Configuration Examples
server can supply information on the names and IP addresses for which it is
responsible. For all other information, a DNS server contacts other DNS servers. For
the establishment of every connection from the workstation, it is possible to give
either an IP address, or a name that a DNS server resolves into an IP address.
8.3

OpenCom 100 in a Serverless LAN

In a peer-to-peer network, the workstations are connected to one another via
network cables. In many networks, the cables run in the form of a star from a
central hub or switch. Such networks do not require special servers. This configu-
ration example is also valid for a LAN with a server using a protocol other than IP
(e.g. AppleTalk or IPX/SPX).
ISP OpenCom
(DNS) (DHCP, RAS,
int. DNS, Internet)
S S Net
0 0
Ext. PC 1
PC
S Net
0
The OpenCom 100 in a serverless LAN
In a serverless LAN, the OpenCom 100 takes over the IP configuration of the con-
nected workstations. All IP settings necessary for the workstations are assigned by
the OpenCom 100 via DHCP (dynamic host configuration protocol). In this oper-
ating mode, an IP address space reserved for such networks is used:
192.168.99.254
255.255.255.0
192.168.99.254
192.168.99.254
92
Note: For further explanations of technical terms, refer to
the Glossary on the CD supplied.
PC 2
Hub Net
OpenCom 100 in a Serverless LAN
OpenCom 100 IP address
Network mask (class C network)
DNS server IP address
Default gateway IP address
