About Your User Guide

This user guide was designed for data center personnel who monitor power, control outlet actions, and administer
equipment operations in the data center network using Server Technology  firmware, version 8.0x or later, on the
PRO2 product family.
Your guide provides installation, connection, and mounting instructions for the PRO2 product in the equipment
cabinet and illustrates the PRO2's key features in a hardware overview.
Also provided is task-based information for working with the firmware. Step-by-step instructions are presented for
daily operational tasks on the PRO2 when using the firmware Web Interface, including GUI screen samples for
each function. If CLI is preferred, a separate chapter provides detailed command syntax and usage for every
command that can be issued on the PRO2.

PDU Power Pivot


Server Technology's PDU Power Pivot flexible infeed provides a simplified power cord routing to the PRO2 unit

with a design that eliminates bend radius issues.
As illustrated below, the PDU Power Pivot capability can deliver a solution for several types of PDU installations
and mountings, setting the correct cord angle for overhead power, offset overhead power, concrete floor, raised
floor, and intra-rack power.
PDU Power Pivot – Flexible Cord Design
To learn more about PDU Power Pivot and watch a brief video that animates the PDU Power Pivot mounting
angles in the equipment rack, see the Server Technology website at: http://info.servertech.com/PDUpowerpivot
Smart PRO2 – User Guide
Introducing the PRO2
•
7
