Back Panel Connectors
A.
C.
E.
The NIC LEDs at the right and left of each NIC provide the following information.
LED
NIC1/
NIC2
®
Intel
Server System SR1690WB Service Guide
A
B
NIC1 connector with USB
ports 2, 5
NIC2 connector
Internal Video Connector
Figure 7. Back Panel Connectors
Table 3. NIC LED Descriptions
LED
LED State
State
Left
Off
LED
Solid Amber
Blinking Amber
Right
Off
LED
Solid Amber
Solid Green
C
D
B.
USB ports 8, 9
D.
RJ-45 Serial B port
Description
No network connection
Network connection in place
Transmit/receive activity
10 Mbps connection (if left
LED is on or blinking)
100 Mbps connection
1000 Mbps connection
E
AF003217
15
