MPU_STIM_INTRQ_MB1 , IO, Address 0x4B[7]
INT1 interrupt mask for manual forced interrupt signal. When set the manual forced interrupt will trigger the INT1 interrupt and
MPU_STIM_INTRQ_ST will indicate the interrupt status.
Function
MPU_STIM_INTRQ_MB1
0 (default)
1
MPU_STIM_INTRQ_MB2 , IO, Address 0x4A[7]
INT2 interrupt mask for manual forced interrupt signal. When set the manual forced interrupt will trigger the INT2 interrupt and
MPU_STIM_INTRQ_ST will indicate the interrupt status.
Function
MPU_STIM_INTRQ_MB2
0 (default)
1
Multiple Interrupt Events
If an interrupt event occurs, and then a second interrupt event occurs before the system controller has cleared or masked the first
interrupt event, the ADV7619 does not generate a second interrupt signal. The system controller should check all unmasked interrupt
status bits as more than one may be active.
Table 70 lists the interrupt registers available and a brief description of their functions. For more details on the functionality of these
interrupt registers, refer to the ADV7619 Software Manual. Refer to the IO map section of the ADV7619 Software Manual for details of
the CP core interrupts and HDMI core interrupts.
Table 70. Interrupt Functions Available in ADV7619
Interrupt Register Location
Interrupt Status 1 IO Map, Address 0x43
Interrupt Status 2 IO Map, Address 0x48
Interrupt Status 6 IO Map, Address 0x5C
HDMI Lvl Int Status 1 IO Map, Address 0x61
HDMI Lvl Int Status 2 IO Map, Address 0x66
HDMI Lvl Int Status 3 IO Map, Address 0x6B
HDMI Lvl Int Status 4 IO Map, Address 0x70
HDMI Edg Int Status 1 IO Map, Address 0x7A
HDMI Edg Int Status 2 IO Map, Address 0x7F
HDMI Edg Int Status 3 IO Map, Address 0x84
HDMI Edg Int Status 4 IO Map, Address 0x89
HDMI Edg Int Status 5 IO Map, Address 0x8E
Description
Disables manual forced interrupt for INT1
Enables manual forced interrupt for INT1
Description
Disables manual forced interrupt for INT2
Enables manual forced interrupt for INT2
Description
CP interrupt status for STDI
CP interrupt status forces manual interrupt
STDI channels interrupt status
HDMI interrupt status for HDMI InfoFrame packets
HDMI interrupt status for audio processing changes
HDMI interrupt status for HDMI video parameters and cable detection
HDMI interrupt status for cable detection and encryption
HDMI interrupt status for newly received HDMI InfoFrame packets
HDMI interrupt status for audio FIFO, clock regeneration and packet errors
HDMI interrupt status for updates in deep color, video, AKSV, and audio
HDMI interrupt status for changes in InfoFrame checksum errors
HDMI interrupt status for background measurements and changes in Inforframe
checksum error
