Analog Devices Advantiv ADV7619 Hardware User's Manual page 26

UG-237
Video ID Codes
(861 Specification) Formats
37, 38 2880 × 576p @ 60 Hz
N/A SVGA 800 × 600p @ 56 Hz
N/A SVGA 800 × 600p @ 60 Hz
N/A SVGA 800 × 600p @ 72 Hz
N/A SVGA 800 × 600p @ 75 Hz
N/A SVGA 800 × 600p @ 85 Hz
N/A SXGA 1280 × 1024p @ 60 Hz
N/A SXGA 1280 × 1024p @ 75 Hz
N/A VGA 640 × 480p @ 60 Hz
N/A VGA 640 × 480p @ 72 Hz
N/A VGA 640 × 480p @ 75 Hz
N/A VGA 640 × 480p @ 85 Hz
N/A VGA 1024 × 768p @ 60 Hz
N/A VGA 1024 × 768p @ 70 Hz
N/A VGA 1024 × 768p @ 75 Hz
N/A VGA 1024 × 768p @ 85 Hz
Recommended Settings if
Pixel Free Run Used and
Repetition DIS_AUTOPRAM_BUFFER = 0
3 PRIM_MODE = 0x5
VID_STD = 0xA
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
0 PRIM_MODE = 0x06
VID_STD = 0x0
Rev. A | Page 26 of 204
Hardware User Guide
Recommended Settings if
Free Run Not Used or Free
Run Used and
DIS_AUTO_PARAM_BUFFER = 1
PRIM_MODE = 0x6
VID_STD = 0x2
PRIM_MODE = 0x06
VID_STD = 0x0
PRIM_MODE = 0x06
VID_STD = 0x1
PRIM_MODE = 0x06
VID_STD = 0x2
PRIM_MODE = 0x06
VID_STD = 0x3
PRIM_MODE = 0x06
VID_STD = 0x04
PRIM_MODE = 0x06
VID_STD = 0x05
PRIM_MODE = 0x06
VID_STD = 0x06
PRIM_MODE = 0x06
VID_STD = 0x08
PRIM_MODE = 0x06
VID_STD = 0x09
PRIM_MODE = 0x06
VID_STD = 0x0A
PRIM_MODE = 0x06
VID_STD = 0x0B
PRIM_MODE = 0x06
VID_STD = 0x0C
PRIM_MODE = 0x06
VID_STD = 0x0D
PRIM_MODE = 0x06
VID_STD = 0x0E
PRIM_MODE = 0x06
VID_STD = 0x0F
