UG-237
Pin No. Mnemonic Type
53 DVDD Power
54 P31 Digital video
output
55 P30 Digital video
output
56 P29 Digital video
output
57 P28 Digital video
output
58 P27 Digital video
output
59 P26 Digital video
output
60 P25 Digital video
output
61 P24 Digital video
output
62 LLC Digital video
output
63 DVDD Power
64 DVDD Power
65 DVDDIO Power
66 P23 Digital video
output
67 P22 Digital video
output
68 P21 Digital video
output
69 P20 Digital video
output
70 P19 Digital video
output
71 P18 Digital video
output
72 P17 Digital video
output
73 P16 Digital video
output
74 P15 Digital video
output
75 P14 Digital video
output
76 P13 Digital video
output
77 DVDDIO Power
78 P12 Digital video
output
79 DVDD Power
80 P11 Digital video
output
81 P10 Digital video
output
82 P9 Digital video
output
83 P8 Digital video
output
84 P7 Digital video
output
85 P6 Digital video
output
86 P5 Digital video
output
Description
Digital Core Supply Voltage (1.8 V).
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Pixel Output Clock for the Pixel Data (Range is 13.5 MHz to 170 MHz).
Digital Core Supply Voltage (1.8 V).
Digital Core Supply Voltage (1.8 V).
Digital I/O Supply Voltage (3.3 V).
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Digital I/O Supply Voltage (3.3 V).
Video Pixel Output Port.
Digital Core Supply Voltage (1.8 V).
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Rev. A | Page 12 of 204
