Wireless PG Outdoor temperature probe (requires PGx905)
Wireless PG 2-way keys
Wireless PG panic button
Wireless PG 2-button key
Wireless PG sirens
Wireless PG repeater
Wireless PG door and window contacts
Wireless PG 2-way magnetic contact device w/hardwired input
Wireless PG flat PIR
Wireless PG outdoor door contact w set/unset support
Wireless PG recessed door/window contact
Wireless PG ceiling mount detector with smart presence
Wireless PIR motion detector
Wireless PG door/window contact
Wireless ceiling PIR detector
Wireless magnetic contact with hardwired input
Central Station Receivers
SG-System I, II, III, IV, 5
Enclosures
The PowerSeries Pro main board can be installed in the metal enclosures listed below: Tamper protection switches can be installed on all
enclosures, including door opening protection and/or removal from the mounting position. Doors can be secured using screws or keylock.
• Model HSC3010C (hinged door) made of 18 Ga steel, painted white, dimensions 372 mm x 412 mm x 114 mm, weight: 9.75 lb or 4.2 Kg
• Model HSC3010CR (hinged door) made of 18 Ga steel, painted red, dimensions 372 mm x 412 mm x 114 mm, weight: 10.0 lb or 4.5 Kg
• Model HSC3030CAR (hinged door) made of 18 Ga steel(base) and 16Ga (door), painted white, dimensions 375mm x 412mm x114mm,
weight: 11.45 lb or 5.2 Kg
• Model HSC3020C(removable door) made of 18 Ga steel, painted white, dimensions 459 mm x 414 mm x 103 mm, weight: 4.3 Kg (no
batteries)/12 Kg (17Ah)
• Model HSC3020CP (removable door) made of PC-ABS, color white, dimensions 368 mm x 489 mm x 108 mm, weight: 2.3 Kg (no batteries)/7.7
Kg (17Ah)
For EN50131-1 Grade 2 or Grade 3 compliant installations, all holes on the side of the cabinets shall be covered (plugged) if no accessories are
installed in the cabinet that will use these mounting holes.
The equipment enclosure shall be secured to the building structure before operation. Use four screws (appropriate for the wall material on which
it is attached) inserted through the four mounting holes provided in the back of the enclosure base.
Section 1: Introduction
- 11 -
PGTEMP-PROBE
UL UL
PGx929 , PGx939
UL
PGx938
UL
PGx949
UL UL
PGx901 , PGx911
UL
PGx920
UL
PGx975
UL
PGx945
UL
PGx914
PGx955
UL
PGx307
UL
PGx862
PG9902
UL
PG9303
PG9872
UL
PG9312
