Trouble [05] Device Faults
Trouble
[01] Zone 1-128 faults
Wireless zones:
Enter [01] to view zones in fault. This trouble is
generated by a zone wireless supervisory trouble.
Hardwired zones:
This trouble is generated by a short on hardwired zones
when DEOL or TEOL is used.
[03] Siren 1-16 faults
This trouble is caused by a wireless supervisory fault on a
wireless siren.
[04] Repeater 1-8 faults
This trouble is caused by a wireless supervisory fault on a
wireless repeater, or by the repeater shutting down due
to a loss of AC/DC power.
[06] Device mask
Enter [06] to view the zone label in masking condition. A
zone programmed as 24H Anti- Masking or a wireless
device has detected a masking condition with one of its
sensors.
[08] Heat trouble
Enter 10 to view the wireless zone which is detecting low
temperature.
[09] CO trouble
Enter 09 to view the zone of a CO wireless device that is
in low sensitivity trouble.
[10] Freeze trouble
Enter 08 to view the wireless zone which is detecting high
temperature.
[11] Probe disconn.
Enter [11] to view the wireless zone which has detected a
disconnect probe.
[12] Fire trouble
Enter [012] to view which zones are in Fire trouble.
Section 7: Troubleshooting
Press [05] to determine specific trouble
Troubleshooting
Ensure fire zones have a 5.6K resistor (green, blue, red) connected.
Remove wire leads from Z and COM terminals and measure resistance of the wire
leads:
Check for a short on DEOL zones or an open condition on SEOL fire zones.
Connect a 5.6K resistor across the Z and COM terminals. Verify the trouble condition
clears.
Placement test a wireless device and re-locate it if bad results are received.
.
Placement test the wireless siren and re-locate if needed.
Placement test the wireless repeater and re-locate if needed.
Refer to the device manual to troubleshoot conditions that may cause masking detec-
tion for that devices sensors.
Move the device to a location with room temperature and ensure the trouble clears. If
not check the programming threshold for high temperature for the zone.
Refer to the CO devices manual for troubleshooting steps for low sensitivity trouble.
Move the device to a location with room temperature and ensure the trouble clears. If
not check the programming threshold for low temperature for the zone.
Refer to the temperature or flood detectors manual for troubleshooting steps for
probe disconnected.
If fire zone is a wireless smoke, ensure it is not tampered, or in supervisory trouble.
Ensure the smoke chamber is cleared of dust. If a 2wire smoke is used ensure a 2.2K
EOL resistor is used. If zone is a 4 wire smoke, ensure a 5.6K EOL resistor is used.
