Configuring The Measuring Point - Endress+Hauser Proline Prosonic Flow W 400 Operating Instructions Manual

Commissioning
Parameter
Volume flow unit
Volume unit
Mass flow unit
Mass unit
Velocity unit
Temperature unit
Density unit
Length unit
86
Parameter overview with brief description
Description
Select volume flow unit.
Result
The selected unit applies to:
• Output
• Low flow cut off
• Simulation process variable
Select volume unit.
Select mass flow unit.
Result
The selected unit applies to:
• Output
• Low flow cut off
• Simulation process variable
Select mass unit.
Select velocity unit.
Effect
The selected unit applies to:
• Flow velocity
• Sound velocity
Select temperature unit.
Result
The selected unit applies to:
• Temperature
• Electronic temperature parameter
(6053)
• External temperature parameter (6080)
• Reference temperature parameter
(1816)
Select density unit.
Result
The selected unit applies to:
• Output
• Simulation process variable
Select the unit of length.
10.4.3

Configuring the measuring point

The "Measuring point " wizard guides you systematically through all the parameters that
must be set for the configuration of the measuring point.
Navigation
"Setup" menu → Measuring point
‣
Measuring point
Measuring point configuration
Proline Prosonic Flow W 400 HART
Selection
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Factory setting
Country-specific:
• m³/h
• ft³/min
Country-specific:
• m³
• ft³
Country-specific:
• kg/h
• lb/min
Country-specific:
• kg
• lb
Depends on country:
• m/s
• ft/s
Country-specific:
• °C
• °F
Country-specific:
• kg/dm³
• lb/ft³
Country-specific:
• mm
• in
→  88
