4.5 Keypad Function Keys

Keypads have 5 programmable function keys that can be configured to perform one of the following actions:
Table 4-2 Function Key Programming Options
[00] Null Function Key
[02] Instant Stay Arm
[03] Stay Arm
[04] Away Arm
[05] [*][9] No-Entry Arm
[06] [*][4] Chime On/Off
[07] System Test
[09] Night Arm
[12] Global Stay Arm
[13] Global Away Arm
[14] Global Disarming
[15] Temperature
[16] Quick Exit
To program a function key:
1. Enter Installer Programming [*][8].
2. Enter section [861] for keypad 1 function key programming.
3. Enter [001] to [005] to select a function key to program.
4. Enter a 2-digit number to assign a function key operation - [00] - [68]. See table above.
5. Continue from step 3 until all function keys are programmed.
6. Press the [#] key twice to exit Installer Programming.
Programmed function keys must be pressed for 2 seconds in order to activate the function.
Function Key Definitions
This section provides detailed descriptions of each programmable function key option.
[00] Null Function Key
This option deactivates the function key. The key does not perform any function when pressed.
[02] Instant Stay Arm
This feature is similar to the Stay Arm function key, except that no exit delay is applied and the system arms immediately.
If no Stay/Away zone types are programmed, the alarm system arms in Away mode.
Note: Do not use this function with CP-01 installations.
[03] Stay Arm
Only perimeter zones are armed. Interior zones are bypassed regardless of whether or not delay zones are tripped during
the exit delay.
[04] Away Arm
All interior and perimeter zones are armed. CP-01 panels require an exit through a delay zone during the exit delay or the
system will arm the perimeter zones only.
[05] No-Entry Arm [*][9]
All Delay 1 and Delay 2 zones become instant zones. If a door or window is opened the system goes immediately into alarm.
This function is typically used when no occupants are expected to return to the site during the armed period. Activation of this
function key requires an access code. This function only works while the system is disarmed.
See "[*][9] No-Entry Arming" on page 73 for more information.
Section 4: System Operation
[17] Arm Interior
[21]-[24] Command Output 1 to 4[*][71] - [*][74]
[29] Bypass Group Recall
[31] Local PGM Activate
[32] Bypass Mode
[33] Bypass Recall
[34] User Programming [*][5]
[35] User Functions [*][6]
[37] Time & Date Program
[39] Trouble Display [*][2]
[40] Alarm Memory [*][3]
[61]-[68] Partition 1 to 8 Select
