xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
If MAC-based is selected in the Authentication Mode drop-down menu in 802.1X Global Settings window, the
following window appears.
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
MAC Address
Click the Apply button to accept the changes made.
NOTE: The Initialize Port(s) cannot be viewed on the Switch unless 802.1X is enabled by port or by
MAC address. To enable 802.1X, go to Security > 802.1X > 802.1X Global Settings, and
select Port-based or Mac-based from the Authentication Mode drop-down menu.

Reauthenticate Port(s)

This window displays reauthentication of a port or group of ports.
To view this window, click Security > 802.1X > Reauthenticate Port(s), as shown below:
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
Click the Apply button to see the current status of the reauthenticated port(s).
NOTE: The Reauthenticate Port(s) cannot be viewed on the Switch unless 802.1X is enabled by port
or by MAC address. To enable 802.1X, go to Security > 802.1X > 802.1X Global Settings,
and select Port-based or Mac-based from the Authentication Mode drop-down menu.
Figure 8-19 Initialize Port(s) - MAC-based window
Description
Select the unit to be displayed.
Select a port or range of ports to be displayed.
Tick the check box and enter the MAC address of the Switch connected to the
corresponding port, if any.
Figure 8-20 Reauthenticate Port(s) window
Description
Select the unit to be displayed.
Select a port or range of ports to be displayed.
217
