E.7 Setting SCSI Target for the 5 1/4-Inch Disk Drives
E-10
For example, the SunCD (ID 6) has a higher ID number than
drives, which have higher ID numbers than 8 mm tape drives and 4 mm tape
auto-loaders.
Table E-2 gives an example of how to number five drives in a SCSI tray.
Table E-2 Example of ID Numbering in a SCSI Tray
Device
SunCD or SunCD Plus
1
-inch tape drive
/
4
8 mm tape drive or 4 mm tape auto-loader
8 mm tape drive or 4 mm tape auto-loader
8 mm tape drive or 4 mm tape auto-loader
Plug the address cable for the disk drive into the SCSI ID connector at the rear
of the drive. See Figure E-11.
Note – Orient the address cable so that the pin 1 of the address cable connector
plugs into pin 1 on the SCSI ID connector at the rear of the drive.
