Hardware User Guide
Function
AUD_INF_CKS_ERR_ST
0 (default)
1
AVI_INF_CKS_ERR_ST , IO, Address 0x89[4] (Read Only)
Latched status of AVI InfoFrame checksum error interrupt. Once set, this bit will remain high until the interrupt is cleared via
AVI_INF_CKS_ERR_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
AVI_INF_CKS_ERR_ST
0 (default)
1
RI_EXPIRED_B_ST , IO, Address 0x89[3] (Read Only)
Latched status of Port B Ri expired Interrupt. Once set this bit will remain high until the interrupt has been cleared via
RI_EXPIRED_B_CLR. This bit is only valid if enabled via corresponding the INT1 or INT2 interrupt mask bit
Function
RI_EXPIRED_B_ST
0 (default)
1
RI_EXPIRED_A_ST , IO, Address 0x89[2] (Read Only)
Latched status of Port A Ri expired interrupt. Once set, this bit will remain high until the interrupt is cleared via RI_EXPIRED_A_CLR.
This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
RI_EXPIRED_A_ST
0 (default)
1
AKSV_UPDATE_B_ST , IO, Address 0x89[1] (Read Only)
Latched status of Port B AKSV Update Interrupt. Once set this bit will remain high until the interrupt has been cleared via
AKSV_UPDATE_B_CLR. This bit is only valid if enabled via corresponding the INT1 or INT2 interrupt mask bit
Function
AKSV_UPDATE_B_ST
0 (default)
1
AKSV_UPDATE_A_ST , IO, Address 0x89[0] (Read Only)
Latched status of Port A AKSV update interrupt. Once set, this bit will remain high until the interrupt is cleared via
AKSV_UPDATE_A_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
AKSV_UPDATE_A_ST
0 (default)
1
HDMI Edg Int Status 5 register consists of the VS_INF_CKS_ERR_ST field.
Description
No change in audio InfoFrame checksum error
An audio InfoFrame checksum error has triggered this interrupt
Description
No change in AVI InfoFrame checksum error
An AVI InfoFrame checksum error has triggered this interrupt
Description
No Ri expired on Port B
Ri expired on Port B
Description
No Ri expired on Port A
Ri expired on Port A
Description
No AKSV updates on Port B
Detected a write access to the AKSV register on Port B
Description
No AKSV updates on Port A
Detected a write access to the AKSV register on Port A
