Analog Devices Advantiv ADV7619 Hardware User's Manual page 141

Hardware User Guide
Function
START_VS[3:0]
0x0 (default)
0x0 to 0x7
0x8 to 0xF
Table 60. Controlling the Start of the VS Timing Signal
START_VS[3:0] Hex
0000 (default) 0x0
0001 0x1
0011 0x3
0111 0x0
1111 0xF
1101 0xD
1000 0x8
1 VS closer to start of active video.
2
VS away from start of active video.
END_VS[3:0] , Addr 44 (CP), Address 0x7F[3:0]
A control to shift the position of the trailing edge of the VSync output by the CP core.
This register stores a signed value in a twos complement format. SEND_VS[3:0] is the number of lines by which the trailing edge of the
VSync is shifted (for example, 0x0F corresponds to a shift of one line toward the active video, 0x01 corresponds to a shift of 1 line away
from the active video).
Function
END_VS[3:0] Description
0x0 (default) Default value.
0x0 to 0x7 The trailing edge of the VSync is shifted toward the active video.
0x8 to 0xF The trailing edge of the VSync is shifted away from the active video.
Table 61. Controlling the End of the VS Timing Signal
END_VS[3:0] Hex
0000 (default) 0x0
0001 0x1
0011 0x3
0111 0x0
1111 0xF
1101 0xD
1000 0x8
1
VS closer to start of active video.
2 VS away from start of active video.
START_VS_EVEN[3:0] , Addr 44 (CP), Address 0x89[7:4]
A control to shift the position of the leading edge of the Vsync output by the CP core.
This register stores a signed value in a twos complement format. START_VS_EVEN[3:0] is the number of lines by which the leading edge
of the Vsync is shifted (for example, 0x0F corresponds to a shift by one line toward the active video, 0x01 corresponds to a shift of 1 line
away from the active video).
Function
START_VS_EVEN[3:0]
0x0 to 0x7
0x8 to 0xF
Description
Default value.
The leading edge of the VSync is shifted toward the active video.
The leading edge of the VSync is shifted away from the active video.
Result
No move (default)
1 HS shift later than default
3 HS shift later than default
7 HS shift later than default
1 HS shift earlier than default
3 HS shift earlier than default
8 HS shift earlier than default
Result
No move (default)
1 HS shift later than default
3 HS shift later than default
7 HS shift later than default
1 HS shift earlier than default
3 HS shift earlier than default
8 HS shift earlier than default
Description
The leading edge of the even Vsync is shifted toward the active video.
The leading edge of the even Vsync is shifted away from the active video.
1
2
1
2
Rev. A | Page 141 of 204
UG-237
Note
Minimum →
Maximum →
Minimum ←
Maximum ←
Note
Minimum →
Maximum →
Minimum ←
Maximum ←
