Hardware User Guide
Function
STDI_DATA_VALID_EDGE_SEL
0
1 (default)
CP_LOCK, CP_UNLOCK
CP_UNLOCK_RAW is programmable as either an edge sensitive bit or a level sensitive bit using the following control. Note that this
control also configures whether an interrupt is generated only on the rising edge of CP_UNLOCK_RAW, or on both edges.
CP_LOCK_UNLOCK_EDGE_SEL , IO, Address 0x41[5]
A control to configure the functionality of the CP_LOCK, CP_UNLOCK interrupts.
Function
CP_LOCK_UNLOCK_EDGE_SEL
0
1 (default)
CP_LOCK_ST , IO, Address 0x43[2] (Read Only)
For a detailed description of this function, see the entry in the List of Interrupt Status Registers section.
CP_UNLOCK_ST , IO, Address 0x43[3] (Read Only)
For a detailed description of this function, see the entry in the List of Interrupt Status Registers section.
HDMI Interrupts Validity Checking Process
All HDMI interrupts have a set of conditions that must be taken into account for validation in the display firmware. When the ADV7619
interrupts the display controller for an HDMI interrupt, the host must check that all validity conditions for that interrupt are met before
processing that interrupt.
For simplicity, HDMI interrupts can be subdivided into three groups, as listed in the following sections.
Group 1 HDMI Interrupts
The interrupts listed in Table 71 are valid irrespective of the mode in which the ADV7619 is configured, that is: HDMI mode
(PRIM_MODE set to values 0x05 or 0x06).
Table 71. HDMI Interrupts Group 1
Interrupts
TMDS_CLK_A
TMDS_CLK_B
CABLE_DET_A
CABLE_DET_B
Group 2 HDMI Interrupts
The interrupts listed in Table 72 are valid on the condition that the ADV7619 is configured in HMDI mode.
Table 72. HDMI Interrupts Group 2
Interrupts
INTERNAL_MUTE
VIDEO_PLL_LCK
AKSV_UPDATE
Description
Generate interrupt for a low to high change in STDI_VALID status
Generate interrupt for a low to high or a high to low change in STDI_VALID status
Description
Generate interrupt for a low to high change in CP_LOCK,UNLOCK status for Ch1.
Generate interrupt for a low to high or a high to low change in CP_LOCK,UNLOCK status for Ch1.
Rev. A | Page 175 of 204
UG-237
