch Exact Label Halves
UPC/EAN Stitch Exact Label Halves When enabled, this allows the scanner the ability to stitch exact UPC-A / EAN-13 label haves with no overlapping characters. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 353: Upc/Ean Stitch Unlike Label Halves
Other UPC/EAN Options UPC/EAN Stitch Unlike Label Halves When enabled, this allows the scanner the ability to stitch two UPC-A / EAN-13 label halves together that may contain differing characters. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 354: Upc/Ean Character Reconstruction
UPC/EAN Character Reconstruction Enables/Disables character reconstruction on UPC/EAN labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 355: Ean Two Label Minimum Reads
Other UPC/EAN Options EAN Two Label Minimum Reads Specifies the minimum number of consecutive times an EAN Two Label bar code must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 356 EAN Two Label Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN TWO LABEL MINIMUM READS = 3 EAN TWO LABEL MINIMUM READS = 4 6-238 ®...
Page 357: Upc/Ean Correlation
Other UPC/EAN Options UPC/EAN Correlation This feature enables/disables character correlation for UPC/EAN. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 358: Upc/Ean Minimum Segment Length
UPC/EAN Minimum Segment Length Specifies the minimum number of characters necessary in a UPC/EAN/ JAN label segment in order for the scanner to accept a label for decoding. Selectable from 5 to 15 characters. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 359 Other UPC/EAN Options UPC/EAN Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 7 CHARACTERS UPC/EAN MINIMUM SEGMENT LENGTH = 8 CHARACTERS 6-241 Product Reference Guide...
Page 360 UPC/EAN Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 9 CHARACTERS UPC/EAN MINIMUM SEGMENT LENGTH = 10 CHARACTERS 6-242 ®...
Page 361 Other UPC/EAN Options UPC/EAN Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 11 CHARACTERS UPC/EAN MINIMUM SEGMENT LENGTH = 12 CHARACTERS 6-243 Product Reference Guide...
Page 362 UPC/EAN Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 13 CHARACTERS UPC/EAN MINIMUM SEGMENT LENGTH = 14 CHARACTERS 6-244 ®...
Page 363 Other UPC/EAN Options UPC/EAN Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 15 CHARACTERS 6-245 Product Reference Guide...
Page 364: Addons
Addons Add-ons (or supplemental characters) are commonly added to the end of UPC/EAN bar codes. The scanner will read the add-ons if they are enabled and in the field of view. Three add-on types are supported: 2- digit, 5-digit and Code 128 add-ons. Supported options are: This option directs the scanner to ignore add-on portion of a None —...
Page 365 Other UPC/EAN Options Addons — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. OPTIONAL 2-DIGIT ADD-ONS = DISABLE OPTIONAL 2-DIGIT ADD-ONS = ENABLE 6-247 Product Reference Guide...
Page 366 Addons — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. OPTIONAL 5-DIGIT ADD-ONS = DISABLE OPTIONAL 5-DIGIT ADD-ONS = ENABLE 6-248 ®...
Page 367 Other UPC/EAN Options Addons — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. OPTIONAL CODE 128 ADD-ONS = DISABLE OPTIONAL CODE 128 ADD-ONS = ENABLE 6-249 Product Reference Guide...
Page 368: Addon Timer
Addon Timer When addons have been selected as optional, this feature sets the duration of time that the scanner can unsuccessfully look for an addon before pro- ceeding to read a bar code. Timer duration is specified in 10ms incre- ments.
Page 369: 2-Digit Add-Ons Minimum Reads
Other UPC/EAN Options 2-Digit Add-ons Minimum Reads Specifies the minimum number of times a 2-digit addon must be read before it is marked as valid and then combined with a base label. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 370 2-Digit Add-ons Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. 2-DIGIT ADD-ONS MINIMUM READS = 3 2-DIGIT ADD-ONS MINIMUM READS = 4 6-252 ®...
Page 371: 5-Digit Add-Ons Minimum Reads
Other UPC/EAN Options 5-Digit Add-ons Minimum Reads Specifies the minimum number of times a 5-digit addon must be read before it is marked as valid and then combined with a base label. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 372 5-Digit Add-ons Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. 5-DIGIT ADD-ONS MINIMUM READS = 3 5-DIGIT ADD-ONS MINIMUM READS = 4 6-254 ®...
Page 373: Code 128 Add-Ons Minimum Reads
Other UPC/EAN Options Code 128 Add-ons Minimum Reads Specifies the minimum number of times a Code 128 addon must be read before it is marked as valid and then combined with a base label. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 374 Code 128 Add-ons Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODE 128 ADD-ONS MINIMUM READS = 3 CODE 128 ADD-ONS MINIMUM READS = 4 6-256 ®...
Page 375: Gtin Enable
GTIN Enable GTIN Enable Enables/Disables the ability to convert UPCE, UPCA, EAN8, and EAN13 labels into the GTIN 14-character format. If add-on information is present on the base label prior to the conversion taking place, the add-on information will be appended to the converted GTIN bar code.
Page 376: Gtin Label Id
GTIN Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 377: Gtin 2-Digit Supplemental Label Id
GTIN Enable GTIN 2-Digit Supplemental Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled and 2-digit supplemental addon bar code labels are converted. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.
