[003] Openings/ Closing
These options control which receiver paths are enabled for Partition 1-8 Opening and Closing event reporting codes. To
assign an event to a receiver, select one of the following options:
[01] Receiver 1
[02] Receiver 2
[03] Receiver 3
[04] Receiver 4
[350] Communicator Formats
Use this programming option to assign a communicator format to each of the four receivers programmed in section [301].
The available communicator formats are as follows:
03
04
To assign a communications format, select a receiver (option [001]-[004]) then enter the 2-digit code corresponding to the
chosen format. For detailed descriptions of each format, see "Reporting Codes" on page 247.
[377] Communication Variables
[001] – Swinger Shutdown
Alarms/Restores
This value defines the number of communication attempts made for alarm/restore events, per zone, before the zone goes
into swinger shutdown. Valid entries are 000 to 014. For CP-01, entries are from 001-006.
Once the programmed number of alarm/restore events have been communicated, no further alarm/restore events for the
zone are communicated until swinger shutdown is reset. The last restore event is not communicated until swinger is cleared.
For example, if the swinger shutdown limit for zone alarms is set to [003], the cycle is as follows: alarm/restore, alarm/restore,
alarm...8 hours or arm/disarm...restore.
The bell output is not activated for alarms on zones that have exceeded the swinger shutdown counter limit. Swinger shut-
down on global zones log once to the system area.
Note: Swinger shutdown resets on all partitions when any partition on the system is armed or disarmed, or every day at mid-
CP-01
night. For CP-01, swinger shutdown is restored after 8 hours of inactivity.
Once reset, the alarm system communicates normally.
Note: The event buffer can follow swinger shutdown if enabled.
Tampers/Restores
This value defines the number of times the same system tamper event occurs before going into swinger shutdown. Valid
entries are 000 to 014.
Maintenance Troubles/Restores
This value defines the number of times the same system Maintenance (trouble) type event occurs before going into swinger
shutdown. Fire troubles follow the Maintenance Swinger Shutdown variable.
[002] – Communication Delays
Transmission Delay (seconds)
This value defines the delay before an alarm is transmitted.
The delay is for zones which have the Transmission Delay attribute enabled. Valid entries are from 000 to 255 seconds (0-
45 seconds for CP-01). Each partition shares the same active timer. If the delay is already active due to an alarm on a dif-
ferent partition, any new activity on another partition does not restart the communications delay timer.
Burglary verified events are postponed until after the transmission delay expires. When a valid disarming procedure is used
while the transmission delay is active, a communications canceled message is briefly displayed on the keypad when the
delay is canceled.
NA
Note: For UL/ULC listed installations, the entry delay plus communication delay cannot exceed 45 seconds.
DTMF Contact ID
SIA FSK
