Trouble [1] Service Required
[03] Loss of clock
The alarm controller internal clock is not set .
[04] Output 1 Fault
HSM2204 output #1 open circuit.
[05] Warm Start
Control panel has recovered from a software lockup
[06] USB Wi-Fi Connected
HSM3WIFI USB to Wi-Fi Adapter is plugged into the
panel
[07] Power Unit Fail (System)
A fault with the internal power supply has been detected
on the panel.
[08] Power Unit Failure (HSM3204CX)
A fault with the internal power supply has been detected
on the corbus repeater.
[09] Power Unit Failure (HSM3350)
A fault with the internal power supply has been detected
on the 3A power supply.
[10] Overcurrent
The combined output power on the panel has exceeded
2A for a period of more than 5 minutes.
Trouble [2] Module Battery Trouble Press [02] to determine specific trouble
Trouble
[01] Panel Low Battery
The panel detects that the battery is
below the low battery threshold (less
than 11.5VDC).
NOTE: This trouble condition will not
clear until the battery voltage is
12.5VDC min., under load. NOTE: If
battery is new allow 1 hour to
charge.
[02] Panel No Battery
The panel detects that no battery is
present or that the battery is
shorted.
Section 7: Troubleshooting
Press [01] to determine specific trouble
To program the time and date:
Enter [*][6][Master Code] then press [01].
Enter the time and date (24-hour clock) using the following format: HH:MM
MM/DD/YY
e.g.,. For 6:00 pm, June 29, 2010:
Enter: [18] [00] [06] [29] [10]
If output #1 is unused: ensure terminals O1, AUX are jumpered with 1K resistor
(brown, black, red).
If output #1 is used: disconnect wire leads from O1, AUX terminals, measure
resistance of leads:
Open circuit indicates a break in wiring.
This trouble automatically restores after two minutes or when acknowledge via the [*]
2 menu. Contact Tech Support if this trouble persists or re-occurs periodically.
The trouble automatically clears once the HSM3WIFI adapter is unplugged from the
panel. This trouble serves as a warning as to not to forget to unplug the adapter when
configuration via Wi-Fi is completed.
Ensure the combined output power of the panel is not exceeding 2A. Power cycle the
panel and if the trouble persists it may indicate a permanent hardware failure.
Ensure the combined output power of the corbus repeater module is not exceeding
2A. Power cycle the module and if the trouble persists it may indicate a permanent
hardware failure.
Ensure the combined output power of the 3A power supply module is not exceeding
3A. Power cycle the module and if the trouble persists it may indicate a permanent
hardware failure.
Reduce the load on the panel by re-powering modules or detectors with a separate
power supply module.
Troubleshooting
Verify voltage measured across DC input terminals is 16-18 VAC. Replace HSM65W power supply
adapter if required.
Connect battery, remove AC power.
Verify measured voltage across Aux terminals is 12.5VDC min.
Replace battery if it is no longer able to hold a charge due to age.
Verify battery is connected.
Ensure battery leads are connected with the right polarity.
Connect battery, remove AC power.
Verify measured voltage across Aux terminals is 12.5VDC min
