UG-237
Pin No. Mnemonic Type
121 HPA_B Miscellaneous
digital
122 RXB_5V HDMI input
123 DDCA_SCL HDMI input
124 DDCA_SDA HDMI input
125 HPA_A/INT2 Miscellaneous
digital
126 RXA_5V HDMI input
127 NC No connect
128 NC No connect
Description
Hot Plug Assert signal output for HDMI Port B.
5 V Detect Pin for Port B in the HDMI Interface.
HDCP Slave Serial Clock Port A. DDCA_SCL is a 3.3 V input that is 5 V tolerant.
HDCP Slave Serial Data Port A. DDCA_SDA is a 3.3 V input that is 5 V tolerant.
A dual function pin that can be configured to output Hot Plug Assert signal (for HDMI Port A)
or an Interrupt2 signal.
5 V Detect Pin for Port A in the HDMI Interface.
No connect.
No connect.
Rev. A | Page 14 of 204
