Analog Devices Advantiv ADV7619 Hardware User's Manual page 196

UG-237
Pin No. Mnemonic Type
49 P34 Digital Output
50 P33 Digital Output
51 P32 Digital Output
52 DVDDIO Power
53 DVDD Power
54 P31 Digital Output
55 P30 Digital Output
56 P29 Digital Output
57 P28 Digital Output
58 P27 Digital Output
59 P26 Digital Output
60 P25 Digital Output
61 P24 Digital Output
62 LLC Digital Output
63 DVDD Power
64 DVDD Power
65 DVDDIO Power
66 P23 Digital Output
67 P22 Digital Output
68 P21 Digital Output
69 P20 Digital Output
70 P19 Digital Output
71 P18 Digital Output
72 P17 Digital Output
73 P16 Digital Output
74 P15 Digital Output
75 P14 Digital Output
76 P13 Digital Output
77 DVDDIO Power
78 P12 Digital Output
79 DVDD Power
80 P11 Digital Output
81 P10 Digital Output
82 P9 Digital Output
83 P8 Digital Output
84 P7 Digital Output
85 P6 Digital Output
86 P5 Digital Output
87 P4 Digital Output
88 P3 Digital Output
89 P2 Digital Output
90 P1 Digital Output
91 P0 Digital Output
92 DVDDIO Power
93 DE Digital Output
94 HS Digital Output
95 VS/FIELD/ALSB Digital I/O
96 NC No connect
97 NC No connect
98 NC No connect
99 NC No connect
100 AP0 Digital Output
101 AP1/I2S_TDM Digital Output
Recommended Configuration if Not Used
Float this pin
Float this pin
Float this pin
Digital I/O Supply Voltage (3.3 V)
Digital Core Supply Voltage (1.8 V)
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
This pin is always connected to the pixel clock input
Digital Core Supply Voltage (1.8 V)
Digital Core Supply Voltage (1.8 V)
Digital I/O Supply Voltage (3.3 V)
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Digital I/O Supply Voltage (3.3 V)
Float this pin
Digital Core Supply Voltage (1.8 V)
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Digital I/O Supply Voltage (3.3 V)
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Rev. A | Page 196 of 204
Hardware User Guide
