Commissioning
Parameter
FlowDC inlet configuration
Intermediate pipe length
Inlet diameter
Transition length
Inlet run
Relative sensor position
Result sensor type / mounting type
Result sensor distance / measuring
aid
* Visibility depends on order options or device settings
90
Prerequisite
The 1 measuring point - 2
signal paths option is selected
in Measuring point
configuration parameter.
The 1 measuring point - 2
signal paths option is selected
in Measuring point
configuration parameter.
• The 1 measuring point - 2
signal paths option is
selected in the Measuring
point configuration
parameter.
• The Concentric diameter
change option is selected in
the Inlet configuration
parameter.
• In the Measuring point
configuration parameter,
the 1 measuring point - 2
signal paths option is
selected.
• In the Inlet configuration
parameter, the Concentric
diameter change option is
selected.
The 1 measuring point - 2
signal paths option is selected
in Measuring point
configuration parameter.
The 1 measuring point - 2
signal paths option is selected
in the Measuring point
configuration parameter and
the Off option is not selected
in FlowDC inlet configuration
parameter.
–
–
10.4.4

Checking the installation status

The status of individual parameters can be checked in the Installation status submenu.
Description
Select FlowDC inlet
configuration.
Enter the length of the
intermediate pipe between the
two bends.
Enter the outer diameter of the
pipe before the cross-section
change. For convenience, the
same measuring pipe wall
thickness as for the clamp-on
system is applied.
Enter length of the concentric
diameter change.
Enter length of the available
straight inlet run.
Shows the correct position for
the sensor.
Shows the selected sensor type
and (if applicable
automatically) selected
mounting type.
Shows the calculated sensor
distance and vernier or wire
length (if applicable) required
for installation.
Proline Prosonic Flow W 400 HART
Selection / User Factory setting
entry / User
interface
• Off –
• Single elbow
• Double elbow
• Double elbow 3D
• 45° bend
• 2 x 45° bend
• Concentric
diameter change
*
• Other
Positive floating- –
point number
1 to 10 000 mm –
0 to 20 000 mm –
0 to 300 000 mm –
• 90° –
• 180°
e.g. C-100-A option / –
(2) V-mounting
option
e.g. 201.3 mm / B 21 –
