Analog Devices Advantiv ADV7619 Hardware User's Manual page 11

Hardware User Guide
Pin No. Mnemonic Type
11 TVDD Power
12 RXA_2− HDMI input
13 RXA_2+ HDMI input
14 CVDD Power
15 GND Ground
16 TEST1 Test
17 DVDD Power
18 TEST2 Test
19 CVDD Power
20 RXB_C− HDMI input
21 RXB_C+ HDMI input
22 TVDD Power
23 RXB_0− HDMI input
24 RXB_0+ HDMI input
25 TVDD Power
26 RXB_1− HDMI input
27 RXB_1+ HDMI input
28 TVDD Power
29 RXB_2− HDMI input
30 RXB_2+ HDMI input
31 CVDD Power
32 GND Ground
33 NC No connect
34 DVDD Power
35 P47 Digital video
output
36 P46 Digital video
output
37 P45 Digital video
output
38 P44 Digital video
output
39 P43 Digital video
output
40 DVDDIO Power
41 P42 Digital video
output
42 P41 Digital video
output
43 P40 Digital video
output
44 P39 Digital video
output
45 P38 Digital video
output
46 P37 Digital video
output
47 P36 Digital video
output
48 P35 Digital video
output
49 P34 Digital video
output
50 P33 Digital video
output
51 P32 Digital video
output
52 DVDDIO Power
Description
Terminator Supply Voltage (3.3 V).
Digital Input Channel 2 Complement of Port A in the HDMI Interface.
Digital Input Channel 2 True of Port A in the HDMI Interface.
HDMI Analog Block Supply Voltage (1.8 V).
Ground.
This pin must be left floating.
Digital Core Supply Voltage (1.8 V)
This pin must be left floating.
HDMI Analog Block Supply Voltage (1.8 V).
Digital Input Clock Complement of Port B in the HDMI Interface.
Digital Input Clock True of Port B in the HDMI Interface.
Terminator Supply Voltage (3.3 V).
Digital Input Channel 0 Complement of Port B in the HDMI Interface.
Digital Input Channel 0 True of Port B in the HDMI Interface.
Terminator Supply Voltage (3.3 V).
Digital Input Channel 1 Complement of Port B in the HDMI Interface.
Digital Input Channel 1 True of Port B in the HDMI Interface.
Terminator Supply Voltage (3.3 V).
Digital Input Channel 2 Complement of Port B in the HDMI Interface.
Digital Input Channel 2 True of Port B in the HDMI Interface.
HDMI Analog Block Supply Voltage (1.8 V).
Ground.
No connect.
Digital Core Supply Voltage (1.8 V).
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Digital I/O Supply Voltage (3.3 V).
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Video Pixel Output Port.
Digital I/O Supply Voltage (3.3 V).
