MVI69-GSC ♦ CompactLogix or MicroLogix Platform
Generic ASCII Serial Communication Module

Stopping the Data Analyzer

Press [S] to stop the data analyzer. Use this option to freeze the display so the data can
be analyzed. To restart the analyzer, press [B].
Important: When in analyzer mode, program execution will slow down. Only use this tool during a
troubleshooting session. Before disconnecting from the Config/Debug port, please press [S] to stop the data
analyzer, and then press [M] to return to the main menu. This action will allow the module to resume its
normal high speed operating mode.

Returning to the Main Menu

Press [M] to return to the Main menu.
4.3

Reading Status Data from the Module

The MVI69-GSC module returns a 29-word Status Data block that can be used to
determine the module's operating status. This data is located in the module's database
at registers 6670 to 6698 and at the location specified in the configuration. This data is
transferred to the CompactLogix processor continuously.
