WebAccess Information
WebAccess Agent
WebAccess
Domain MTA
WebAccess Agent
(GWINTER)
This example places the Development post office on the same node and on the same GroupWise
volume with the Provo1 domain; therefore, the Provo1 MTA and the Development POA can use the
same secondary IP address. The Manufacturing post office is placed on a different node on a
different GroupWise volume, so that the Manufacturing post office has a different secondary IP
address.
The example also illustrates that the MTA, the POA, and the Internet Agent use different port
numbers for agent ports and HTTP ports. In contrast, the WebAccess Agent uses the same port
number for the agent port and the HTTP port.
The example uses default port numbers where possible. For example, the default MTA message
transfer port is 7100 and the default POA client/server port is 1677. Incrementing port numbers are
used in the example when multiple components have the same type of ports. For example, port
numbers 1677 and 1678 are both POA client/server ports and port numbers 7180 through 7184 are
all HTTP ports. Incrementing from the default port numbers generates unique, though related, port
numbers.
If you are going to set up a GroupWise name server to help GroupWise clients locate their post
offices, make sure that the default POA port number of 1677 is used somewhere in the cluster. For
more information, see
Office Agent" in the
IP ADDRESS WORKSHEET
Fill out the "IP Address Worksheet" on page 37
unique port numbers for all GroupWise agents in the cluster. (MTA, POA, Internet Agent, WebAccess
Agent).
After you have filled out the IP Address Worksheet, transfer the secondary IP addresses and cluster-
unique port numbers from the IP Address Worksheet to the System Clustering Worksheet and the
Agent Clustering Worksheet so that they are available in the sequence in which you will need them
as you set up GroupWise in a cluster.
30 GroupWise 8 Interoperability Guide
WebAccess MTA
IP Address MTP Port
172.16.5.84 7120
(same as MTA) N/A
"Simplifying Client/Server Access with a GroupWise Name
GroupWise 8 Administration
MTA WebAccess
HTTP Port Agent Port
7184 N/A
N/A 7205
Guide.
to help you plan secondary IP addresses and cluster-
WebAccess
HTTP Port
N/A
7205
(same as agent)
Server" in "Post
