In the RGB case (refer to Figure 38), the ADV7619 has the programmability to control manually the RGB limited/full range regardless of
the ITC bit.
Y[1:0] = 01b, 10b, 11b
YCbCr MODE
START
YCbCr COLORIMETRY
C[1:0] = xxb?
C[1:0] = 00b
EXTENDED COLORIMETRY
EC[2:0] = 001b
xvYCC709
Figure 36. HDMI Auto CSC Flowchart (Case YCbCr-1)
YCbCr COLORIMETRY
C[1:0] = 00b
VIDEO FORMAT IDENTIFICATION CODE
CHECK VIC[6:0] VALUES IN AVI INFOFRAME
VIC[6:0] == 0d VIC[6:0] == 32d
VIC[6:0] == 1d VIC[6:0] == 33d
VIC[6:0] == 34d
VIC[6:0] == 4d
VIC[6:0] == 5d VIC[6:0] == 39d
VIC[6:0] == 16d VIC[6:0] == 40d
VIC[6:0] == 19d VIC[6:0] == 46d
VIC[6:0] == 20d VIC[6:0] == 47d
VIC[6:0] == 31d VIC[6:0] >= 60d
TRUE
YUV709
Figure 37. HDMI Auto CSC Flowchart (Case YCbCr-2)
Rev. A | Page 110 of 204
C[1:0] = 11b
EC[2:0] = xxxb?
EC[2:0] = 000b
xvYCC601 REMAIN CURRENT STATUS
FALSE
YUV601
Hardware User Guide
C[1:0] = 10b
YUV601
EC[2:0] != (001 OR 000)
