Notes on the operating manual

1 Notes on the operating manual
This operating manual is an important aid for ensuring the safe and reliable
functioning of the device.
Reflex Winkelmann GmbH accepts no liability for any damage resulting from
failure to observe the information in this operating manual. In addition to the
requirements set out in this operating manual, national statutory regulations
and provisions in the country of installation must also be complied with
(concerning accident prevention, environment protection, safe and professional
work practices, etc.).
This operating manual describes the device with basic equipment and interfaces
for optional equipment with additional functions.

Notice!
Every person installing this equipment or performing any other work at
the equipment is required to carefully read this operating manual prior
to commencing work and to comply with its instructions. The manual is
to be provided to the product operator and must be stored near the
product for access at any time.
2

Liability and guarantee

The device has been built according to the state of the art and recognised safety
rules. Nevertheless, its use can pose a risk to life and limb of personnel or third
persons as well as cause damage to the system or other property.
It is not permitted to make any modifications at the device, such as to the
hydraulic system or the circuitry.
The manufacturer shall not be liable nor shall any warranty be honoured if the
cause of any claim results from one or more of the following causes:
• Improper use of the device.
• Unprofessional commissioning, operation, service, maintenance, repair or
installation of the device.
• Failure to observe the safety information in this operating manual.
• Operation of the device with defective or improperly installed
safety/protective equipment.
• Failure to perform maintenance and inspection work according to
schedule.
• Use of unapproved spare parts or accessories.
Prerequisite for any warranty claims is the professional installation and
commissioning of the device.

Note!
Arrange for Reflex Customer Service to carry out commissioning and
annual maintenance,  11.1 "Reflex Customer Service",  30.
3

Safety

3.1

Explanation of symbols

3.1.1

Symbols and notes used

The following symbols and signal words are used in this operating manual.
DANGER
Danger of death and/or serious damage to health
• The sign, in combination with the signal word 'Danger', indicates
imminent danger; failure to observe the safety information will result
in death or severe (irreversible) injuries.
WARNING
Serious damage to health
• The sign, in combination with the signal word 'Warning', indicates
imminent danger; failure to observe the safety information can result
in death or severe (irreversible) injuries.
CAUTION
Damage to health
• The sign, in combination with the signal word 'Caution', indicates
danger; failure to observe the safety information can result in minor
(reversible) injuries.
ATTENTION
Damage to property
• The sign, in combination with the signal word 'Attention', indicates a
situation where damage to the product itself or objects within its
vicinity can occur.
18 — English Anybus® - CompactCom / Modbus-RTU® — 08.11.2022 - Rev. B
 Note!
This symbol, in combination with the signal word 'Note', indicates
useful tips and recommendations for efficient handling of the product.
3.2

Personnel requirements

Installation and operation tasks are to be carried out by specialist personnel or
specially trained personnel only.
The electric connections and the wiring of the device must be executed by a
trained electrician in accordance with all applicable national and local
regulations.
3.3

Personal protective equipment

Use the prescribed personal protective equipment as required (e.g. ear
protection, eye protection, safety shoes, helmet, protective clothing, protective
gloves) when working on the system.
Information on personal protective equipment requirements is set out in the
relevant national regulations of the respective country of operation.
3.4

Intended use

The bus module Anybus-CompactCom ® for Modbus-RTU ® is an extension
module that can be mounted in the Control Touch controller of Reflex systems. It
enables connection of the Control-Touch controller to the Modbus-RTU ®
network as a slave.
The bus module is integrated directly into the slot provided for it in the
controller's regulator housing. A master-slave process is used for data transfer. A
potential-free RS-485 interface is available on the Modbus side. A D-sub
connector is necessary for the connection.
Reflex Control-Touch controller
The bus module Anybus-CompactCom ® for Modbus-RTU ® must only be used in
Reflex Control-Touch controllers.
Any use of the bus module other than this shall be deemed incorrect use.
