FIELD FUNCTION DESCRIPTIONS

Throughout this user guide, a series of function tables are provided. The function of a field is described in a table preceded by the bit
name, a short function description, the I
The detailed description consists of:
•
For a readable field, the values the field can take
•
For a writable field, the values the field can be set to
Example Field Function Description
This section provides an example of a field function table followed by a description of each part of the table.
PRIM_MODE[3:0], IO Map, Address 0x01[3:0].
A control to select the primary mode of operation of the decoder.
Function
PRIM_MODE[3:0]
0000
0001
0010
0011
0100
0101
0110 (default)
0111 to 1111
In this example
•
The name of the field is PRIM_MODE and it is four bit long.
•
2
Address 0x01 is the I C location of the field in big endian format (MSB first, LSB last).
•
The address is followed by a detailed description of the field.
•
The first column of the table lists values the field can take or can be set to. These values are in binary format if not preceded by 0x or
in hexadecimal format if preceded by 0x.
•
The second column describes the function of each field for each value the field can take or can be set to. Values are in binary format.

REFERENCES

CEA, CEA-861-D, A DTV Profile for Uncompressed High Speed Digital Interfaces, Revision D, July 18, 2006.
Digital Content Protection (DCP) LLC, High-Bandwidth Digital Content Protection System, Revision 1.4, July 8, 2009.
HDMI Licensing and LLC, High-Definition Multimedia Interface, Revision 1.4a, March 4, 2010.
ITU, ITU-R BT.656-4, Interface for Digital Component Video Signals in 525-Line and 625-Line Television Systems Operating
at the 4:2:2 Level of Recommendation ITU-R BT.601, February 1998.
2
C map, the register location within the I
Rev. A | Page 6 of 204
Hardware User Guide
2
C map, and a detailed description of the field.
Description
Reserved
Reserved
Reserved
Reserved
Reserved
HDMI-Comp
HDMI-GR
Reserved