Page 378: Gtin 5-Digit Supplemental Label Id
GTIN 5-Digit Supplemental Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled and 5-digit supplemental addon bar code labels are converted. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.
Page 379: Gtin Code 128 Supplemental Label Id
GTIN Enable GTIN Code 128 Supplemental Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled and Code 128 supplemental addon bar code labels are converted The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.
Page 380: Databar Omnidirectional Enable
DataBar Omnidirectional Enable Enables/disables the ability of the scanner to decode DataBar Omnidirec- tional labels. This value-added feature is a factory-programmed option. Contact your dealer for information about upgrading your system to include this advanced capability. NOTE To set this feature: 1.
Page 381: Databar Omnidirectional/Ean-128 Emulation
DataBar Omnidirectional Enable DataBar Omnidirectional/EAN-128 Emulation Enables/disables the ability of DataBar Omnidirectional to be transmitted as EAN-128. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 382: Databar Omnidirectional Label Id
DataBar Omnidirectional Label ID This feature specifies an DataBar Omnidirectional label ID to be added to bar code data. To set this feature: The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 383: Databar Omnidirectional Minimum Reads
DataBar Omnidirectional Enable DataBar Omnidirectional Minimum Reads Specifies the minimum number of consecutive times an DataBar Omnidi- rectional label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 384 DataBar Omnidirectional Minimum Reads — contin- Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. DataBar Omnidirectional MINIMUM READS = 3 DataBar Omnidirectional MINIMUM READS = 4 6-266 ®...
Page 385: Databar Expanded Enable
DataBar Expanded Enable DataBar Expanded Enable Enables/disables the ability of the scanner to decode DataBar Expanded labels. This value-added feature is a factory-programmed option. Contact your dealer for information about upgrading your system to include this advanced capability. NOTE To set this feature: 1.
Page 386: Databar Expanded Ean-128 Emulation
DataBar Expanded EAN-128 Emulation Enables/disables EAN-128 emulation for DataBar Expanded. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 387: Databar Expanded Label Id
DataBar Expanded Enable DataBar Expanded Label ID This feature specifies an DataBar Expanded label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 388: Databar Expanded Length Control
DataBar Expanded Length Control This feature specifies either variable-length or fixed-length decoding for DataBar Expanded. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 389: Databar Expanded Length 1
DataBar Expanded Enable DataBar Expanded Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see DataBar Expanded Length . Length includes the barcode’s check and data characters. Control) To set this feature: 1.
Page 390: Databar Expanded Length 2
DataBar Expanded Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see DataBar Expanded . Length includes the barcode’s check and data characters. Length Control) To set this feature: 1.
Page 391: Databar Expanded Minimum Reads
DataBar Expanded Enable DataBar Expanded Minimum Reads Specifies the minimum number of consecutive times an DataBar Expanded label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 392 DataBar Expanded Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. DataBar Expanded MINIMUM READS = 3 DataBar Expanded MINIMUM READS = 4 6-274 ®...
Page 393: Code 39 Enable
Code 39 Enable Code 39 Enable Enables/disables the ability of the scanner to decode Code 39 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 394: Code 39 Start Stop Character Transmission
Code 39 Start Stop Character Transmission Enables/disables transmission of Code 39 start and stop characters. This feature applies only when Code 39 Check Character Calculation enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 395: Code 39 Check Character Calculation
Code 39 Enable Code 39 Check Character Calculation Enables/disables calculation and verification of an optional Code 39 check character. When disabled, any check character in label is treated as a data character. If check calculation is disabled, the risk is increased that a misread can occur.
Page 396: Code 39 Check Character Transmission
Code 39 Check Character Transmission Enables/disables transmission of optional Code 39 check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 397: Code 39 Full Ascii
Code 39 Enable Code 39 Full ASCII Enables/disables the ability of the scanner to translate to Code 39 full ASCII labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 398: Code 39 Label Id
Code 39 Label ID This feature specifies a Code 39 label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 399: Code 39 Require Quiet Zones
Code 39 Enable Code 39 Require Quiet Zones When enabled, this feature requires that quiet zones (margins) be present for Code 39 labels. When disabled, quiet zones are optional. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 400: Code 39 Length Control
Code 39 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 39. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 401: Code 39 Length 1
Code 39 Enable Code 39 Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see Code 39 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.
Page 402: Code 39 Length 2
Code 39 Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see Code 39 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.
Page 403: Code 39 Correlation
Code 39 Enable Code 39 Correlation This feature enables/disables character correlation for Code 39. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 404: Code 39 Stitching
Code 39 Stitching Enables/disables stitching for Code 39 labels. When parts of a Code 39 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.
Page 405: Code 39 Minimum Reads
Code 39 Enable Code 39 Minimum Reads Specifies the minimum number of consecutive times a Code 39 label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 406 Code 39 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODE 39 MINIMUM READS = 3 CODE 39 MINIMUM READS = 4 6-288 ®...
