Section 4: System Operation
Trouble 04 – AC or DC input power trouble:
[01] Zone 001 - 128 AC or DC input power trouble: An AC or DC input power trouble has been detected on a PGX934 PIR + Camera.
[02] Keypad AC or DC input power trouble: A keypad has an AC or DC input power trouble.
[03] Siren 01 - 16 AC: A siren has an AC or DC input power trouble.
[04] Repeater 01 - 08 AC: A wireless repeater has an AC or DC input power trouble.
[05] HSM2300 01 - 04 AC: An HSM2300 has an AC or DC input power trouble.
[06] HSM2204 01 - 04 AC: An HSM2204 has an AC or DC input power trouble.
[07] Panel AC: The alarm controller has an AC failure condition.
[08] HSM3204CX AC: A corbus repeater has an AC or DC input power trouble.
[09] HSM3350 AC: The 3A power supply has an AC or DC input power trouble.
Trouble 05 – Device Faults:
[01] Zone 001 - 128: A zone is in supervisory fault.
[02] Keypad 01 - 16: A wireless or hardwired keypad is in supervisory fault.
[03] Siren 01 - 16: A siren is in supervisory fault.
[04] Repeater 01 - 08: A wireless repeater is in fault (supervisory or loss of AC/DC).
[06] Device Mask: A detection mechanism on the sensor is masked.
[07] Gas Trouble:A gas sensor is in fault.
[08] Heat Trouble: A temperature sensor is in fault or a temperature senso reaches the high temperature warning threshold.
[09] CO Trouble: A CO sensor is in fault.
[10] Freeze Trouble: A temperature sensor falls below the low temperature warning threshold.
[11] Probe Disconn.: The probe on the flood detector or the temperature detector is disconnected.
[12] Fire Trouble: A smoke sensor is in fault, or there is an open loop ondition for 2-wire or 4-wire smoke detector.
Trouble 06 – Device Low Battery:
[01] Zone 001- 128: Wireless zone has a low battery.
[02] Keypad 01-16: Keypad has a low battery.
[03] Siren 01 - 16: Siren has a low battery.
[04] Repeater 01 - 08: Repeater has a low battery.
[05] User 01 - 1000: Wireless Key has a low battery.
Trouble 07 – Device Tampers:
[01] Zone 001 - 128 Tamper: A wireless or hardwired zone is in tamper.
[02] Siren 01 - 16 Tamper: A wireless siren is in tamper.
[03] Repeater 01 - 08 Tamper: A wireless repeater is in tamper.
[04] Audio Station 01 - 04 Tamper: An audio station connected to an HSM2955 is in tamper.
Trouble 08 – RF Delinquency Trouble:
[01] Zone 001 - 128 RF Delinquency: No response from a wireless zone for 13 minutes. This trouble prevents arming until acknowledged or
cleared using [*][2].
[02] Keypad 01 - 16 RF Delinquency: No response from a wireless keypad for 13 minutes.
[03] Siren 01 - 16 RF Delinquency: No response from a wireless siren for 13 minutes.
[04] Repeater 01 - 16 RF Delinquency: No response from a wireless repeater for 13 minutes.
