Back Panel Connectors
A.
C.
E.
G.
The NIC LEDs at the right and left of each NIC provide the following information.
LED
Left
Right
®
Intel
Server System SR1560SF Service Guide
A
B
C
D
Mouse
Serial Port B (RJ45)
NIC 2 (10/100/1000 Mb)
USB Port 6
Figure 9. Back Panel Connectors
Table 3. NIC LED Descriptions
LED State
Off
Solid Amber
Blinking Amber
Off
Solid Amber
Solid Green
E
F
B.
Keyboard
D.
NIC 1 (10/100/1000 Mb)
F.
Video
H.
USB Port 5
Description
No network connection
Network connection in place
Transmit/receive activity
10 Mbps connection (if left LED is on or blinking)
100 Mbps connection
1000 Mbps connection
G
H
AF002161
13
