Analog Devices Advantiv ADV7619 Hardware User's Manual page 166

UG-237
CEC_WAKE_OPCODE4[7:0] , Addr 80 (CEC), Address 0x7C[7:0]
CEC_WAKE_OPCODE4
This value can be set to a CEC opcode that requires a response. On receipt of this opcode the Rx generates an interrupt that can be used
to alert the system that a CEC opcode of interest has been received and requires a response.
Function
CEC_WAKE_OPCODE4[7:0]
00001101 (default)
xxxxxxxx
CEC_WAKE_OPCODE5[7:0] , Addr 80 (CEC), Address 0x7D[7:0]
CEC_WAKE_OPCODE5
This value can be set to a CEC opcode that requires a response. On receipt of this opcode, the Rx generates an interrupt that can be used
to alert the system that a CEC opcode of interest has been received and requires a response.
Function
CEC_WAKE_OPCODE5[7:0]
01110000 (default)
xxxxxxxx
CEC_WAKE_OPCODE6[7:0] , Addr 80 (CEC), Address 0x7E[7:0]
CEC_WAKE_OPCODE6
This value can be set to a CEC opcode that requires a response. On receipt of this opcode the Rx generates an interrupt that can be used
to alert the system that a CEC opcode of interest has been received and requires a response.
Function
CEC_WAKE_OPCODE6[7:0]
01000010 (default)
xxxxxxxx
CEC_WAKE_OPCODE7[7:0] , Addr 80 (CEC), Address 0x7F[7:0]
CEC_WAKE_OPCODE7
This value can be set to a CEC opcode that requires a response. On receipt of this opcode the Rx generates an interrupt that can be used
to alert the system that a CEC opcode of interest has been received and requires a response.
Function
CEC_WAKE_OPCODE7[7:0]
01000001 (default)
xxxxxxxx
Description
TEXT VIEW ON
User specified OPCODE to respond to
Description
SYSTEM AUDIO MODE REQUEST
User specified OPCODE to respond to
Description
DECK CONTROL
User specified OPCODE to respond to
Description
PLAY
User specified OPCODE to respond to
Rev. A | Page 166 of 204
Hardware User Guide
