Table 5-4 : Cellular Technology
Display
GP
ED
HS
H+
CD
EV
LT
5 bars indicate maximum signal strength. 0 bars indicate the communicator is not connected to the network.
[851] Alternate Communicator Programming
The programming sections described in this document can be viewed at the keypad. To start programming, enter: [*] [8]
[installer code] [851] [section number], where section number is the 3-digit section number referenced in this section. The pro-
gramming worksheets at the end of this document can be used to record the new values when programming changes have
been made from the default values. Installers may review/record programming options at the panel keypad.
System Options
[001] Ethernet IP Address
Default (000.000.000.000)
Enter the IP address of the communicator. Ensure that the IP address is unique to the communicator on the local network.
Format is 4 fields, each field is a 3 digit decimal number. Valid range: 000-255. If an IP address is programmed in this sec-
tion, the unit will operate with static IP (DHCP disabled). Sections [002] and [003] must also be programmed when using
static IP addresses.
Note: Default for this section is Dynamic Host Configuration Protocol (DHCP) enabled. When enabled, the DHCP server will
set values for: IP address [001], subnet mask [002], and gateway [003]. Programming an IP address in this section will dis-
able DHCP (Static IP).
[002] Ethernet IP Subnet Mask
Default (255.255.255.000)
Enter the Ethernet IP subnet mask of the communicator. Format is 4 fields, each field is 3 digits. Valid range: 000-255.
Note: If DHCP is enabled, the DHCP server will assign the subnet mask for this section and the programmed value will be
ignored.
[003] Ethernet Gateway IP Address
Default (000.000.000.000)
Enter the Ethernet gateway IP address of the communicator. The gateway IP address is required when a router is used on
the local network to reach the destination IP address specified in section [001]. Format is 4 fields, each field is a 3-digit
decimal number.
Valid range: 000-255.
Note: If DHCP is enabled, the DHCP server will assign the gateway IP address for this section and the programmed value
will be ignored.
[004] Receiver Supervision Interval
Default (135)
When receiver supervision is enabled (ON) in section [005] toggle option [3], the unit sends heartbeats to Ethernet receiver 1
or cellular receiver 1 to test the communications path. Use this section to set the interval time (in seconds) when heartbeats
will be sent to the receivers. Valid range 00000-65535 seconds. If the programmed value is less than 10 seconds, super-
vision is disabled.
Section 5: Programming
Technology
GPRS
EDGE
HSPA
HSPA
CDMA
EVDO
LTE
