Section 2: Installation
HSM3408 in HSC3010 Enclosure
The following diagram indicates the routing of power limited and non-power limited wiring inside the enclosure. Battery
leads and AC cord are non-power limited. All other wiring is power limited.
Figure 2-5 HSM3408 in HSC3010C Enclosure
HSM3408 and HSM3350 Mounting in HSC3020C Enclosure
The following diagram indicates the available mounting locations of the HSM3350, HSM3408, power supply module and
tamper bracket inside the HSC3020C enclosure.
HSM3350
HSM3408
HSM3408
Figure 2-6 HSM3350 and HSM3408 Modules in HSC3020C Enclosure
