UG-237

PIN CONFIGURATION AND FUNCTION DESCRIPTIONS

GND
1
PIN 1
CVDD
2
RXA_C–
3
RXA_C+ 4
TVDD
5
RXA_0–
6
RXA_0+
7
TVDD
8
RXA_1–
9
RXA_1+
10
TVDD
11
RXA_2– 12
RXA_2+ 13
CVDD 14
GND
15
TEST1
16
DVDD 17
TEST2 18
CVDD
19
RXB_C–
20
RXB_C+ 21
TVDD 22
RXB_0–
23
RXB_0+
24
TVDD
25
RXB_1–
26
RXB_1+
27
TVDD 28
RXB_2– 29
RXB_2+
30
CVDD
31
GND
32
NOTES
1. NC = NO CONNECT. DO NOT CONENCT TO THIS PIN.
2. THE EXPOSED PADDLE SHOULD BE CONNECTED TO GROUND.
Table 4. Pin Function Descriptions
Pin No. Mnemonic Type
0 GND Ground
1 GND Ground
2 CVDD Power
3 RXA_C− HDMI input
4 RXA_C+ HDMI input
5 TVDD Power
6 RXA_0− HDMI input
7 RXA_0+ HDMI input
8 TVDD Power
9 RXA_1− HDMI input
10 RXA_1+ HDMI input
ADV7619
TOP VIEW
(Not to Scale)
Figure 3. Pin Configuration
Description
Ground.
Ground.
HDMI Analog Block Supply Voltage (1.8 V).
Digital Input Clock Complement of Port A in the HDMI Interface.
Digital Input Clock True of Port A in the HDMI Interface.
Terminator Supply Voltage (3.3 V).
Digital Input Channel 0 Complement of Port A in the HDMI Interface.
Digital Input Channel 0 True of Port A in the HDMI Interface.
Terminator Supply Voltage (3.3 V).
Digital Input Channel 1 Complement of Port A in the HDMI Interface.
Digital Input Channel 1 True of Port A in the HDMI Interface.
Rev. A | Page 10 of 204
Hardware User Guide
96 NC
VS/FIELD/ALSB
95
94 HS
93 DE
DVDDIO
92
P0
91
P1
90
P2
89
P3
88
P4
87
P5
86
85 P6
84 P7
83 P8
P9
82
P10
81
80 P11
79 DVDD
P12
78
DVDDIO
77
76 P13
75 P14
P15
74
P16
73
P17
72
P18
71
P19
70
69 P20
68 P21
P22
67
66 P23
65 DVDDIO
