Sensor Graph Color-Coding

The sensor graph colors change dynamically to communicate operating conditions:
For Line (Load) Status:
Green = Normal
Yellow = low warning/high warning (threshold configured by user)
Red = low alarm/high alarm (threshold configured by user)
Configure line current thresholds and threshold hysteresis at Configuration > System > Lines.
For Temperature Status:
Violet = coldest; low alarm (threshold configured by user)
Blue = cold; low warning (threshold configured by user)
Green = acceptable temperature range
Yellow – warm; high warning (threshold configured by user)
Red = hot; high alarm (threshold configured by user)
Configure low/high temperature thresholds and threshold hysteresis at Configuration > System > Sensors.
For Humidity Status:
Violet = wettest; high alarm (threshold configured by user)
Blue = wet; high warning (threshold configured by user)
Green = acceptable percentage of relative humidity
Yellow = dry; low warning (threshold configured by user)
Orange = driest; low alarm (threshold configured by user)
Configure low/high humidity thresholds and hysteresis at Configuration > System > Sensors.

System Information

This section of the Summary page provides general information:
Firmware: Current firmware version
•
Uptime: Cumulative time the PRO2 has been up and running since the last unit restarted. Shows
•
continuous, real-time system updates with an approximate 5-second automatic refresh. A manual refresh is
not required.
Ethernet NIC S/N: The serial number of the PRO2 derived from the Ethernet NIC.
•
Active Users: Number of active user sessions accessing the firmware. These sessions include serial,
•
Telnet, SSH, and Web sessions. Also shows sessions that an unauthorized user may be attempting to
access the system. The number changes instantly as the number of active user sessions changes. A total
of 4 concurrent web user sessions are allowed (HTTPS or HTTPS).
Note: Depending on the web browser, multiple web accesses from the same machine are often
considered as one active user.
