If the tape drive is installed in a previously unused drive bay, assign the
next available SCSI address to the tape drive (from 0 to 6, depending on the
system configuration). For example:
Your system has both a CD-ROM drive and a
bottom right bay, ID6 and ID 5. If all other drive bays are empty, you can:
Install the tape drive in any of the other three drive bays.
Assign the next available SCSI address, ID 4 in this example, to the newly
installed tape drive (regardless of which bay is used).
Note – If the SPARCcenter 2000 system has more than one
however, the ID numbers for all
numbers for any 8 mm tape drives or 4 mm tape auto-loaders.
Table E-1 Example of SCSI Addresses for the 8 mm Tape Drive
Drive Bay
SCSI Address
Bottom right
ID 6 (lower); ID 5 (upper)
Top right
ID 4
Top left
ID 3
Bottom left
ID 2 (upper); ID 1 (lower)
Device select
switches
Half-height
tape
Figure E-8
Four Locations for alf Height 8 mm Tape Drives (Front View)
SCSI Targeting
1
-inch tape drive in the
/
4
1
-inch tape drives must be higher than the ID
/
4
E
1
-inch tape drive,
/
4
Half height
tape
ID 6 & ID 5
CD-ROM and
1
/
-inch tape
4
E-7
