Trouble [2] Module Battery Trouble Press [02] to determine specific trouble
[04] 4 High Current output 1-4 Low
Battery (HSM2204)
HSM2204 battery less than
11.5VDC.
NOTE: This trouble condition will not
clear until the battery voltage is
12.5VDC min., under load. Charge
battery. It may be low due to a long
period without AC.
[05] 4 High Current output 1-4 No
Battery (HSM2204)
Enter 05 to view which HSM2204
does not have a battery connected.
[07] Power Supply 1-4 Low Battery
(HSM2300)
Enter 07 to view which HSM2300
has a battery voltage less than
11.5V.
[08] Power Supply 1-4 No Battery
(HSM2300)
Enter 08 to view which HSM2300
does not have a battery connected.
[10] HSM3204CX low battery
Enter 10 to view which HSM3204X
has a battery voltage less than 11.5V
[11] HSM3204CX no battery
Enter 11 to view which HSM3204CX
does not have a battery connected.
[13] HSM3350 low battery 1
Enter 13 to view which HSM3350
has a battery voltage less than
11.5V.
Section 7: Troubleshooting
Verify voltage measured across DC input terminals is 16-18 VDC. Replace HSM65W power supply
adapter if required.
Connect battery, remove AC power.
Verify measured voltage across Aux terminals is 12.5VDC min.
Replace battery if it is no longer able to hold a charge due to age.
Verify battery is connected.
Ensure battery leads are connected with the right polarity.
Connect battery, remove AC power.
Verify measured voltage across Aux terminals is 12.5VDC min
Verify voltage measured across DC input terminals is 16-18 VAC. Replace HSM65W power supply
adapter if required.
Connect battery, remove AC power.
Verify measured voltage across Aux terminals is 12.5VDC min.
Replace battery if it is no longer able to hold a charge due to age.
Verify battery is connected.
Ensure battery leads are connected with the right polarity.
Connect battery, remove AC power.
Verify measured voltage across Aux terminals is 12.5VDC min
Verify voltage measured across DC input terminals is 16-18 VAC. Replace HSM65W power supply
adapter if required.
Connect battery, remove AC power.
Verify measured voltage across Aux terminals is 12.5VDC min.
Replace battery if it is no longer able to hold a charge due to age.
Verify voltage measured across DC input terminals is 16-18 VAC. Replace HSM65W power supply
adapter if required.
Connect battery, remove AC power.
Verify measured voltage across Aux terminals is 12.5VDC min.
Replace battery if it is no longer able to hold a charge due to age.
Verify voltage measured across DC input terminals is 16-18 VAC. Replace HSM65W power supply
adapter if required.
Connect battery, remove AC power.
Verify measured voltage across Aux terminals is 12.5VDC min.
Replace battery if it is no longer able to hold a charge due to age.