Page 407: Pharmacode 39 Enable
Pharmacode 39 Enable Pharmacode 39 Enable Enables/disables the ability of the scanner to decode Italian Pharmacode 39 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 408: Pharmacode 39 Start Stop Character Transmission
Pharmacode 39 Start Stop Character Transmission Enables/ disables transmission of start and stop characters for Pharmacode To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 409: Pharmacode 39 Check Character Transmission
Pharmacode 39 Enable Pharmacode 39 Check Character Transmission Enables/disables transmission of Pharmacode 39 check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 410: Pharmacode 39 Label Id
Pharmacode 39 Label ID This feature specifies a Pharmacode 39 label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 411: Code 128 Enable
Code 128 Enable Code 128 Enable Enables/disables the ability of the scanner to decode Code 128 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 412: Code 128 Transmit Function Characters
Code 128 Transmit Function Characters Enables/disables transmission of Code 128 function characters 1, 2, 3, and 4. Disabled is the recommended setting for all interfaces. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 413: Convert Code 128 To Code 39
Code 128 Enable Convert Code 128 to Code 39 Enables/disables conversion of Code 128 labels to Code 39. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 414: Code 128 Label Id
Code 128 Label ID This feature specifies a Code 128 label ID to be added to bar code data.. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 415: Code 128 Length Control
Code 128 Enable Code 128 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 128. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 416 Code 128 Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see Code 128 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.
Page 417: Code 128 Length 2
Code 128 Enable Code 128 Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see Code 128 Length Con- . Length includes the barcode’s check and data characters. trol) To set this feature: 1.
Page 418: Code 128 Correlation
Code 128 Correlation This feature enables/disables character correlation for Code 128. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 419: Code 128 Stitching
Code 128 Enable Code 128 Stitching Enables/disables stitching for Code 128 labels. When parts of a Code 128 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.
Page 420: Code 128 Minimum Reads
Code 128 Minimum Reads Specifies the minimum number of consecutive times a Code 128 label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 421 Code 128 Enable Code 128 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODE 128 MINIMUM READS = 3 CODE 128 MINIMUM READS = 4 6-303 Product Reference Guide...
Page 422: Enable
EAN-128 Enable Enables/disables the ability of the scanner to decode EAN-128 labels. When disabled, EAN128 labels are transmitted in Code128 data format. When enabled, EAN128 labels are transmitted in EAN128 data format To set this feature: 1. Scan the SWITCH bar code. 2.
Page 423: Label Id
EAN-128 Enable EAN-128 Label ID This feature specifies an EAN-128 label ID to be added to bar code data.. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 424: Interleaved 2 Of 5 (I 2 Of 5) Enable
Interleaved 2 of 5 (I 2 of 5) Enable Enables/disables the ability of the scanner to decode Interleaved 2 of 5 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 425: I 2 Of 5 Check Character Calculation
Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Check Character Calculation Enables/disables calculation and verification of an optional Interleaved 2 of 5 check character. If check character calculation is disabled, the risk is increased that a misread can occur.
Page 426: I 2 Of 5 Check Character Transmission
I 2 of 5 Check Character Transmission Enables/disables transmission of an optional Interleaved 2 of 5 check char- acter. This feature applies only when I 2 of 5 Check Character Calculation enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2.
Page 427: I 2 Of 5 Label Id
Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Label ID This feature specifies an I 2 of 5 label ID to be added to bar code data.. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.
Page 428: I 2 Of 5 Length Control
I 2 of 5 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for I 2 of 5. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 429: I 2 Of 5 Length 1
Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see I 2 of 5 Length Control) Length includes the barcode’s check and data characters.
Page 430: I 2 Of 5 Length 2
I 2 of 5 Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see I 2 of 5 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.
Page 431: I 2 Of 5 Correlation
Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Correlation This feature enables/disables character correlation for I 2 of 5. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 432: I 2 Of 5 Stitching
I 2 of 5 Stitching Enables/disables stitching for I 2 of 5 labels. When parts of an I 2 of 5 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.
Page 433: I 2 Of 5 Minimum Reads
Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Minimum Reads Specifies the minimum number of consecutive times an I 2 of 5 label must be decoded before it is accepted as a good read. To set this feature: 1.
Page 434 I 2 of 5 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. I 2 of 5 MINIMUM READS = 3 I 2 of 5 MINIMUM READS = 4 6-316 ®...
Page 435: Standard 2 Of 5 (Std 2 Of 5) Enable
Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 (Std 2 of 5) Enable Enables/disables the ability of the scanner to decode Standard 2 of 5 labels. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 436: Standard 2 Of 5 Check Character Calculation
Standard 2 of 5 Check Character Calculation Enables/disables calculation and verification of an optional Standard 2 of 5 check character. If check character calculation is disabled, the risk is increased that a misread can occur. When disabled, any check characters in a bar code are treated as data characters.
Page 437: Standard 2 Of 5 Check Character Transmission
Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Check Character Transmission Enables/disables transmission of an optional Standard 2 of 5 check charac- ter. This feature applies only when Standard 2 of 5 Check Character Calcu- lation is enabled.
Page 438: Standard 2 Of 5 Label Id
Standard 2 of 5 Label ID This feature specifies a Standard 2 of 5 label ID to be added to bar code data.. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 439: Standard 2 Of 5 Length Control
Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Standard 2 of 5. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 440: Standard 2 Of 5 Length 1
Standard 2 of 5 Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see Standard 2 of 5 Length Con- . Length includes the barcode’s check and data characters. trol) To set this feature: 1.
Page 441: Standard 2 Of 5 Length 2
Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see Standard 2 of 5 Length .
