MVI56E-SMGC ♦ ControlLogix™ Platform
Enhanced FMC722 TPU General Communication Module

4.7 Reading Status Data from the Module

Module status information is useful for troubleshooting and can be accessed in several
different ways. The following is a listing of the data contained in the MVI56E-SMGC
status data object.
Object in
SMGCInStat
PassCnt
Product
Rev
OP
Run
BlkErrs.Read
BlkErrs.Write
BlkErrs.Parse
BlkErrs.Err
Client[0].Connect
Client[0].State
Client[0].Open
Client[0].Estab
Client[0].Close
Client[0].SyncErr
Client[0].DBPCount
Client[0].DBTCount
Client[0].CfgWord
Client[0].RxCount
Client[0].RxOverflow
Client[0].TxCount
Client[0].TxOverflow
Client[0].LenErr
ProSoft Technology, Inc.
Description
Block Offset
Start
53
Program cycle counter
54
Product name
56
Revision level
58
Operating system level
60
Run number
62
Number of blocks transferred from module to
processor
63
Number of blocks transferred from processor to
module
64
Number of blocks parsed by module
65
Number of block errors in module
66
Connection state of Client 0
67
State machine value
Number of times socket open function called
68
Number of times socket established
69
70
Number of times socket closed
71
Total number of errors in trying to find the sync bytes
for the start of a message
72
Total number of data blocks parsed
73
Total number of data blocks built.
74
Configuration error word
75
This status value contains the total number of
messages received by the client.
76
This status value contains the total number of
messages received that exceed the specified buffer
size for the client.
77
This status value contains the total number of
messages transmitted by the client.
78
This status value contains the total number of
transmit messages that exceeded the specified
maximum buffer size for the client.
79
Total number of messages with a length setting
larger than MAX_BUFFER.
Diagnostics and Troubleshooting
User Manual
Page 64 of 98
