Chapter 4: Using the Web Interface
This chapter shows how to work with the firmware GUI (version 8.0x or later) for the PRO2.
Logging In
Logging into the Web interface directs the Web client to the configured IP address of the Smart unit.
To login by Web interface
In the firmware login window, provide a valid username and password, and click OK.
If you enter an invalid username or password, you will be prompted again.
You are given three attempts for a valid username/password combination, after which the session ends and a
protected page will be displayed
Note: The default firmware username/password is admn/admn. There is no "i" in admn.
Quick Tour of the GUI
The web interface provides web-based access to the firmware for the Smart unit. The interface is designed with
three major screen sections shown in the following screen example:
1.
System Header: Displays PRO2 description/location, IP address, and user/access level.
2.
Navigation Bar:
Provides access to PRO2 power monitoring and configuration of operational parameters.
3.
Details Window: Shows status/configuration information based on the option selected in the navigation bar.
Example of PRO2 Firmware Web Interface: Overview > System Page
Note: The optional blinking PRO2 location string (IP address) in the System Header may not work with
all web browsers.
Using the Web Interface
Smart PRO2 – User Guide
•
26
