Note: Each Ethernet/cellular receiver must be programmed with a unique DNIS.
[113] Ethernet Receiver 2 Address
Default (000.000.000.000)
Programming the Ethernet receiver 2 IP address with 000.000.000.000 will disable Ethernet.
Enter the Ethernet receiver 2 IP address. This address will be provided by the central station system administrator. Format is
4 fields, each field is a 3-digit decimal. Valid range: 000-255.
Note: When a valid IP address has been programmed, Ethernet receiver 2 is enabled and will communicate events over the
Ethernet channel.
Ethernet receiver 2 and cellular receiver 2 may be configured to communicate to the same central station receiver.
To configure the device to operate using this common receiver mode functionality, program the Ethernet receiver 2 and cel-
lular receiver 2 IP address and port number with the same values. When operating in common receiver mode the Ethernet
receiver 2 account code will be used for communications over Ethernet and cellular.
Note: Do not program Ethernet receiver 1 and Ethernet receiver 2 to communicate to same receiver.
[114] Ethernet Receiver 2 UDP Remote Port
Default (03061)
This section is used to program the port number used by Ethernet receiver 2. Set the value of this port when the installation
is located behind a firewall, and must be assigned a particular port number as determined by the central station system
administrator. Valid range: 00000 - 65535.
Note: Do not program Ethernet receiver 1 and Ethernet receiver 2 port with the same value.
[115] Ethernet Receiver 2 UDP Local Port
Default (03065)
Use this section to program the value of the local outgoing port. Set et the value of this port when the installation is located
behind a firewall and must be assigned a particular port number as determined by the network administrator. Valid range:
00000 - 65535.
Note: Do not program Ethernet receiver 1 and Ethernet receiver 2 port with the same value.
[116] Ethernet Receiver 2 Domain Name
Default ( )
Enter the Domain Name as 32 character ASCII.
Ethernet Options
[124] Ethernet Test Transmission Time
Default (9999)
Enter a 4 digit number (0000-2359) using the 24-hour clock format (HHMM) to set the test transmission time of day. Valid
range: 00 - 23 hours (HH) and 00 - 59 minutes (MM). Programming a value of 9999 will disable the test transmission time.
Note: The internal date and time will automatically be programmed when the unit communicates with the primary receiver.
[125] Ethernet Test Transmission Cycle
Default (000000)
This value represents the interval between test transmissions, in minutes. Valid range: 000000 - 999999 minutes. Once the
unit has sent the initial periodic test transmission, all future test transmissions will be offset by the programmed number of
minutes. See sections [026] - [029].
Table 5-6 Ethernet Test Transmission Interval
Test Transmission Interval
Programmed Minutes
Note: Minimum value is 000005 minutes. Programming an interval that is less than 5 minutes will disable test transmission.
Cellular Receiver 3 Options
[201] Cellular Receiver 3 Account Code
Default (0000000000)
Section 5: Programming
Daily Weekly
001440 010080
- 143 -
Monthly
043200