Page 442: Standard 2 Of 5 Correlation
Standard 2 of 5 Correlation This feature enables/disables character correlation for Standard 2 of 5. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 443: Standard 2 Of 5 Stitching
Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Stitching Enables/disables stitching for Standard 2 of 5 labels. When parts of a Stan- dard 2 of 5 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.
Page 444: Standard 2 Of 5 Minimum Reads
Standard 2 of 5 Minimum Reads Specifies the minimum number of consecutive times a Standard 2 of 5 label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2.
Page 445: Standard 2 Of 5 Minimum Reads
Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. STANDARD 2 of 5 MINIMUM READS = 3 STANDARD 2 of 5 MINIMUM READS = 4 6-327...
Page 446: Codabar Enable
Codabar Enable Enables/disables the ability of the scanner to decode Codabar labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 447: Codabar Start Stop Character Transmission
Codabar Enable Codabar Start Stop Character Transmission Enables/disables transmission of Codabar start and stop characters. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 448: Codabar Start Stop Character Set
Codabar Start Stop Character Set This feature selects the format of transmitted Codabar start/stop charac- ters. Options are: • ABCD/TN* E • ABCD/ABCD • abcd/tn* e • abcd/abcd To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below or from the following page representing the desired option.
Page 449 Codabar Enable Codabar Start Stop Character Set — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODABAR START STOP CHARACTER = abcd/tn* e CODABAR START STOP CHARACTER = abcd/abcd 6-331 Product Reference Guide...
Page 450: Codabar Start Stop Character Match
Codabar Start Stop Character Match Enables/disables the requirement that start and stop characters match. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 451: Codabar Check Character Calculation
Codabar Enable Codabar Check Character Calculation Enables/disables calculation and verification of an optional Codabar check character. If check character calculation is disabled, the risk is increased that a misread can occur. When disabled, any check characters in a bar code are treated as data characters.
Page 452: Codabar Check Character Transmission
Codabar Check Character Transmission Enables/disables transmission of an optional Codabar check character. Applies only when Codabar Check Character Calculation is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 453: Codabar Label Id
Codabar Enable Codabar Label ID This feature specifies a Codabar label ID to e added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 454: Codabar Require Quiet Zones
Codabar Require Quiet Zones When enabled, this feature requires that quiet zones (margins) be present for Codabar labels. When disabled, quiet zones are optional. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 455: Codabar Length Control
Codabar Enable Codabar Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Codabar. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 456: Codabar Length 1
Codabar Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see Codabar Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.
Page 457: Length Includes The Barcode's Check And Data Characters
Codabar Enable Codabar Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see Codabar Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.
Page 458: Codabar Correlation
Codabar Correlation This feature enables/disables character correlation for Codabar. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 459: Codabar Stitching
Codabar Enable Codabar Stitching Enables/disables stitching for Codabar labels. When parts of a Codabar bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.
Page 460: Codabar Minimum Reads
Codabar Minimum Reads Specifies the minimum number of consecutive times a Codabar label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 461 Codabar Enable Codabar Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODABAR MINIMUM READS = 3 CODABAR MINIMUM READS = 4 6-343 Product Reference Guide...
Page 462: Code 93 Enable
Code 93 Enable Enables/disables the ability of the scanner to decode Code 93 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 463: Code 93 Label Id
Code 93 Enable Code 93 Label ID This feature specifies a Code 93 label ID to be added to bar code data.. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 464: Code 93 Length Control
Code 93 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 93. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 465: Scan The Appropriate Digits From The Keypad In Resent The Desired Label Length. The Selectable Range For This Option Is
Code 93 Enable Code 93 Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see Code 93 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.
Page 466: Code 93 Length 2
Code 93 Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see Code 93 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.
Page 467: Code 93 Correlation
Code 93 Enable Code 93 Correlation This feature enables/disables character correlation for Code 93. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 468: Code 93 Stitching
Code 93 Stitching Enables/disables stitching for Code 93 labels. When parts of a Code 93 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.
Page 469: Code 93 Minimum Reads
Code 93 Enable Code 93 Minimum Reads Specifies the minimum number of consecutive times a Code 93 label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 470 Code 93 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODE 93 MINIMUM READS = 3 CODE 93 MINIMUM READS = 4 6-352 ®...
Page 471: Msi/Plessey Enable
MSI/Plessey Enable MSI/Plessey Enable Enables/disables the ability of the scanner to decode MSI/Plessey labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 472: Msi/Plessey Check Character Calculation
MSI/Plessey Check Character Calculation Enables/disables calculation and verification of optional MSI/Plessey check characters. If check character calculation is disabled, the risk is increased that a misread can occur. When disabled, any check characters in a bar code are treated as data characters.
Page 473: Msi/Plessey Number Of Check Characters
MSI/Plessey Enable MSI/Plessey Number of Check Characters Specifies number of MSI/Plessey check characters to be calculated and verified. Check characters are always modulus 10. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below representing the desired number of MSI/ Plessey check characters to be calculated and verified.
Page 474: Msi/Plessey Check Character Transmission
MSI/Plessey Check Character Transmission Enables/disables transmission of optional MSI/Plessey check characters. This feature applies only when MSI/Plessey Check Character Calcula- tion is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 475: Msi/Plessey Label Id
MSI/Plessey Enable MSI/Plessey Label ID This feature specifies an MSI/Plessey label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.
