12.4

Purge air fixture: Sender/receiver unit GM32 Ex

12.5

Purge air fixture: Reflector unit GM32 Ex

12.6

Connection unit, Ex version I/O module

8015594/YV18/V1-8/2017-08 | SICK
Subject to change without notice
Dimensions
Weight
Description
Dimensions
Weight
Connections for auxiliary sub‐
stances
Description
Bus protocol
Dimensions
Weight
Connections for auxiliary sub‐
stances
Description
Analog outputs
Analog inputs
Digital outputs
Digital inputs
Interfaces
Bus protocol
Dimensions (W x H x D)
Weight
291 mm x 280 mm x 161 mm
≤ 9 kg
Flange attachment with connections for purge air and purge
air monitoring
320.9 mm x 360 mm x 220 mm (see dimension drawings for
details)
≤ 7 kg
Purge air
Flange attachment with connections for purge air and purge
air monitoring
CAN (internal system bus)
320.9 mm x 360 mm x 220 mm (see dimension drawings for
details)
≤ 7 kg
Purge air
Serves for on-site connection of the power supply and of data
and signal cables
2 outputs:
0/4 ... 22 mA, 500 Ω
Per module, modules can be selected and extended as
required
2 inputs:
0/4 ... 22 mA, 100 Ω
Per module, modules can be selected and extended as
required
4 outputs:
48 V AC/DC, 0.5 A, 25 W
Per module, modules can be selected and extended as
required
4 inputs:
3.9 V, 4.5 mA, 0.55 W
Per module, modules can be selected and extended as
required
Ethernet via fiber optical cable
Extendable via external control unit (option)
• OPC
• Ethernet TCP/IP (only via fiber optic cable connection)
679 mm x 630 mm x 158 mm
≤ 16 kg
O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
12
TECHNICAL DATA
91
