5 Diagnostics and Troubleshooting

The module provides diagnostic information in four forms to the user.
1) Status Data values are transferred from the module to the controller tags in the
CompactLogix processor.
2) Status data is available to other nodes on the network by reading of module's internal
database area containing status data.
3) All data contained in the module can be viewed through the configuration/debug port
to an attached terminal emulator.
4) LED status indicators on the front of the module yield information on the modules
status.
The following sections explain how to obtain the Status Data from the module and the
meaning of the individual LED's on the module.

5.1 Reading Status Data from the module

The MVI69-DFCM module returns a 29-word Status Data block that can be used to
determine the module's operating status. This data is located in the module's database
at registers 7600 to 7628 and at the location specified in the configuration. This data is
transferred to the CompactLogix processor continuously with each read block.

5.2 LED Status Indicators

The LED's will indicate the module's operating status as follows:
ProSoft
Module
CFG
P1
P2
APP
BP ACT
ProSoft Technology, Inc.
MVI69-DFCM User Manual
June 24, 2004
Color Indication
Stat
us
Green On Data is being transferred between the module and
a remote terminal using the Configuration/Debug
port.
Off No data is being transferred on the
Configuration/Debug port.
Green On Data is being transferred between the module and
the DF1 network on Port 1.
Off No data is being transferred on the port.
Green On Data is being transferred between the module and
the DF1 network on Port 2.
Off No data is being transferred on the port.
Amber On The MVI69-DFCM module program has recognized
a communication error on one of its ports.
Off The MVI69-DFCM is functioning normally.
Amber On The LED is on when the module is performing a
write operation on the backplane.
Off The LED is off when the module is performing a
read operation on the backplane. Under normal
operation, the LED should blink rapidly on and off.
Diagnostics and Troubleshooting
51