Page 476: Msi/Plessey Length Control
MSI/Plessey Length Control This feature specifies whether variable-length or fixed-length decoding will be set for MSI/Plessey. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 477: Msi/Plessey Length 1
MSI/Plessey Enable MSI/Plessey Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see MSI/Plessey Length Con- . Length includes the barcode’s check and data characters. trol) To set this feature: 1.
Page 478: Msi/Plessey Length 2
MSI/Plessey Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see Code 93 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.
Page 479: Msi/Plessey Correlation
MSI/Plessey Enable MSI/Plessey Correlation This feature enables/disables character correlation for MSI/Plessey. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 480: Msi/Plessey Stitching
MSI/Plessey Stitching Enables/disables stitching for MSI/Plessey labels. When parts of an MSI/ Plessey bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met. To set this feature: 1.
Page 481: Msi/Plessey Minimum Reads
MSI/Plessey Enable MSI/Plessey Minimum Reads Specifies the minimum number of consecutive times an MSI/Plessey label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
Page 482 MSI/Plessey Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. MSI/PLESSEY MINIMUM READS = 3 MSI/PLESSEY MINIMUM READS = 4 6-364 ®...
Page 483 MSI/Plessey Enable 6-365 Product Reference Guide...
Page 484 6-366 ® Magellan 8300/8400...
Page 485: Appendix A. Led/Beeper Indications & Controls
Appendix A LED/Beeper Indications & Controls shows the operator’s controls and indicators. The descriptions Figure A-1 following identify the use or function of each component. Figure A-1. Scanner and Scale Controls Scanner LED Indicator Volume/Tone Button Scale Zero Button & LED Speaker (Beeper) Port...
Page 486: Controls And Indicators
Controls and Indicators The control panel consists of a green LED indicator, a Volume/Tone push button and a Scale Zero push button/LED indicator as described in the following pages. The unit also includes a beeper which can be configured to sound indications of scanning, weighing, and deactivation activities. Since beeper indications are configurable, your unit may not be pro- grammed to sound all the indications listed.
Page 487: Volume/Tone Push Button
Controls and Indicators Table A-1. Scanner and Scale LED Indications DURATION COMMENT INDICATION The scanner motor and/or laser have automati- Sleep Mode Scanner (Green) LED flashes slowly cally switched off and the unit has entered Sleep Indication Mode due to extended inactivity. Scanner (Green) LED 1-second off, 1/ Host Disabled Host has disabled scanning.
Page 488 Table A-2. Volume/Tone Push Button Functions PRESS FUNCTION COMMENT DURATION Alternatively, the scanner can be awakened by: Momentary (when Wakes scanner from Sleep - Moving an object through the scan zone. scanner is asleep) Mode - A weight change on the scale. - Scanning with an attached auxiliary scanner.
Page 489: Scale Zero Push Button
Controls and Indicators Scale Zero Push Button The Scale Zero Push Button is used for multiple functions as listed in Table A-3 The Scale Zero Push Button has no function in a “scanner only” model. The button must be configured to enable standard functions, or Scale Diagnostics will not be an available feature.
Page 490: Calibration Switch
Calibration Switch This switch initiates the scale’s calibration routine. A certified weight set is needed to perform the scale calibration steps detailed in Chapter 5, Cali- . This switch is not included in scanners without scale modules. bration Calibration Switch Seal This seal allows you to secure the Calibration Switch access cover and restrict access to the Calibration Switch.
Page 491: Appendix B. Cable Information
Appendix B Cable Information Introduction The following pages contain pinout information, enabling you to create standard interface cables for use in interconnecting the scanner, scale, external handheld scanner, and POS terminal. General Specifications Wire Requirements • Cable length should not exceed 15 feet. •...
Page 492: Scanner
RS-232 Cable Pinout Scanner Connector Hardware RJ45, 10 Position Cable Pinout Table B-1RS-232 Cable Pinouts PIN # FUNCTION DESCRIPTION No Connection CTS in Clear To Send (input) No Connection RTS out Request To Send (output) RxD in Receive Data (Input) TxD out Transmit Data (output) No Connection...
Page 493: Scale
Introduction RS-232 Cable Pinout — continued Scale Connector Hardware RJ45, 10 Position Cable Pinout Table B-2RS-232 Scale Cable Pinouts PIN # FUNCTION DESCRIPTION +5V pullup +5V pullup CTS IN Clear To Send (input) No Connection RTS OUT Request To Send (output) RxD IN Receive Data (Input) TxD OUT...
Page 494: Ibm Cable Pinout
IBM Cable Pinout Scanner and Scale Connector Hardware RJ45, 10 Position Cable Pinout Table B-3IBM Cable Pinouts PIN # FUNCTION DESCRIPTION No Connection No Connection No Connection LINEB Line B No Connection LINEA Line A No Connection No Connection Signal Ground No Connection ®...
Page 495: Ibm Usb Cable Pinout
IBM USB Cable Pinout IBM USB Cable Pinout Scanner and Scale Connector Hardware RJ45, 10 Position Cable Pinout Table B-4IBM USB Cable Pinouts PIN # FUNCTION DESCRIPTION No Connection No Connection VBUS USB VBUS USB D- USB D- No Connection USB D+ USB D+ No Connection...
