INTRODUCTION TO THE COMPONENT PROCESSOR

A simplified block diagram of the the component processor (CP) on the ADV7619 is shown in Figure 40. Data is supplied to the CP from
the data preprocessor (DPP). The CP circuitry is activated under the control of PRIM_MODE[3:0] and VID_STD[5:0] .
The CP is designed to run at speeds of up to 170 MHz. Therefore HDMI video with pixel clock frequencies above 170 MHz must be
routed directly to Video Output Formatter bypassing Data Preprocessor (DPP) and Component Preprocessor (CP). For more information
about bypassing DPP and CP refer to Pass Through Mode section.
The CP is activated for the following modes of operation:
•
Manual and automatic gain control
•
Manual offset correction
•
Saturation
•
Insertion of timing codes and blanking data
The CP also has the following capabilities:
•
Generates HSync, VSync, FIELD, and data enable (DE) timing reference outputs
•
Color space conversion
•
Color control adjustment

CLAMP OPERATION

The CP contains a digital fine clamp block. Its main purposes is to allow a clamp to operate even if the input signal is coming from a
digital source
The digital fine clamp operates in three separate feedback loops, one for each channel. The incoming video signal level is measured at the
back porch. The level error, that is, clamp error, is compensated for by subtracting or adding a digital number to the data stream.
The digital clamp loop can be operated in an automatic or a manual mode with the following options:
•
The clamp values for Channel B and Channel C can be set manually. This is the recommended mode.
•
The clamp value is determined automatically on a line-by-line basis.
•
The clamp loops can be frozen. This means that the currently active offsets will no longer be updated but will be applied
permanently.
•
The clamp value for channel A can be set manually (static value).
STANDARD
IDENTIFICATION
(STDI)
DIGITAL
GAIN
DELAY FINE
CONTROL
CLAMP
Figure 40. Component Processor Block Diagram
