Analog Devices Advantiv ADV7619 Hardware User's Manual page 197

Hardware User Guide
Pin No. Mnemonic Type
102 AP2 Digital Output
103 AP3 Digital Output
104 AP4 Digital Output
105 SCLK/INT2 Digital Output
106 AP5 Digital Output
107 MCLK/INT2 Digital Output
108 DVDD Power
109 SDA Digital I/O
110 SCL Digital Input
111 INT1 Digital Output
112 RESET Digital Input
113 CS Digital Input
114 PVDD Power
115 XTALP Miscellaneous
Analog
116 XTALN
Miscellaneous
Analog
117 DVDD Power
118 CEC Digital I/O
119 DDCB_SCL Digital Input
120 DDCB_SDA Digital I/O
121 HPA_B Digital Output
122 RXB_5V Digital Input
123 DDCA_SCL Digital Input
124 DDCA_SDA Digital I/O
125 HPA_A/INT2 Digital Output
126 RXA_5V Digital Input
127 NC No connect
128 NC No connect
Recommended Configuration if Not Used
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Digital Core Supply Voltage (1.8 V)
This pin is always connected to the I
This pin is always connected to the I
Float this pin
Level of this pin should be controlled by an external processor
Float this pin
PLL Supply Voltage (1.8V)
Input Pin for 28.63636 MHz Crystal or an External 1.8 V, 28.63636 MHz Clock Oscillator
Source to Clock the ADV7619
Crystal Input. Input pin for 28.63636 MHz crystal
Digital Core Supply Voltage (1.8 V)
Float this pin
Connect this pin to ground via a 10k ohm resistor
Float this pin
Float this pin
If RXB_5V is not used, float RXB_5V and set DIS_CABLE_DET_RST to 0. In case where Port B
is not used, RXB_5V can be left unconnected.
Connect this pin to ground via a 10k ohm resistor
Float this pin
Float this pin
If RXA_5V is not used, float RXA_5V and set DIS_CABLE_DET_RST to 0. In the case where
Port A is not used, RXA_5V can be left unconnected.
Float this pin
Float this pin
Rev. A | Page 197 of 204
2
C data line of a control processor
2
C clock line of a control processor
UG-237