Page 496: Auxilliary Port
Auxilliary Port External Handheld Input Connector Hardware RJ45, 10 Position Cable Pinout Table B-5Auxilliary Port Cable Pinouts PIN # FUNCTION DESCRIPTION +5V pullup +5V pullup CTS in Clear To Send (input) No Connection - Reserved RTS out Request To Send (output) RxD in Receive Data (Input) TxD out...
Page 497: Power Cable
Power Cable Power Cable Connector Hardware 3 pin Molex Cable Pinout Table B-6Power Cable Pinouts PIN # FUNCTION DESCRIPTION EARTH GND Earth Ground SIGNAL GND Signal Ground +12V IN +12V in Product Reference Guide...
Page 498: Remote Display
Remote Display Connector Hardware 4 pin SDL Cable Pinout Table B-7Remote Display Cable Pinouts PIN # FUNCTION DESCRIPTION +12V OUT +12V out LINE_A_DSPLY LINE A Display LINE_B_DSPLY LINE B Display Ground ® Magellan 8300/8400...
Page 499: Eas Comm Port (Sensormatic Systems Only
® EAS Comm Port (Sensormatic systems EAS Comm Port (Sensormatic systems ONLY) ® EAS Deactivator Control Box Connection Connector Hardware Cable Pinout Table B-8. EAS Port Cable Pinouts PIN # FUNCTION DESCRIPTION +5V Out +5V Out External Read Indicator When configured, signifies good read Intended to drive an external amplifier that Audio Out drives and external speaker.
Page 500 NOTES B-10 ® Magellan 8300/8400...
Page 501: Appendix C Keypad
Appendix C Keypad Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 502 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 503 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 504 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 505 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 506 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 507 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 508 Use the bar codes in this appendix to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 509: Appendix D Host Commands
Appendix D Host Commands Accepting Commands from an RS-232 Scanner Host The scanner responds to the following RS-232 commands: COMMAND ASCII COMMENT Enable Scanner 0x45 Disable Scanner 0x44 Reset Scanner 0x52 Not On File Indication 0x46 Long series of beeps Beep Good Read Tone 0x42 Beeps if Good Read Beep is enabled...
Page 510 NOTES ® Magellan 8300/8400...
Page 511: Appendix E. Keyboard Function Key Mappings
Appendix E Keyboard Function Key Mappings Keyboard Model Cross Reference summarizes the keyboard models, their defined protocol, scancode set, and some Table E-2 unique features. The remaining tables in this chapter provide the function key maps associated with each of the scancode sets. Product Reference Guide...
Page 512 Table E-1. Keyboard Model Cross Reference Func. Trans- Scancode Model Type I/F ID mission Country Protocol Mode Support PC/XT Foreign ALT Mode Wedge A PC/XT Scan Set 1 PS/2 25-286; PS/2 30-286; Wedge B AT/PS2 Scan Set 2 PS/2 50, 50Z; PS/2 60,70,80,90,95 Foreign ALT Mode PS/2 25 and 30...
Page 513 Keyboard Model Cross Reference Table E-2. Scanset 1 Function Key Map ASCII ASCII code Scancode (hex) ALT right Make E0h 38h ALT right Break E0h B8h ALT left Make ALT left Break CTRL left Make CTRL left Break CTRL right Make E0h 1Dh CTRL right Break E0h 9Dh...
Page 514 Table E-3. Scanset 2 Function Key Map ASCII ASCII code Scancode (hex) ALT right Make E0h 11h ALT right Break E0h F0h 11h ALT left Make ALT left Break F0h 11h CTRL left Make CTRL left Break F0h 14h CTRL right Make E0h 14h CTRL right Break E0h F0h 14h...
Page 515 Keyboard Model Cross Reference Table E-4 Scanset 3, 102-Key Function Key Map ASCII (hex) ASCII code Scancode ALT right Make ALT right Break F0h 39h ALT left Make ALT left Break F0h 19h CTRL left Make CTRL left Break F0h 11h CTRL right Make CTRL right Break F0h 58h...
Page 516 Table E-5. Scanset 3 122-Key Function Key Map ASCII (hex) ASCII code Scancode ALT Right Make ALT Right Break F0h 39h ALT left Make ALT left Break F0h 19h CTRL left (RESET) Make only CTRL left (RESET) Make/Break 11h F0h 11h ONLINE Enter Make only ONLINE Enter Make/Break 58h F0h 58h...
Page 517 Keyboard Model Cross Reference Table E-6. Japanese DOS Function Key Map ASCII value ASCII code Scancode ALT right Make ALT right Break ALT left Make ALT left Break CTRL left Make CTRL left Break CTRL right Make CTRL right Break TAB right RIGHT arrow (inner keypad) TAB left...
Page 518 Table E-7. NEC 9801-Key Function Key Map ASCII value ASCII code Scancode unused CAPS LOCK ON (make) CAPS LOCK OFF (break) CTRL left Make CTRL left Break CTRL-C TAB right RIGHT arrow (inner keypad) TAB left 0Fh + S DELETE INSERT (inner keypad) KATAKANA LOCK ON (Make) KATAKANA LOCK OFF (Break)
Page 519 Keyboard Model Cross Reference Table E-8. USB Keyboard Function Key Usage Map ASCII Key Value Usage Name ALT right Make ALT right Break GUI right Make GUI right Break CTRL right Make CTRL right Break TAB right RIGHT arrow (inner keypad) TAB left Enter (right keypad) INSERT (inner keypad)
Page 520 NOTES E-10 ® Magellan 8300/8400...
