Server Technology PRO2 Switched POPS C2WG12BM User Manual page 93

Network > HTTP/HTTPS
The HTTP/HTTPS page configures server options for HTTP, HTTPS, and SSL, including user-defined certificates.
The page also determines settings for the Sentry Power Manager (SPM) enterprise software product.
To configure HTTP and HTTPS/SSL:
1. Server: Check (or uncheck) the Enable checkboxes to enable/disable support for the HTTP and/or
HTTPS/SSL server options.
2. Port: Type a port number or accept the default HTTP/HTTPS/SSL port numbers as displayed. The HTTP
default port number is 80; the SSL default port number is 443.
Note: SSL-encrypted (HTTPS) must be used for secure website connections.
To configure HTTPS/SSL only:
1. User Certificate: Check (or uncheck) the Enable checkbox to enable/disable support for custom user
certificates.
2. Passphrase: Provide a passphrase (0-63 characters) for the new user certificate. To change the
passphrase, type a new passphrase and check the Change checkbox
3. Stored Files: This section displays a message (described in the following table) to confirm the upload status
of the user certificate and its related public key.
Custom User Certificate Messages
Message
Cert & Key
Cert
No Cert
Factory Encrypted
None
4. Installed Certificate: Shows the type of certificate that was installed – Factory, User, Company.
Using the Web Interface
Description and Valid Values/Range
Both the user certificate and its key were uploaded successfully.
User certificate was uploaded without a key.
User certificate was not uploaded.
User certificate was encrypted and uploaded at product assembly.
Neither the user certificate nor its key were uploaded.
Smart PRO2 – User Guide
•
93