Page 521: Appendix F. Factory Defaults
Appendix F Factory Defaults The following table provides a listing of the most common factory settings for the interfaces shown. Table F-1. Factory Default Settings RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable Enable Enable Enable Enable Enable Enable Scanner Button Options...
Page 522 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable Power-up Beep Con- 1 beep 1 beep 1 beep 1 beep 1 beep 1 beep trol Good Read Beep Enable Enable Enable Enable Enable Enable Control Good Read Beep Medium Medium Medium Medium...
Page 523 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable Scale Intercharacter No delay No delay Delay Remote Display — Enable Enable Enable Enable Enable Enable/Disable EAS Active State EAS Timeout 20ms 20ms 20ms 20ms 20ms 20ms Maximum Host- Transmitted Mes- No limit No limit No limit...
Page 524 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable IBM Label Slicing Slice Slice Control when nec. when nec. IBM Maximum Label Slice Length IBM USB Scanner Table top Device Type scanner RS-232 Baud Rate 9600 9600 9600 RS-232 Number of 8 data bits 8 data bits 7 data bits...
Page 525 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable RS-232 ICL DC1 Character Delay Disable Disable Enable RS-232 Team POS Disable Disable ICL Scale RS-232 Beep on Disable Disable ASCII BEL RS-232 Beep After Disable Disable Disable Weigh RS-232 Beep on Not Enable Enable Enable...
Page 526 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable Single Cable RS-232 330 msec Stale Weight Timeout Single Cable RS-232 Transmit Scale — Transmit as 4 digits Weight Digits Single Cable Manu- Disable facturer Extensions Single Cable Paces- Disable etter Plus Enable Single Cable RS-232 Option 5...
Page 527 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable Keyboard Interface — Disable Keyboard Simulation Keyboard Interface — Disable Control Characters Keyboard Interface — 10 msec Intercharacter Delay Coupon Control Disable Disable Disable Disable Disable Disable UPC-A Enable Enable Enable Enable Enable...
Page 528 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable UPC-E Check Char- Disable Disable Disable Disable Enable Enable acter Transmission Expand UPC-E to Disable Disable Disable Disable Disable Disable UPC-A Expand UPC-E to Disable Disable Disable Disable Disable Disable EAN-13 UPC-E Label ID UPC-E 2-Digit Sup-...
Page 529 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable EAN-13 Minimum Reads EAN-13 128 Supple- mental Label ID Bookland Label ID EAN-8 Enable Enable Enable Enable Enable Enable Enable EAN-8 Check Char- Enable Enable Disable Enable Enable Enable acter Transmission Expand EAN-8 to Disable Disable...
Page 530 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable 1 (Very 1 (Very 1 (Very 1 (Very 1 (Very 1 (Very EAN-8 Decoding Lev- Conserva- Conserva- Conserva- Conserva- Conserva- Conserva- tive) tive) tive) tive) tive) tive) EAN-8 Minimum Reads EAN-8 Minimum Seg- ment Length Price Weight Check...
Page 531 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable 5-Digit Add-ons Mini- mum Reads Code 128 Add-ons Minimum Reads UPC/EAN Minimum Segment Length GTIN Enable Disable Disable Disable Disable Disable GTIN Label ID GTIN 2-Digit Supple- mental Label ID GTIN 5-Digit Supple- mental Label ID GTIN Code 128 Sup-...
Page 532 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable DataBar Expanded Label ID DataBar Expanded Variable Variable Variable Variable Variable Variable Length Control DataBar Expanded Length 1 DataBar Expanded Length 2 DataBar Expanded Minimum Reads Code 39 Enable Enable Disable Enable Enable...
Page 533 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable Code 39 Stitching Enable Enable Enable Enable Enable Enable Code 39 Minimum Reads Pharmacode 39 Disable Disable Disable Disable Disable Disable Enable Pharmacode 39 Start Stop Character Disable Disable Disable Disable Disable Disable...
Page 534 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable EAN-128 Enable Disable Disable Disable Disable Disable Disable EAN-128 Label ID None None None Interleaved 2 of 5 (I 2 Disable Disable Disable Disable Disable Disable of 5) Enable I 2 of 5 Check Char- Disable Disable Disable...
Page 535 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable Standard 2 of 5 Variable Variable Variable Variable Variable Variable Length Control Standard 2 of 5 Length 1 Standard 2 of 5 Length 2 Standard 2 of 5 Cor- Disable Disable Disable Disable...
Page 536 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable Codabar Length Con- Variable Variable Variable Variable Variable Variable trol Codabar Length 1 Codabar Length 2 Codabar Correlation Disable Disable Disable Disable Disable Disable Codabar Stitching Disable Disable Disable Disable Disable Disable Codabar Minimum...
Page 537 RS-232 Wincor- Keybd. RS-232 Single IBM USB Nixdorf Wedge Cable MSI/Plessey Label ID MSI/Plessey Length Variable Variable Variable Variable Control MSI/Plessey Length MSI/Plessey Length MSI/Plessey Correla- Disable Disable Disable Disable tion MSI/Plessey Stitch- Disable Disable Disable Disable MSI/Plessey Mini- mum Reads F-17 Product Reference Guide...
Page 538 NOTES F-18 ® Magellan 8300/8400...
Page 539: Appendix G. Handheld Data Format Requirements
Maximum label lengths will be enforced for label validation (i.e. labels longer than the maximum label size will not be validated). • Standard Datalogic formats generally use a single prefix character. The specific formats are provided below. Product Reference Guide...
Page 540: Datalogic Handheld Data Format Requirements
Datalogic Handheld Data Format Requirements The following sections describe label transmission formats that are typi- cally observed in factory configurations of Datalogic handheld scanners. DataBar Omnidirectional • Prefix must be ASCII characters ‘R4’ • Check character must be included in label •...
Page 541 UPC-A with 5-Digit Supplemental • System number must be included in label data • Check digit must be included in label data and is assumed to be cor- rect • Prefix must be an ASCII character 'A' - total length including prefix must be 18 •...
Page 542 UPC-E with 2-Digit Supplemental • System number must be included in label data. • Check digit must be included in label data and is assumed to be cor- rect. • Supplemental data is appended to base label. • Prefix must be an ASCII character 'E' - total length including prefix must be 11.
Page 543 EAN-8 • Check digit must be included in label data and is assumed to be cor- rect • Prefix must be an ASCII characters 'FF' - total length including pre- fix must be 10 • Example: 'FF00210126' EAN-8 with 2-Digit Supplemental •...
Page 544 EAN-13 • Check digit must be included in label data and is assumed to be cor- rect • Prefix must be an ASCII character 'F'- total length including prefix must be 14 • Example: 'F1101234567891' EAN-13 with 2-Digit Supplemental • Check digit must be included in label data and is assumed to be cor- rect •...
Page 545 Code 39 • Check character must be included in label data. • Label length including start, stop and check characters and exclud- ing prefix character must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type.
Page 546: Standard 2 Of
Standard 2 of 5 • Check character must be included in label data. • Label length including check characters and excluding prefix charac- ters must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. •...
Page 547 Code 128 • Prefix must be an ASCII character '#'. • Label length excluding prefix character must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. • Function characters may be transmitted as a hexadecimal value 8x. Where x correlates to function characters 1 thru 4 as follows: •...
Page 548: Aim Formats
AIM Formats AIM specifies a 3-character string that is attached as a prefix to the label data for transmission. Because AIM specifies one identifier for UPC-A, UPC-E and EAN-13 labels, UPC-A, UPC-E and EAN-13 will be received from the handheld and transmitted to the POS by the scanner as EAN-13. Using this form of identification, the ']' character must be the first charac- ter in the label received from the handheld.
Page 549: Digit Supplemental
• Prefix must be ASCII characters ']E0'- total length including prefix must be 16. • Example: ']E01101234567891'. EAN-8 • Check digit must be included in label data and is assumed to be cor- rect. • Prefix must be ASCII characters ']E4' - total length including prefix must be 11.
Page 550 5-Digit Supplemental • Supplemental data is appended to any EAN base label. • Prefix must be ASCII characters ']E2'. • Length of supplemental data including prefix must be 8. Total required length is 24 for EAN-13 and 19 for EAN-8. •...
Page 551: Code 39
Code 39 • Check character must be included in label data. • Label length including start, stop and check characters and exclud- ing prefix characters must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type.
Page 552: Code 93
Code 93 • Prefix must be ASCII characters ']G0'. • Label length excluding prefix characters must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. • Example : ']G0Code93-test'. DataBar Omnidirectional • Prefix must be ASCII characters ']e0'.
Page 553: Prefix Must Be An Ascii Character
Standard 2 of 5 • Check character must be included in label data. • Label length including check characters and excluding prefix charac- ters must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. •...
Page 554 NOTES G-16 ® Magellan 8300/8400...
Page 555 NOTES G-17 Product Reference Guide...
Page 556 NOTES G-18 ® Magellan 8300/8400...
Page 557: Ascii Character Set
ASCII Character Set The table on this page shows a set of ASCII characters and their corresponding Hex Values. The Hex Values in this table are needed for setting symbology specific label identifiers, as well as enabling custom prefix and suffix characters. ASCII ASCII ASCII...
Page 558 Telephone: 49 (0) 61 51/93 58-0 Telephone: (65) 6435-1311 germany.scanning@datalogic.com singapore.scanning@datalogic.com India Spain and Portugal Datalogic Scanning India Datalogic Scanning Sarl Sucursal en España Telephone: 91- 22 - 64504739 Telephone: 34 91 746 28 60 india.scanning@datalogic.com spain.scanning@datalogic.com Italy United Kingdom...

This manual is also suitable for:

Magellan 8400 Magellan 8301 Magellan 8401 Magellan 8302 Magellan 8402 Magellan 8303 ... Show all

Datalogic MAGELLAN 8300 Product Reference Manual

Chapter 1. Introduction

Chapter 2. Site Preparation and Installation

Chapter 3. Operation and Maintenance

Chapter 4. Problem Isolation

Chapter 5. Calibration

Chapter 6. Programming

Quick Links

Related Manuals for Datalogic MAGELLAN 8300

Summary of Contents for Datalogic MAGELLAN 8300
